Uri Guterman

The introduction of 8 and 16 channel Wisenet X Series NVRs makes it cost-effective, for even small businesses to take advantage of the licence-free Deep Learning AI video analytics, built into Wisenet AI cameras. As is the case with the 32 and 64 Wisenet X NVRs introduced in 2020, by reading the AI metadata captured by Wisenet AI cameras, the new NVRs are able to help users to quickly and accurately search video for objects and the attributes associated to them.  Deep Learning AI video analytics The Deep Learning AI video analytics simultaneously detects and classifies various object types The Deep Learning AI video analytics simultaneously detects and classifies various object types, including people, vehicles, faces and licence plates, and is supported by Wisenet AI algorithms. Unique to Hanwha Techwin, these identify the attributes of objects or people, such as age group, gender or colour of the clothing that a person is wearing. The attributes are saved as metadata on the NVRs, alongside the images captured by the cameras, enabling users to quickly search for specific objects or incidents. The algorithms are even able to recognise if a person is wearing glasses or holding a bag. Key features shared by the NVRs include the following: A brand-new user interface. New trapezium design extends life of HDDs by enhanced heating dissipation. Up to 32 MP recording with improved support for Wisenet 4K, 8K, thermal imaging, PTZ and multi-sensor models. WiseStream II complementary compression technology, which when combined with 265 compression, improves bandwidth efficiency by up to 75%, compared to current H.264 technology. Dual HDMI and VGA display outputs. Automatic Recovery Back-up. Event push notifications to smartphones. ONVIF Profile S conformant. Easy configuration The installation time of the new NVRs is minimised, by the ability of engineers to remotely connect to the NVRs. This is achieved via a smartphone or tablet, without having to set up a complex network, by using P2P and unique QR product codes. Configuration of the NVRs is also easily achieved with the help of an intuitive interface and installation wizard provided. GDPR and NDAA compliant The NVRs are also NDAA compliant, which has become an essential requirement Security personnel can apply bookmarks to prevent important video from being overwritten, with the NVRs programmed to automatically delete the bookmarked video, after a defined time period to ensure compliance with GDPR regulations. The NVRs are also NDAA compliant, which has become an essential requirement that consultants, system designers and system integrators need to take into consideration when submitting tenders for projects involving clients who operate multi-nationally. The 3 new Wisenet X NVRs are as follows: XRN-820S: 8 channels. Up to 100Mbps network camera recording with up to 12TB data storage via 2 SATA HDDs slots. PoE. XRN-1620SB1: 16 channels. Up to 140Mbps network camera recording with up to 24TB data storage via 4 SATA HDDs slots. PoE. XRN-1620B2: 16 channels. Up to 140Mbps network camera recording with up to 80TB data storage via 8 SATA HDDs slots. New Wisenet X Series NVRs “There are so many ways in which Deep Learning AI video analytics can enhance the value of a video surveillance solution and these new NVRs make the technology affordable even for applications which only require a small number of cameras,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. Uri Guterman adds, “Together with Wisenet AI cameras, the NVRs offer a high degree of detection accuracy, while minimising false alarms. In addition to providing users with a powerful tool to identify and respond quickly to any suspicious activity, they also offer businesses, and particularly the retail sector, with the opportunity to capture and analyse business intelligence.”

Mavili Elektronik Ticaret A.S. has developed a plug-in that enables its Maxlogic intelligent addressable fire detection system to interact with Hanwha Techwin’s Wisenet WAVE video management software (VMS). The integration of Maxlogic with Wisenet WAVE via the Mavili SPRVSR+ plug-in ensures control room operators can rapidly visually verify a fire alarm event and take appropriate action. Detailed maps, together with information on the Maxlogic devices installed at each site, can be displayed alongside images captured by Wisenet cameras. Visually verifying alarm event When an alarm event occurs, a pop-up message instantly appears on the screen, with operators able to view live images from cameras installed at the event’s location. PTZ cameras are automatically moved to the point where there might be a fire. PTZ cameras are automatically moved to the point where there might be a fire After viewing the video of an event, operators can use Wisenet WAVE’s graphical user interface to silence the alarm and reset the system, whilst an event log provides access to the recorded video for forensic post-event investigations. A robust and integrated solution “Adding video verification to our Maxlogic fire detection system with the help of Wisenet high-resolution cameras, means we can offer end-users even greater peace of mind in knowing they are benefiting from an integrated solution that offers them a very high level of protection from a potential fire”, said Mr. Gurkan Erdem, Sales & Marketing Director of Istanbul based Mavili Elektronik Ticaret A.S. “In addition to capturing superb quality images, Wisenet cameras have an excellent reputation for being robust and ultra-reliable. Hanwha Techwin is, therefore, an ideal technology partner for us to work with to ensure our customers gain maximum advantage from their Maxlogic intelligent addressable fire detection systems”. Wisenet WAVE Wisenet WAVE is designed to make it almost effortless to monitor high-definition video streams. An auto-discover feature ensures connected cameras and a wide range of third-party IP network devices can be addressed and set up in just minutes. An intuitive ‘drag & drop’ tool makes it easy to set up a display of live and recorded images on a single screen or video wall, with customisable layouts and sizes. Characteristic features Motion detection and video analytics support can be configured to generate alerts with push notifications sent to mobiles Other key features include a virtual PTZ which, with just a simple click of the mouse, enables operators to zoom in to see close-up detail of any suspicious activity, whilst motion detection and video analytics support can be configured to generate alerts when user-defined incidents occur, with push notifications sent to mobile devices. Enhancing partnership “We are delighted that an independent manufacturer such as Mavili Elektronik Ticaret A.S. has entrusted Hanwha Techwin to be its preferred technology partner and has invested its time in developing the SPRVSR+ plug-in”, said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “The Maxlogic fire detection brand is highly respected and has achieved success in over 70 countries. Mavili Elektronik Ticaret A.S. shares our passion for providing the highest possible levels of pre and post-sales support and we are therefore very pleased that this integrated solution will be available to all our customers across Europe”.

Hanwha Techwin has added 5 new 2-megapixel high-definition AI cameras to its Wisenet P series. The new cameras are designed to complement the 4K models which were launched in 2020, by making it more cost-effective for users to benefit from AI technology. As is the case with the existing 4K models, the new cameras are equipped with Deep Learning AI video analytics which delivers a high level of detection accuracy whilst minimising false alarms. It does so by simultaneously detecting and classifying various object types, including people, vehicles, faces and licence plates. AI video analytics The Deep Learning AI video analytics is supported by Wisenet AI algorithms which identify the attributes of objects or people, such as their age group and gender or the colour of their clothes. The attributes are saved as metadata alongside the images captured by the Wisenet P series AI cameras, enabling users to quickly search for specific objects or incidents. The algorithms are even able to recognise if a person is wearing glasses or is holding a bag. Operators are able to take advantage of VMS from software developers such as Genetec and Milestone Operators are able to take advantage of VMS from software developers such as Genetec and Milestone, as well as Wisenet WAVE and Wisenet SSM, to forensically search for specific objects or people by filtering the recorded metadata, as well as use the search capabilities of the latest generation of Wisenet X NVRs which are able to read AI metadata captured by the cameras. Social distancing analytics A recent firmware update, incorporated into the new 2-megapixel cameras and available as a downloadable upgrade for the existing 4K models, sees face mask detection and social distancing analytics added to the cameras’ capabilities. There is also enhanced people counting and queue management functionality. To help remove the risk of overcrowding and to assist, for example, store managers make the best use of human resources, this includes the ability to count the number of people queuing and generate alerts if a specified maximum number is exceeded. The cameras are also equipped with Hanwha Techwin’s Occupancy Monitoring application which generates alarm outputs that can be used to control automatic doors or a traffic beacon, as well as trigger the display of ‘wait’ or ‘enter’ messages when the maximum permitted a number of people allowed in an area at one time, has been reached. Video analytics applications With these various licence-free Deep Learning AI video analytics applications available as standard on the Wisenet P series AI cameras, users do not have to incur the cost of purchasing licences to be allowed to use them. Key features of the new 2-megapixel Wisenet P series AI cameras include: Digital auto-tracking which enables the cameras to transmit two streams of video, providing the option for operators to see a camera’s full field of view, whilst at the same time using a digital PTZ auto-tracking feature while viewing Full HD images, to track the movements of a person or vehicle. WiseNRII optimises image noise reduction to reduce blurring. 50ma output which can be used to power LEDs, sensors or glass break detectors. Minimising network bandwidth The cameras have a BestShot feature which selects the best images which have been captured The new cameras also benefit from next-generation WiseStream III complementary compression technology. This applies a low compression rate to objects and people which are detected and tracked by AI, whilst applying high compression to the remaining field of view. When combined with H.265, this results in an improvement in bandwidth efficiency by up to 80% compared to current H.264 technology. To further minimise network bandwidth and data storage requirements, as well as increase operator efficiency, the cameras have a BestShot feature which selects the best images which have been captured of a person or object and only sends these, together with the associated metadata, to a storage server. The new Wisenet P series AI cameras are as follows: PNB-A6001 box camera PNO-A6081R bullet camera with built-in IR illumination PND-6081RV dome camera with built-in IR illumination PND-6081RF flush mounted dome camera with built-in IR illumination PNV-A6081R vandal-resistant dome with built-in IR illumination Mission critical applications “We are confident that these new affordable cameras will help prove that AI based video surveillance technology is not just suitable for high-end, mission critical applications,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “In addition to helping combat criminal activity, we believe there are countless applications where the business intelligence captured with the assistance of the Deep Learning AI video analytics, as well as the cameras’ ability to help businesses operate safely during the COVID-19 affected era, will ensure they offer a high return on investment, regardless of where they may be deployed.”

Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe, provides a bite-sized overview of the contribution IR illumination can make to the effectiveness of a video surveillance system. Video surveillance cameras need light to capture high quality images 24 hours a day. In times gone by, this meant supplementary lighting had to be installed to ensure cameras could operate effectively in low light and night-time conditions. The cost of doing so could be prohibitive if civil engineering work was required for cabling purposes. Impacting residential areas Light pollution could also be an issue for local authorities in terms of people complaining about its impact in residential areas. As often has been the case, technology came to the rescue in the form of infra-red (IR) illumination. Unlike the eyes, which can only detect white light within 400 to 700 nanometres (approx.) wavelengths, IR light at 850 nanometres can assist cameras to capture high quality monochrome images in what human beings would consider to be complete darkness. More energy efficient Earlier generations of the IR illumination were in the form of incandescent IR lights Earlier generations of the IR illumination were in the form of incandescent IR lights, which were expensive to buy and were power hungry, as well as having a very limited lifespan. More recently, cameras have been equipped with LED IR illuminators which are much more energy efficient and reliable. With the IR light emitted invisible to the human eye, they offer the additional benefit of control room operators being able to direct security guards to the scene or report the suspicious activity to police, without the intruders being aware they have been detected. The big breakthrough in terms of delivering light to enable cameras to capture clear, sharp images at night has come from the development of adaptive IR illumination. Vehicle number plates This, as the name suggests, adjusts the angle of the camera’s IR LEDs to match the level of zoom and as such, the IR illumination can be concentrated on objects up to a distance of 200 metres. Cameras with adaptive IR illumination introduced by manufacturers such as Hanwha Techwin, use three sets of IR LEDs which are calibrated to ensure near, medium distance and far away objects, such as people and vehicle number plates, are sufficiently illuminated. In doing so, they offer a highly effective, as well as energy efficient and eco-friendly way to ensure video surveillance cameras are able to perform to the best of their abilities, regardless of the lighting conditions.

Hanwha Techwin has announced consultants, system designers and system integrators are now able to specify Wisenet Q series and Wisenet WAVE PoE NVRs supplied with Seagate hard disk drives (HDDs). High-density HDDs “Seagate’s space-efficient, high-density HDDs (hard disk drives) are able to perfectly meet the data storage demands of video surveillance systems and equally important, they have a reputation for being ultra-reliable,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. Uri Guterman adds, “Our decision to collaborate with Seagate Technology will therefore enhance the ability of these Wisenet NVRs (Network Video Recorders) to robustly fulfill the requirements of virtually any video surveillance applications, other than those, which require a server-based storage solution.”  Wisenet Q and WAVE PoE NVRs Wisenet WAVE PoE NVRs provide a cost-effective way of utilising the Wisenet WAVE VMS Wisenet WAVE PoE NVRs provide a cost-effective, seamlessly integrated and optimised way of utilising the latest version of the feature-rich Wisenet WAVE video management software (VMS), without having to install a server. Wisenet Q PoE NVRs are designed to be suitable for virtually any small to medium size video surveillance applications, which require a cost-effective, robust and reliable video recording and storage solution. Retail and corporate applications As such, they are ideal for budget limited office, retail and warehouse type applications that do not need a high number of cameras, but where users wish to have the ability to record high-definition images.

The six new cameras added to the Wisenet X PTZ PLUS range have been developed by Hanwha Techwin to enable users to capture evidence grade images of activity occurring in large open area applications. The ability of the new 2MP, 6MP and 4K Wisenet X PTZ PLUS cameras to operate effectively in environments such as airports, car parks, industrial estates, stadia and city centres, is enhanced by a long list of technically advanced features, which include AI-based object tracking, precise PTZ control and improved pre-set accuracy. The cameras, which have a lightweight, compact form factor, are also able to capture high-quality images of objects up to a distance of 200 metres regardless of the lighting conditions, with the help of adaptive IR technology which adjusts the angle of the camera’s IR LEDs to match the level of zoom. AI auto-tracking Operators can programme a camera to lock onto and auto-track a specific object with the help of deep learning video analytics An AI auto-tracking feature allows control room operators to efficiently monitor the movement of objects while remaining hands-free to control other cameras. With a right-click of a mouse, operators can programme a camera to lock onto and auto-track a specific object. It does so with the help of deep learning video analytics which detects and classifies people and vehicles. The video analytics is supported by AI algorithms unique to Hanwha Techwin. Alternatively, operators can take advantage of highly accurate manual control PTZ functionality to zoom in to see close up detail of target objects and track their movement. Other key features and functions Pre-set Accuracy: During their life cycle, most PTZ cameras are likely to be expected to ‘pan and tilt’ many thousands of times and it is not unknown for positioning errors to occur. Wisenet PTZ PLUS cameras, which have a pre-set accuracy of ±0.1˚, are able to detect if they are not precisely aimed at the specified field of view and will move within one second to the correct position. Focus Save: Applied to up to 32 pre-defined areas, focus save functionality ensures that regardless of the lighting conditions, a camera is able to rapidly come into focus when it is moved to a new position. Tilt Range: The cameras’ extended tilt range of up to 110⁰ allows any objects positioned above the cameras to be seen. Wisenet7 chipset At the heart of all Wisenet X PTZ PLUS cameras is Wisenet7, Hanwha Techwin’s most powerful chipset to date, which with extreme’ Wide Dynamic Range (WDR) functionality that utilises Local Contrast Enhancement and Scene Analysis technologies, is able to facilitate the capture of ultra-clear images from scenes containing a challenging mix of bright and dark areas. Excellent low light performance is also assured thanks to the utilisation of 3D noise reduction technology which, while minimising motion blur, uses several filters to isolate and remove pixels that are causing noise, while a new noise reduction algorithm improves the edge and colour of objects. Cyber secure Wisenet7 chipset incorporates a list of technologies that significantly enhance the cyber security credentials Complying with UL CAP and Secure by Default standards, the Wisenet7 chipset also incorporates an impressive list of ground-breaking technologies that significantly enhance the cyber security credentials of the Wisenet PTZ PLUS cameras. They also benefit from a Hanwha Techwin proprietary device certificate issuing system which embeds unique certificates into Wisenet products during both the development phase and manufacturing process. This further enhances the camera’s ability to prevent hackers from tampering with its firmware. Installer friendly Compact and approximately 65% lighter than most PTZ domes, the camera-mount installed Wisenet X PTZ PLUS cameras can be quickly and easily deployed, requiring engineers during a first fix to just ‘match 3 points and twist’. This conveniently enables them to tighten screws without having to hold onto the camera. Unlike conventional PTZ cameras which require up to 5 separate cables, the Wisenet X PTZ PLUS cameras only need a single RJ45 cable to operate and this is installed with a flexible bush to ensure the camera is waterproof. The new Wisenet PTZ PLUS cameras are as follows: Wisenet XNP-9250: 4K 25x PTZ camera Wisenet XNP-9250R: 4K 25x IR PTZ camera Wisenet XNP-8250: 6MP 25x PTZ camera Wisenet XNP-8250R: 6MP 25x IR PTZ camera Wisenet XNP-6400: 2MP 40x PTZ camera Wisenet XNP-6400R: 2MP 40x IR PTZ camera Authority comments “Our comprehensive Wisenet camera line-up offers a variety of options for monitoring wide open areas. However, I would encourage consultants, system designers and system integrators to take a close look at our PTZ PLUS range when there is a need to closely monitor and automatically track moving people or vehicles,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “Our design, development and manufacturing teams have combined their expertise to pack these cameras with a long list of practical features and innovative technology which collectively will surely meet, if not exceed, users’ expectations.”

