Dahua DH-H2A 2MP Indoor Fixed-focal Wi-Fi Pan & Tilt Network Camera

Product Profile

Series Overview

Dahua Wireless series cameras are not only easy to install and operate, but also perform outstandingly and cost-effective. They provide full coverage of a scene with 1080p resolution, 0° to 355° pan and -5°to 80° tilt. Their powerful functions, such as human detection and auto-tracking, assist with the accurate detection and continuous tracking of targets. Information is also synchronously sent to your phone to keep you up-to-date. These cameras are widely used in small and medium-sized scenes such as small-sized retail stores.

Functions

Motion Detection
When moving objects appear in the monitoring image, Dahua Motion Detection technology triggers alarm or records.

Day/Night
Dahua Day/Night function provides color image when illumination is adequate; when illuminance is inadequate, it switches night mode and provides white and black image. It can guarantee that the network camera can work normally when illuminance changes.

Two-way Talk
With its built-in high-sensitivity microphone and high-power speaker, the camera realizes two-way talk through the mobile app.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Technical Specification

Make	Dahua Technology
Manufacturer	Dahua Technology Ltd
Category	CCTV>IP cameras
Model code	DH-H2A
Series	Wi-Fi series
Colour Type	Colour / Monochrome
Resolution	2 MP resolution
Electrical Specifications	Voltage: 5 V DC Power Consumption: Basic: 1.7 W ; Max.: 3.5 W
Motion Activated	Yes
Wide Dynamic Range	Yes
Picture Elements HxV	1920 × 1080
Network Properties	Image Frame Rate: 25 fps Interface: RJ-45 (10/100 Base-T)
Electronic Shutter Range	Auto/Manual 1/3 s–1/100,000 s
Compression Type	H.265
Physical Specifications	Weight g: 204.2 Dimensions mm: φ77.8 x 108.1
Environmental Specifications	Operating Temperature ^oC: -10 ~ +45 C (14 ~ 113 F) Operating Humidity %: ≤ 95
Additional info	2-MP 1/3.2" CMOS image sensor, low luminance, and high definition image. Outputs max. 2 MP (1920 × 1080)@25 fps. H.265 codec, high compression rate, ultra-low bit rate. Built-in IR LED, and the max. IR illumination distance is 10 m. Supports max. 256 G Micro SD card; built-in Mic; built-in speaker. 5 VDC power supply. Supports Wi-Fi. Supports motion detection, human detection.