Two new Wisenet cameras equipped with Hanwha Techwin’s ground-breaking Wisenet7 chipset have reinforced the company’s claim to be the manufacturer of multi-directional cameras.  The 4-channel PNM-9022V utilises alpha blending technology to stitch the overlapping images captured by its four Full HD sensors into a seamless 8.3-megapixel 209° image, thus ensuring an operator never loses sight of a person or vehicle moving across a wide area. Digital PTZ functionality Superseding the highly successful Wisenet PNM-9020V, the PNM-9022V can also be used to capture 180° images, with operators able to take advantage of digital PTZ functionality across two of the camera’s channels. With Wisenet7 SoC, Hanwha Techwin’s most powerful chipset to date, at its heart, the PNM-9022V’s 4 sensors, which come with 2.8mm fixed focal lenses, are able to capture high definition colour images when the lighting level is as low as 0.03 Lux. Wisenet7 also features Hanwha Techwin proprietary ‘extreme’ Wide Dynamic Range (WDR) technology which, performing at up to 120dB, utilises new Local Contrast Enhancement and Scene Analysis technologies to enable the camera to capture ultra-clear images from scenes containing a challenging mix of bright and dark areas. Certificate issuing system Lens Distortion Correction (LDC) technology utilised by the PNM-9022V corrects the distortion created Lens Distortion Correction (LDC) technology utilised by the PNM-9022V corrects the distortion created through the use of wide-angle lenses. This delivers images which more closely resemble what is seen through the human eye. As part of the fast-growing number of new cameras which incorporate the UL CAP certificated Wisenet7 chipset, the National Defence Authorization Act (NDAA) compliant PNM-9022V is packed with an impressive list of technologies to protect it from cyber-attacks. It also benefits from a Hanwha Techwin proprietary device certificate issuing system, which embeds unique certificates into Wisenet7 products during both the development phase and manufacturing process. This further enhances the camera’s ability to prevent hackers from tampering with its firmware. Cable connection purposes 2 Micro SD/SDHC/SDXC slots enable up to 1TB of video or data to be stored at the edge should there be disruption to the network. Video of any incidents, which potentially might have been lost on the recorder side, can therefore be retrieved from the camera when the network connection has been restored. Minimising the time needed to be spent on site, the PNM-9022V has a hinged backplate to provide easy access for cable connection purposes. Installers have to simply install the back plate, clip the camera in place and tighten two screws. Intelligent video analytics Other key features include the following: A suite of built-in Intelligent Video Analytics (IVA), which includes audio detection, defocus detection, directional detection, enter/exit, appear/disappear, motion detection, virtual line and camera tampering detection. Heatmap video analytics which provides business intelligence on customer density and buying behaviour. Support for WiseStream II complementary compression technology, as well as H.265, H.264 and MJPEG compression formats. Bandwidth efficiency is improved by up to 75% compared to current H.264 technology, when WiseStream II is combined with H.265 compression. PoE+ which negates the need to install a power supply and separate cabling for the camera. IP66, IK10 and NEMA4X rated for protection against water, dust and mechanical impact. Cost-effective solution Coinciding with the launch of the PNM-9022V, the PNM-9322VQP with 4 sensors and an integral PTZ camera, is designed to provide a highly cost-effective solution for detecting and tracking objects over wide open areas. The option of exchangeable 2 and 5-megapixel lens modules enables the camera’s sensors to work together to seamlessly capture 360° images of up to 20-megapixel resolution. In addition, the device’s PTZ camera element can be configured to zoom in and track a moving object or move to a user defined preset position when the line crossing detection function of the multi-directional camera detects activity. It is also able to ‘hand-over’ to cameras covering adjacent areas to ensure operators can continue to observe people or vehicles as they move out of its field of view. Providing audio support The NDAA compliant PNM-9322VQP supersedes the highly successful PNM-9320VQP Equipped with the Wisenet7 chipset, the NDAA compliant PNM-9322VQP supersedes the highly successful PNM-9320VQP, with the additional benefit of providing audio support. “These two new models perfectly complement our other existing 2, 3, 4 and 5-channel multi-sensor cameras which collectively enable us to offer customers an affordable multi-directional camera solution for virtually any video surveillance project,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. Providing significant savings “All of these cameras will help users achieve a high return on investment (ROI) as they can perform the role of a greater number of standard HD cameras. In doing so, they provide significant savings on camera purchasing costs and with less cable, conduit, mounting hardware and network switches required, installation costs are reduced as well. With only a single IP connection, they also only require one VMS licence.” “The value of these two new cameras being NDAA compliant and UL CAP certificated should also not be underestimated. System integrators will quite often find that both can be a key requirement when they are submitting tenders for projects involving end-users which operate multi-nationally.”

A new range of Wisenet Public View Monitors (PVMs) equipped with a built-in SSL connected 2-megapixel camera have been introduced to help retailers deter fraudsters and shoplifters. Offering a choice of 10”, 27” and 32” monitors, the 3 new PVMs are designed to be located at store entrances, shopping aisles, till points or self-checkout pay points. With an SD/SDHC/SDXC slot that can facilitate up to 512GB of data storage, the PVMs provide store management with the opportunity to display a slide show which can include supplier adverts, own-brand product promotions and special offers. A default blinking recording in progress message is superimposed over the displayed graphics to let would be thieves know they are on camera, with operators having the option to customise the message and configure its size, colour, opaqueness and positioning on the monitor. Face detection Face and motion detection feature can be configured to switch the display to live view to make people aware they are being watched Supported by the Wisenet WAVE and SSM video management platforms as well as Wisenet NVRs, the ONVIF Conformant PVMs can be programmed so that images captured by the cameras are either continuously recorded or when prompted to do so by built-in face or motion detection video analytics. The face and motion detection feature can also be configured to switch the display to live view to make people aware they are being watched, as they will be able to see themselves on the monitor as they enter a store or walk down a shopping aisle. The display reverts to the slide show after a specified number of seconds. The PVMs, which can be integrated with tagging (EAS) systems to record images of people who might be leaving the store with stolen items, also provide support for the AI-Masking, AI-Bio, AI-Face-Detect and AI-Occupancy video analytics applications, developed by Hanwha Techwin’s technology partner, A.I. Tech. Video evidence Regardless of whether they are displaying live images or a slide show, or the monitor has been turned off by someone using a remote control, the PVMs will continuously stream images to a control room where they can be viewed via video management software (VMS), as well as continue to be recorded on an on-site or remotely located NVR. The ultra-low light capabilities of the new PVMs, together with Wide Dynamic Range (WDR) technology performing at up to 150dB, enables the built-in camera to capture clear, sharp images in strongly contrasting light conditions at, for example, store entrances where strong sunlight may be streaming in. Power over Ethernet All three PVMs can be powered by 12V DC, with the Wisenet SMT-1030PV also offering the option to utilise Power over Ethernet (PoE+) if there isn’t an existing power supply close to where the PVM is being installed. A single cable of up to 100m is all that is needed to provide both powers to the SMT-1030PV and for network communications. The three new Wisenet PVMs, which can be mounted by using standard VESA brackets, are as follows: SMT-1030PV: 10” monitor with LED backlight and 1024 x 600 display resolution. SMT-2730PV: 27” monitor with LED backlight, HDMI input and Full HD display. SMT-3230PV: 32” monitor with LED backlight, HDMI input and Full HD display. Loss prevention strategy “With retailers increasingly relying on PVMs to play an important role within their strategic approach to loss prevention, we have designed our new models to make it quick and easy, as well as cost-effective, to deploy them across a large number of stores,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “As the only PVMs available which, for cyber security and data protection purposes, are supplied with a complete built-in SSL connected camera, they eliminate the need for system integrators to install and connect a separate supporting camera, which some other manufacturers’ PVMs require." "By building in an intuitive user interface, we have also made it extremely easy for busy store managers to take full advantage of the PVM’s functionality, including the ability to utilise the monitor for advertisement and signage using the slide show mode.”

The new Wisenet PNM-9000QB camera module is designed for ATM, retail and other covert fraud and theft detection applications. Remote camera heads comprise an image sensor camera equipped with a fixed, pinhole or fisheye lens. As their name implies, they are designed to be installed remotely from the other components of a video surveillance camera and this means they can be discretely installed within an ATM and other tight spaces, or located neatly into a corner of a room or lift with the help of mounting brackets. Specially designed cables With Hanwha Techwin’s powerful Wisenet7 chipset at its heart, the PNM-9000QB camera module is able to simultaneously process images from the 4 remote head cameras. With less cable and network switches required, this makes the module far more cost-effective than its single channel predecessor, as the time system integrators have to spend on-site is reduced. With just a single IP connection, there is also a cost saving for end-users, as only one VMS license is required. When connected via specially designed cables and installed the other side of a wall to a module, the camera heads are totally isolated from the network. Although this is likely to be of benefit to most end-users, it will be of particular importance to banks who need to protect confidential customer data and prevent fraud. Contrasting light conditions The Tamper Detection feature is included in the module’s suite of Intelligent Video Analytics (IVA) Additional protection comes in the form of Tamper Detection which generates an alarm if someone covers, changes the angle or sprays paint on one of the head camera’s lens. The Tamper Detection feature is included in the module’s suite of Intelligent Video Analytics (IVA), as is defocus detection, motion detection and loitering detection. The Wisenet7 chipset at the heart of the PNM-9000QB features Hanwha Techwin’s latest generation ‘extreme’ Wide Dynamic Range (WDR) technology. This performs at up to 120dB to enable each of the remote camera heads to capture clear, sharp 2-megapixel Full HD images at full frame rate even in strongly contrasting light conditions which often exist at ATMs’ sites. Upgrading network capacity With the support of WiseStream II, the bandwidth required to transmit images captured by a PNM-9000QB is significantly reduced, which may negate the need for banks to incur the cost of upgrading network capacity when the camera is retrofitted at an existing ATM location. This is because bandwidth efficiency is improved by up to 75% compared to current H.264 technology, when WiseStream II is combined with H.265 compression. 2 Micro SD/SDHC/SDXC slots enable up to 512GB of video or data to be stored at the edge should communication between the PNM-9000QB and a Wisenet NVR be disrupted. The Automatic Recovery Back-up (ARB) feature built into the latest generation of Wisenet NVRs, facilitates the transfer and seamless storage of the images stored on the PNM-9000QB’s SD cards when the network connection is restored. This provides continuity of recording and negates the risk of what could be valuable video evidence being lost. Monitoring tall spaces Other key features include the following: Hallway View enables operators to effectively monitor tall and narrow spaces such as shopping aisles. Support for H.265, H.264 and MJPEG compression formats. 2 alarm input/outputs (I/O). HDMI output. Power over Ethernet (PoE+) which negates the need to install a power supply and separate cabling for the camera. Cyber security technologies The PNM-9000QB has also been developed to meet the UK’s Secure by Default standard The UL Cybersecurity Assurance Program (UL CAP) certificated Wisenet7 chipset built into the PNM-9000QB is packed with technologies which collectively offer the highest possible levels of protection for edge-based cameras from the activities of cyber criminals. These cyber security technologies, together with tamper detection and the use of special network cables, offer banks, retailers and other types of end-users with peace of mind in knowing their confidential data will be kept safe from hackers. The PNM-9000QB has also been developed to meet the UK’s Secure by Default standard and as such, is cyber and network secure by default out-of-the-box. Monitoring live images “The PNM-9000QB camera module offers a highly secure and cost-effective way for security personnel to monitor live images or capture video evidence of activity at rows of ATMs installed at airports, banks, hotels, leisure facilities or shopping centres,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “With criminals finding ever more sophisticated ways to commit fraud at ATMs, the module offers an affordable and flexible way to covertly monitor any suspicious activity and use the captured video to carry out post-incident forensic investigations.”

The Wisenet TNM-3620TDY is a bi-spectrum, multi-channel device which incorporates a QVGA-class thermal imaging camera and a 2-megapixel video surveillance camera. As such, it can detect heat and measuring temperature with a very high degree of accuracy, whilst providing visual verification of people within its field of view. In body temperature mode, the QVGA-class thermal imaging camera is able to estimate a person’s temperature within a range of 30⁰~45°C, with +/-0.5⁰C accuracy. When supported by black body technology, the accuracy increases to +/-0.3⁰C, allowing the TNM-3620TDY to provide a strong indication that a person may have a fever. Medical electrical equipment Offering support for Deep Learning AI-based face detection functionality, the TNM-3620TDY can measure the temperatures of up to 10 people in real time at a distance of up to 3m, with operators able to choose to view either the captured thermal images or standard high-definition video images. The TNM-3620TDY is compliant with a series of device technical standards for the safety and essential performance of medical electrical equipment, which has been published by the International Electrotechnical Commission (IEC). In addition, Hanwha Techwin has completed the FDA facility registration process and device registration for the TNM-3620TDY in respect of FDA 510(k) clearance is in progress. Thermal imaging camera This provides a powerful tool which generates alerts when there is a threat of fire in recycling In normal Radiometric mode, the thermal imaging camera with a high degree of accuracy detects and measures changes in temperature within -20⁰C to 130°C range, with users able to set up detection zones to cover specific areas of interest within the camera’s field of view. This provides a powerful tool which generates alerts when there is a threat of fire in recycling, waste management and landfill type facilities, where spontaneous combustion may occur. A detected change in temperature may also be a warning that machinery in factories, processing plants, cold stores and utilities, is faulty. In addition, a spot detection feature enables operators, via a web viewer, to click on any pixel within an image to obtain a measurement of the temperature of the area covered by that pixel. Dynamically controls encoding The TNM-3620TDY supports H.265, H.264 and MJPEG compression formats, as well as WiseStream II, a complementary compression technology which dynamically controls encoding, balancing quality and compression, according to movement in the image. Bandwidth efficiency is improved by up to 75% compared to current H.264 technology when WiseStream, which is unique to Wisenet cameras, is combined with H.265 compression. Other key features include: The 2-megapixel video surveillance camera features a set of Intelligent Video Analytics which include directional detection, motion detection, enter/exit, virtual line, audio detection and cameras tampering detection. The TNM-3620TDY has a Micro SD/SDHC/SDXC slot which allows up to 256GB of video or data to be stored at the edge should there be disruption to the network. Video evidence, which potentially might have been lost, can therefore be retrieved when the network connection has been restored. PoE+ (IEEE802.3at) and 12VDC. Video surveillance industry The TNM-3620TDY is a great addition to our suite of COVID-19 related solutions" “Regretfully, in terms of the reputation of the video surveillance industry, some so called ‘fever screening’ solutions devised by other manufacturers, have attracted negative publicity. This is because they have been oversold in terms of what they are capable of delivering,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “Although we have often been the first to market with new product developments and technologies, in this instance we have taken the time to develop the TNM-3620TDY to ensure it is fit for purpose. We highly value the trust our customers and business partners have in our ability to provide solutions which do not compromise on performance and quality. In this respect, they can be confident this camera will meet, if not exceed, their expectations.” “As such, the TNM-3620TDY is a great addition to our suite of COVID-19 related solutions, which includes face mask detection, occupancy monitoring and AI deep learning-based social distance measuring applications.”

The latest addition to the Wisenet P ‘Premium’ camera series removes the risk that important video evidence might be missed when there is a need to monitor two adjacent sides of a building. With the middle camera sensor covering the blind spot between the areas being monitored by the other two sensors, the 3-channel multi-directional Wisenet PNM-8082VT camera provides an efficient way to ‘see around corners’ and offers a cost-effective alternative to deploying three standard fixed cameras. Single IP connection “Together with our existing 2, 4 and 5-channel multi-sensor cameras, the PNM-8082VT offers cost savings for both system integrators and end users,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “They all use less cable, conduit, mounting hardware and network switches, compared to that normally needed to install a greater number of standard cameras, and with just a single IP connection, only one VMS licence is required.” IP66, IK10 and NEMA4X ratings for protection against water, dust and mechanical impact, makes the PNM-8082VT an ideal choice for outdoor applications, although it also offers an equally affordable solution for indoor applications, such as when there is a requirement to observe activity taking place, for example, at a ‘T’ shaped corridor.  Scene analysis technologies With a removable infrared cut filter (ICR), each of the PNM-8082VT’s sensors offers true day/night camera functionality The PNM-8082VT’s middle sensor can be used to make it impossible for an intruder to attempt to attack or spray paint on the cameras’ lens without video evidence of them being captured. A potential blind spot, which can occur when two standard cameras are pointing in different directions to cover two corner sides of a building, is avoided. This is because the PNM-8082VT’s 3 directional monitoring ensures that regardless of which direction the intruder approaches, they will be caught on camera. With a removable infrared cut filter (ICR), each of the PNM-8082VT’s sensors offers true day/night camera functionality and is able to catch 2-megapixel high definition colour images when the lighting level is as low as 0.04 Lux. They are also equipped with Hanwha Techwin proprietary ‘extreme’ Wide Dynamic Range (WDR) technology which, performing at up to 150dB, utilises new Local Contrast Enhancement and Scene Analysis technologies to capture ultra-clear images from scenes containing a challenging mix of bright and dark areas. Camera tampering detection The PNM-8082VT’s 2 Micro SD/SDHC/SDXC slots enable up to 1,024GB of video or data to be stored at the edge should there be disruption to the network. Video of any incidents, which potentially might have been lost, can therefore be retrieved when the network connection has been restored. Other key features include the following: Single IP connection with only one VMS licence is required. Simple Focus: A single push of a button located at the back of the camera is all that is needed to automatically focus the camera. A suite of built-in Intelligent Video Analytics (IVA) which includes defocus detection, directional detection, enter/exit, motion detection, virtual line and camera tampering detection. Support for WiseStream II complementary compression technology, as well as H.265, H.264 and MJPEG compression formats. Bandwidth efficiency is improved by up to 75% compared to current H.264 technology when WiseStream II is combined with H.265 compression. PoE+ which negates the need to install a power supply and separate cabling for the camera. “The Wisenet PNM-8082VT gives system integrators a competitive edge as it can be installed much quicker and with less cost than the equivalent number of standard cameras. It also provides a more cost-effective option than a 4-channel multi-directional camera when only 3 sensors are needed to meet the requirements of the application,” said Uri Guterman. “In a highly competitive market, there is an opportunity for system integrators to pass on these cost savings to their end-user clients.”

The time needed to plan, design and accurately evaluate the efficiency of a video surveillance system has been significantly reduced with the news that JVSG’s highly acclaimed IP Video System Design Tool now supports all Wisenet IP Network cameras from Hanwha Techwin. Visualisation of security system System designers and system integrators simply need to import 2D or 3D models of the end user’s building or site, and then enter in some parameters specific to the project, such as the proposed installation height of each camera and the required field of view. JVSG System Design Tool produces an accurate visualisation of the planned video surveillance system With this information, the JVSG System Design Tool produces an accurate visualisation of the planned video surveillance system which, for example, will help identify any blind spots. JVSG System Design Tool The JVSG System Design Tool, which is able to calculate precise camera lens focal lengths, viewing angles and pixel density requirements within seconds, helps choose the best model for each camera location. This is because key features of Wisenet cameras, such as camera resolution and IR Illumination distance have been integrated into the programme. Depending on whether there is a requirement to simply detect and monitor activity in an area or if there is a need to capture evidence grade images, the JVSG System Design Tool will indicate if the specified cameras will be able to match an end-user’s operational requirements. It can also be used to calculate the bandwidth usage of the cameras and corresponding video storage requirements. Wisenet IP cameras and JVSG System Design Tool integration “We are delighted to have successfully completed our integration with JVSG’s powerful design tool, which efficiently replaces the need to produce CAD drawings and minimises the time needed to make complex calculations,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. He adds, “Consultants, system designers, product specifiers and systems integrators will all benefit from the reduction in the time it takes to manually search for camera specifications and build these into system designer proposals.” Adding value to Wisenet brand JVSG's IP Video System Design Tool will, without doubt, greatly contribute to our ability to achieve this objective" Uri Guterman stated, “At Hanwha Techwin, we fully understand that having best in class and high performance products is not enough. We also need to add value to the Wisenet brand by continually looking at ways to make it as easy as possible for our cameras to be specified, installed, commissioned and maintained.” He further commented, “Alongside our own proprietary tools, such as Device Manager, Wisenet ToolBox Plus and the Wisenet QR Scanner App, the JVSG’s IP Video System Design Tool will, without doubt, greatly contribute to our ability to achieve this objective.” Technology partnership Max Shumeyko, Founder of JVSG, while commenting on the success of the integration said, “We are delighted to have formed a technology partnership with Hanwha Techwin, a globally renowned manufacturer of video surveillance products, which also has a formidable reputation for leading the market with feature rich cameras that capitalise on the very latest advances in technology.” Max adds, “The integration of the comprehensive Wisenet camera range with our Design Tool, will save users considerable time and remove the ‘headache’ normally associated with designing an IP network video surveillance camera.”

The opportunity for businesses to take full advantage of the meta-data captured by AI cameras has been significantly enhanced with the introduction of 3 new Wisenet NVRs. The feature-rich NVRs, which offer up to 400Mbps network camera recording, are able to read the AI metadata, enabling operators to quickly and accurately search video for objects and attributes associated to them.  Introduced at the same time as the 64 channel XRN-6410B4 and sharing the same features, the Wisenet XRN-3210B4 has 32 channels, whilst the 64 channel XRN-6410DB4 NVR is also equipped with a dual switched-mode power supply (SMPS), to ensure continuity of recording for mission critical applications. The 3 NVRs are compatible with all Wisenet AI cameras which have licence-free Deep Learning AI video analytics onboard. Minimising false alarms Together, the NVRs and AI cameras offer a high degree of detection accuracy, whilst minimising false alarms The analytics simultaneously detects and classifies various object types, including people, vehicles, faces and licence plates, and is supported by Wisenet AI algorithms. Unique to Hanwha Techwin, these identify the attributes of objects or people, such as age group, gender or colour of the clothing a person is wearing. The attributes are saved as metadata on the NVRs alongside the images captured by the cameras, enabling users to quickly search for specific objects or incidents. The algorithms are even able to recognise if a person is wearing glasses or holding a bag. Together, the NVRs and AI cameras offer a high degree of detection accuracy, whilst minimising false alarms. As such, they provide control room operators and security personnel with a powerful tool to identify and respond quickly to any suspicious activity. Analyse business intelligence They also offer businesses, and in particular the retail sector, with the opportunity to capture and analyse business intelligence, which will enable them to review customer demographics, gain a greater understanding of customer behaviour and improve the customer experience. In this respect, because AI can handle extremely busy and dynamic scenes, it is much more suitable for retail environments than traditional video analytics. In addition to H.265, H.264 and MJPEG, the new NVRs support WiseStream II, a complementary compression technology, unique to Hanwha Techwin, which dynamically controls encoding, balancing quality and compression, according to movement in the image. When WiseStream II is combined with H.265 compression, bandwidth efficiency is improved by up to 75% compared to current H.264 technology. Valuable video evidence Automatic Recovery Back-up will facilitate the transfer and seamless storage of the images stored on the SD card Installation time is minimised with the ability for engineers to remotely connect to the NVRs via a smartphone or tablet without having to set up a complex network, by using P2P and unique QR product codes. In addition, the NVRs can be easily and quickly configured to match an end-user’s requirements via an updated Wisenet user interface, and with the help of a new installation Wizard. If communication between one of the NVRs and a Wisenet camera equipped with an SD card is disrupted, Automatic Recovery Back-up (ARB) will facilitate the transfer and seamless storage of the images stored on the SD card when the network connection is restored. This provides continuity of recording and negates the risk of what could be valuable video evidence being lost. Other key features include: 16 HHD bays enable up to 160 TB of data to be recorded and stored onboard in non-RAID mode. RAID-5 and 6 support (8 HDDs x 2 array) Improved Wisenet camera compatibility with support for 4K, 8K, thermal imaging, PTZ and multi-sensor models Dual HDMI display outputs Simultaneous playback on all channels New user-friendly graphical display which provides operators with a wide range of practical features, including ‘Instant’, timeline and event thumbnail preview Event push notifications to smartphones ONVIF Profile S conformant Video security solutions “Our AI cameras, supported by these new NVRs, are allowing us to offer future-proof video security solutions that deliver a level of functionality which would have been difficult to imagine just a few years ago,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “They are a clear demonstration of Hanwha Techwin’s commitment to harness the power of AI technology and in doing so, enable our customers to achieve maximum value from their video surveillance systems.”

The Wisenet QR Scanner App is designed to help quickly create a list of all Wisenet devices associated with a specific project, without having to take the products out of their packaging. The App, which can be downloaded from the Apple App Store and Google Play and run on any smart mobile device, is able to capture information on all the latest generation of Wisenet products, including model names, serial numbers and MAC addresses. This information can then be used to create a Bill of Materials (BOM) to verify that an order has been fulfilled and subsequently that all devices have been installed. In addition, the information captured by the App can be exported to the Wisenet Device Manager software tool and edited to enable installation engineers to configure the products, update their firmware, change passwords and much more. QR scanner technology “We are continually looking at ways at which we can make life easier for our customers and we are particularly driven to do so in the current tough economic climate,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin. “We are therefore very pleased to be able to capitalise on accurate and proven QR scanner technology to help reduce installation time and minimise costs.”

With system designers having so many options when it comes to specifying the most appropriate cameras to monitor large areas, Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe, provides an overview of the merits of some of the most suitable camera formats. PTZ cameras PTZ cameras have traditionally been used for city and wide area surveillance applications such as airports, car parks, shopping centres, sports stadia and warehouses, with operators able to track the movement of objects and zoom in to observe close-up detail of any activity. The ability of an operator to proactively monitor an incident and zoom in to verify what is occurring, ensures they are able to quickly decide on the most appropriate response. Many PTZ cameras feature auto-tracking, as well as continuous pan and pre-set positioning In addition, many PTZ cameras feature auto-tracking, as well as continuous pan and pre-set positioning, which means that images of a moving object will be captured and recorded even when operators are distracted or are away from their workstations. The deterrent effect of PTZ cameras configured to automatically tour an area should also not be underestimated as they will create a strong impression to would be offenders that they are being watched, even if the images captured by the cameras are not being monitored in real-time. 8K cameras Whilst it should be emphasised that PTZ cameras still have a big part to play in detecting anti-social or criminal activity, recent advances in video surveillance technology has meant that system designers now have the option to consider specifying other types of cameras which, depending on the application, might be more suitable. The sharpness and clarity of the images captured by 8K video surveillance cameras, for example, simply ‘need to be seen, to be believed’. In reality, very few users are likely to deploy 8K cameras with the intention of just monitoring an entire field of view. The value of these cameras comes from the fact that 8K is the equivalent of 16 x 1080p Full HD images and this means that a single camera can capture a vast amount of information, enabling operators to digitally zoom into a very small part of the scene without any pixilation of the image. Fixed or PTZ cameras For this reason, a football stadium is an excellent example of where an 8K camera can be put to very good use as it would be capable of capturing evidence grade images of 20,000 or more fans occupying a football stand. As such, its price/performance ratio makes the 8K camera a viable, cost-effective alternative to the deployment of multiple fixed or PTZ cameras. PTZ cameras are a lower price option and are ideal for when operators need to scan a wide area of view When it comes to deciding whether an ultra-high resolution 8K or PTZ is the best camera format for any given location, it will very much depend on what the end-user wishes to achieve. However, budget limitations also need to be taken into consideration. In simple terms, an 8K camera is a highly impressive, high performance option if there is a requirement to continually record a camera’s entire field of view at the same time that an operator might need to zoom into a specific area of interest. Video surveillance cameras However, PTZ cameras are a much lower price option and are ideal for when operators need to constantly scan a wide area of view, whilst having the flexibility when necessary, to quickly zoom in to see what may be occurring in greater detail. The case for PTZ cameras is further strengthened when real-time monitoring is more important than recording video for evidence purposes and equally important, the latest generation of PTZ cameras are equipped with adaptive IR technology which adjusts the angle of the camera’s built-in IR LEDs to match the level of zoom. Multi-directional cameras typically offer the capabilities of two, three or four video surveillance cameras in a single housing and yet, as they only have a single IP connection, one will only need to purchase one VMS licence. Multi-streaming cameras Those equipped with two separate lenses are designed to capture high definition images of adjacent areas. Depending on the required field of view, there is a choice of interchangeable lens modules which can be easily fitted on site by an installation engineer. These multi-streaming cameras significantly reduce the costs which would normally be associated with installing two separate cameras to monitor, for example, an L-shaped area such as two sections of a corridor or two sides of a building. There are also multi-directional cameras available which feature four separate sensors There are also multi-directional cameras available which feature four separate sensors, with operators able to choose from a broad range of customisable angles and zoom settings per sensor. This offers cost savings for both system integrators and end users, as multi-sensor cameras use less cable, conduit and mounting hardware, compared to what would normally be required to enable up to four separate cameras to do the same job. With less network connections, they also require fewer switches. Built-in PTZ Designed for monitoring large open areas with just one camera, the images captured by the four sensors can be seamlessly stitched to produce a panoramic image covering up to 220° images. Life will also be much easier for installers if models equipped with motorised PTRZ gimbals are specified. These will reduce on-site times as they enable engineers to remotely pan, tilt and rotate the lens’ positions in order to set the camera’s field of view. It is worth noting that some manufacturers, such as Hanwha Techwin, offer 4 channel multi-sensor cameras with an additional integral PTZ camera. This can be configured to automatically zoom in and track a moving object or move to a user configured pre-set position when the motion detection function of one of the four camera sensors detects activity. 360⁰ cameras This addition of a PTZ camera means users are able to avoid incurring the higher capital, installation and maintenance costs of deploying 5 separate cameras to cover a large area, whilst achieving the same level of functionality. A single 360⁰ camera will quite often offer the most efficient and cost-effective way of monitoring a large area and particularly so when a number of standard cameras might normally be required to avoid any blind spots. Most 360⁰ or ‘fisheye’ cameras offer a variety of alternative viewing modes, including single panorama They also offer a compact option for retail stores and other environments where aesthetics is important. Savings can be achieved on maintenance costs compared to other types of cameras, as 360⁰ models have no moving parts. Most 360⁰ or ‘fisheye’ cameras offer a variety of alternative viewing modes, including single panorama, double panorama and quad views. Video management software They are also likely to feature a digital PTZ which allows operators to electronically pan, tilt and zoom in on specific areas for a more detailed view whilst continuing to monitor and record the whole 360-degree view. Some of the cameras will have onboard de-warping functionality. Where this is not the case, video management software, such as Wisenet WAVE, can be used to de-warp the fish-eye images. With so many different camera formats to choose from, consultants, system designers and integrators have an interesting challenge in deciding which cameras will best meet the requirements of a specific video surveillance project. To a large extent, the decision can be logically made with the help of the risk assessment process and by taking into account an end-user client’s operational requirements. High quality images PTZ cameras are likely to be strong contenders when the captured images are to be viewed in real-time An 8K camera, for example, would seem the obvious choice when there is a need to monitor large crowds of people in wide open areas, whilst multi-directional cameras are ideal for capturing images of adjacent areas. PTZ cameras are likely to be strong contenders when the captured images are to be viewed in real-time, as they will provide operators with a high level of control and enable them to proactively track the movement of people. Their greater deterrent effect should also not be underestimated. In reality, a combination of two or more of these types of cameras is likely to be required for most high security or mission critical applications and there is a multitude of other factors to be considered before deciding on the best cameras for a specific project. These include, for example, the required image resolution and if there is a need for the cameras to have built-in IR illumination so that they will capture high quality images regardless of the light levels. Various camera types The need for video analytics and whether the cameras have the ability to support third-party specialist applications should also be considered, as should bandwidth requirements. As always, the best advice is to work with manufacturers one believes that they can trust and ask them to provide live demonstrations of the various camera types. This will allow them to make informed judgements on which cameras have price/performance ratios that will match their specific requirements.

The new Wisenet TNV-8010C 5-megapixel corner mount camera has been built to make it impossible for a ligature to be tied around it, as well as very difficult for someone to rip it off a wall. Although primarily intended to assist police, prison and mental health institutions in preventing inmates and patients from self-harming within secure room environments, the vandal-resistant and water-proof TNV-8010C also offers a robust solution for other demanding applications, such as the monitoring of activity at ATMs and within lifts. Sharp colour images With a wide field of view and a -7~+7° tilt range, the TNV-8010C features Hallway View which enables the camera to capture 5-megapixel images in a 3:4 aspect ratio and 2-megapixel in a 9:16 aspect ratio, thus enabling users to more effectively monitor tall and narrow spaces, such as corridors. The TNV-8010C is equipped with Wide Dynamic Range (WDR) technology that performs at up to 120dB As a true day/night camera which is able to capture clear, sharp colour images when the ambient light level is as low as 0.1lux, the TNV-8010C is equipped with Wide Dynamic Range (WDR) technology that performs at up to 120dB to accurately produce images in scenes that simultaneously contain very bright and very dark areas. Intelligent Video Analytics Key Features IP66, IP6K9K and IK10+ vandal resistant. Optional aesthetically pleasing brushed stainless steel cover. Bi-directional audio support. Built-in alarm input/output (I/O). A suite of built-in Intelligent Video Analytics (IVA) includes defocus detection, directional detection, motion detection, enter/exit, virtual line and audio detection, as well as tampering detection which will generate an alert if someone attacks the camera. Support for WiseStream II complementary compression technology, as well as H.265, H.264 and MJPEG compression formats. Bandwidth efficiency is improved by up to 75% compared to current H.264 technology when WiseStream II is combined with H.265 compression. Micro SD/SDHC/SDXC slot. Up to 128GB of video or data can be stored on-board the camera should there be disruption to the network. Video of any incidents, which potentially might have been lost, can therefore be retrieved when the network connection has been restored. Power over Ethernet (PoE) which negates the need to install a power supply and separate cabling for the camera. 3 magnet points, which lock the camera’s module into its anti-ligature cover, makes installation quick and easy. Installing dome camera “As is the case with our previously introduced 3-megapixel TNV-7010RC corner mount camera which has built-in IR illumination, considerable thought has gone into the design of the TNV-8010C,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “In addition to preventing a ligature being tied around it, the TNV-7010RC’s is also considerably smaller than its predecessor. As such, it will fit neatly into a corner of a room or lift and offer a more attractive option to installing a dome camera in the same location.”

The integration developed between Vanderbilt’s ACT Enterprise access control software platform and Hanwha Techwin’s Wisenet WAVE video management software (VMS), means operators are now able to instantly visually verify access control activity and events directly from ACT Enterprise. ACT Enterprise is a role-based software platform which streamlines the monitoring and management of ACTpro access control systems comprising web-enabled door controller interfaces and MiFare and/or DESfire card readers. The integration removes the need for control room operators to use two separate software platforms to visually verify access control events. Instead, operators are able to conveniently view live streams or recorded video associated with a door, directly in ACT Enterprise. Wisenet WAVE If, for example, a door has been forced open, an operator can simply right-click on the event listed in ACT Enterprise, to immediately replay the relevant recorded video made available by Wisenet WAVE. With an auto-discover feature which enables connected cameras and third-party IP network devices to be addressed and set up in just minutes, Wisenet WAVE makes it almost effortless to monitor high-definition video streams. Wisenet video surveillance and ACT Enterprise systems are increasingly being specified for the same projects" Key features include a virtual PTZ which, with just a click of the mouse, enables operators to zoom in to see close-up detail of any suspicious activity. The latest version of WAVE, 4.1, also features push notifications of user defined alarm events which can be sent to mobile devices. Support for Wisenet AI cameras allows the attributes of classified objects or people to be forensically searched by filtering recorded metadata. Technology partnership “Wisenet video surveillance and ACT Enterprise systems are increasingly being specified for the same projects. With this in mind, we have worked closely with the Vanderbilt team to ensure our respective solutions seamlessly interact,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “This is an excellent example of two global market leaders cooperating to ensure our mutual customers are able to efficiently and conveniently obtain maximum value from their investment in a security solution.” Access control event Commenting on the success of the integration, Michael Moyna, Senior Product Manager at Vanderbilt, stated: “This integration makes for a more precise examination of the video system concerning the access control event. It also removes the operator's need to visit the control room to retrieve the footage, as it can be viewed directly within ACT Enterprise instead. This, of course, delivers an added layer of convenience to the system’s users.”

The Wisenet XNF-9010RV and XNF-9010RVM 12 megapixel fisheye cameras are the latest additions to the range of Wisenet X cameras equipped with Hanwha Techwin’s proprietary Wisenet7 chipset. The ground-breaking Wisenet7 chipset, which boasts an impressive list of technologies that significantly improve the cyber security credentials of Wisenet cameras, is UL Cybersecurity Assurance Program (UL CAP) certificated. It therefore enables Hanwha Techwin to provide users with peace of mind in knowing their confidential data will be kept safe from hackers. Video surveillance solutions In addition to setting a new standard for IP network video surveillance solutions in respect of cyber security, the feature-rich Wisenet7 also ensures the two new fisheye cameras, which have built in IR illumination, are able to capture superb quality images, regardless of the lighting conditions. A new ‘extreme’ Wide Dynamic Range (WDR) feature, for example, utilises new Local Contrast Enhancement and Scene Analysis technologies to capture ultra-clear images from scenes containing a challenging mix of bright and dark areas. The two cameras share a long list of other real-life practical features, with the mobile XNF-9010RVM having the addition of an M12 connector. Built to withstand vibrations, the EN50155 certificated XNF-9010RVM is designed to offer a robust solution for monitoring activity on buses, trains, trucks and other forms of transport. Potential video evidence A digital PTZ allows users to electronically pan, tilt and zoom in on specific areas for a more detailed view Both cameras have on-board dewarping and offer a variety of alternative viewing modes, including single panorama, double panorama and quad views. A digital PTZ allows users to electronically pan, tilt and zoom in on specific areas for a more detailed view, whilst at the same time, continuing to monitor the whole 360⁰ view. It also offers privacy masking, a 12VDC and PoE capability. In the event of network disruption, video is automatically recorded to on-board SDXC storage to ensure that potential video evidence is not lost. In addition to providing a powerful tool to deter and detect criminal activity, the two cameras are equipped with specialist business intelligence applications which enable users to achieve so much more from their video surveillance systems. Improving customer experience Collectively, the heatmap, people counting and queue management video analytics are able to assist businesses, and the retail sector in particular, with identifying opportunities to improve productivity, gain a greater understanding of customer behaviour and improve the customer experience. The two new cameras support H.265, H.264 and MJPEG compression formats, as well as WiseStream II, a complementary compression technology which dynamically controls encoding, balancing quality and compression, according to movement in the image. Bandwidth efficiency is improved by up to 75% compared to current H.264 technology when WiseStream, which is unique to Wisenet cameras, is combined with H.265 compression. Intelligent video analytics Other key features include the following: 1.08mm fixed lens. Stereo graphic type lens enhances resolution within the peripheral regions of an image. Simple Focus: A single push of a button located at the back of the camera is all that is needed to automatically focus the camera via the Simple Focus feature, which can also be remotely accessed via the network. A suite of Intelligent Video Analytics (IVA), which includes defocus detection, directional detection, motion detection, appear/disappear, enter/exit, loitering, tampering, virtual line, audio detection. Sound classification: An audio analytics feature which recognises critical sounds such as raised voices, screams, broken glass, gunshots and explosions, and generates an alert to enable security personnel to quickly react to any incidents. Vandal resistant hard coated dome cover. Cyber security credentials “A single fish-eye camera will quite often offer the most efficient and cost-effective way of monitoring a large area, and particularly so when a number of standard cameras might normally be required to avoid any blind spots.” “They also offer a compact option for environments where aesthetics or space limitations might be an issue,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “Whilst there is no shortage of fish-eye cameras on the market, the cyber security credentials and image enhancing features of the XNF-9010RV and XNF-9010RVM, ensures they stand out from the crowd.”

AI based object tracking, precise PTZ control, improved pre-set accuracy, adaptive IR illumination and enhanced cyber security are just a few of the many innovations which have been built into the new high definition Wisenet X PTZ PLUS cameras launched by Hanwha Techwin. Designed for perimeter protection and large open area applications such as airports, car parks, industrial estates, stadia and city centres, the new 2MP, 6MP and 4K Wisenet X PTZ PLUS cameras are able to capture evidence grade images of objects up to a distance of 200 metres regardless of the lighting conditions, with the help of adaptive IR technology which adjusts the angle of the camera’s IR LEDs to match the level of zoom. Wisenet7 chipset At the heart of the new Wisenet X PTZ PLUS cameras is Wisenet7, Hanwha Techwin’s ground-breaking proprietary chipset which offers an impressive list of technologies that significantly enhance the cameras’ cyber security credentials. The cameras also benefit from a Hanwha Techwin proprietary device certificate issuing system which embeds unique certificates into Wisenet products during both the development phase and manufacturing process. Wisenet7 also ensures the capture of superb quality images with an ‘extreme’ Wide Dynamic Range (WDR) feature utilising Local Contrast Enhancement and Scene Analysis technologies to capture ultra-clear images from scenes containing a challenging mix of bright and dark areas. Auto-tracking An AI auto-tracking feature allows control room operators to efficiently monitor the movement of objects An AI auto-tracking feature allows control room operators to efficiently monitor the movement of objects whilst remaining hands-free to control other cameras. With a right click of a mouse, operators can programme a camera to lock onto and auto-track a specific object. It does so with the help of deep learning video analytics which detects and classifies people and vehicles. The video analytics is supported by AI algorithms unique to Hanwha Techwin.  During their life cycle, most PTZ cameras are likely to be expected to ‘pan and tilt’ many thousands of times and it is not unknown for positioning errors to occur. Wisenet PTZ PLUS cameras, which have a pre-set accuracy of ±0.1˚, are able to detect if they are not precisely aimed at the specified field of view and will move within one second to the correct position. Other key features Built-in wipers remove rain, sleet or snow and then activate a heater on the lens to dry any residual water. An extended tilt range of up to 110⁰ ensures that objects positioned above the cameras can be seen. Improvements in manual control PTZ functionality makes it much easier for operators to manually zoom to see close up detail of target objects and track their movement. A focus save function, which can be applied to 32 pre-defined areas, ensures that regardless of the lighting conditions, a camera is able to rapidly come into focus when it is moved to a new position. Installer friendly Compact and approximately 65% lighter than most PTZ domes, the camera-mount installed Wisenet X PTZ PLUS cameras can be quickly and easily deployed, requiring engineers during a first fix to just ‘match 3 points and twist’. This conveniently enables them to tighten screws without having to hold onto the camera. Unlike conventional PTZ cameras which require up to 5 separate cables, the Wisenet X PTZ PLUS only needs a single RJ45 cable to operate and this is installed with a flexible bush to ensure the camera is waterproof. Wisenet PTZ PLUS cameras The new Wisenet PTZ PLUS cameras are as follows: -              Wisenet XNP-9300RW: 4K 30x optical zoom PTZ camera -              Wisenet XNP-8300RW: 6MP 30x optical zoom PTZ camera -              Wisenet XNP-6400RW: 2MP 40x optical zoom PTZ camera “Setting a new standard is a phrase which is often used when products are launched, but I believe it can genuinely be applied to these new cameras,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “Our highly talented design, development and manufacturing teams have certainly put their expertise to very good use and in doing so, have raised the bar in terms of providing users with the ability to closely monitor and track any suspicious activity or incident.”

Hanwha Techwin’s position as global in video surveillance has been reaffirmed with the announcement that Wisenet7, the company’s next generation proprietary camera chipset, has achieved UL Cybersecurity Assurance Program (UL CAP) certification. With cybersecurity being a top priority for the electronic security industry, the certification enables Hanwha Techwin to validate that its latest generation of Wisenet cameras are equipped with the highest possible levels of protection from the activities of cyber criminals.    UL CAP is a certification program run by UL, a company which has been a global in safety science for over 100 years. The program assesses potential cybersecurity issues and the level of risk from hackers in respect of network-connectable hardware devices and software. UL CAP certification With the support of the certification, Hanwha Techwin is able to provide peace of mind to system integrators and end-users Hanwha Techwin is among only a handful of manufacturers within the video surveillance industry that have so far achieved the UL CAP certification for their products and is the only one within Korea to have done so. With the support of the certification, Hanwha Techwin is able to provide peace of mind to system integrators and end-users seeking to comply with GDPR by ensuring confidential data cannot be accessed, copied or tampered with. Although it usually takes in the region of 8 to 10 months, Hanwha Techwin was able to complete the certification process within 3 months as the company’s in-house Security Computer Engineering Response Team (S-CERT) had already been working on addressing any potential security vulnerabilities in Wisenet hardware and software. This ensured that Wisenet7 was able to meet all of UL’s thorough evaluation criteria, such as penetration test, access control and user authentication, encryption and software updates. Wisenet7 chipset Wisenet7 chipset boasts a list of technologies which are designed to improve cybersecurity credentials The ground-breaking Wisenet7 chipset boasts an impressive list of technologies which are designed to significantly improve the cybersecurity credentials of Wisenet cameras. These include: Secure Boot Verification: This provides an extra layer of security by sandboxing different elements of a camera’s operating system, which means they are in a protected space. A full boot is completed before there is communication with any other part of the system. This prevents interruption to the boot process which could be exploited by a hacker. Secure OS: Wisenet7 uses a separate secure operating system (OS) for encryption and decryption, as well as for verifying that apps have not been modified or are not forgeries. A separate Linux based API is needed to access the Secure OS, without which there is no way to make any changes from the outside of a camera. Security features By enforcing restricted and secure access to the UART port, Wisenet7 allows the debugging process to be safely completed Anti-Hardware Clone: This functionality prevents Wisenet7 from being cloned. In addition to protecting intellectual property, this ensures that a Wisenet7 chipset with a Hanwha Techwin label is a genuine copy and removes the risk of a cloned device which may contain malicious software being used to steal sensitive data, such as passwords. Secure JTAG: JTAG ports are hardware interfaces which are used to programme, test and debug devices. Cyber criminals can gain low level control of a camera via a JTAG port and perhaps replace firmware with a malicious version. Wisenet7 prevents this from happening as it secures JTAG ports via a key-based authentication mechanism to which only authorised personnel working for Hanwha Techwin have access. Secure UART: UART ports are serial interfaces typically used for debugging cameras. They allow administrator access to a camera and are therefore a target for hackers attempting to access sensitive information, such as password keys. By enforcing restricted and secure access to the UART port, Wisenet7 allows the debugging process to be safely completed without opening the door to cyber criminals. Global provider in cybersecurity Cybersecurity is essential for network video surveillance products as it allows us to provide end-users with confidence" “Cybersecurity is essential for network video surveillance products as it allows us to provide end-users with confidence in knowing that their confidential data will be kept safe from hackers,” said Uri Guterman, Head of Product & Marketing for Hanwha Techwin Europe. “Achieving UL CAP certification for Wisenet7 underscores our commitment to equip our next generation of cameras with innovative features that set a new standard for cybersecurity.” “The certification helps us maintain our position as a global leader in a number of different ways. In Europe, Middle East and US, for example, major projects which are subject to a tender process often stipulate that UL CAP certification is required. In the private sector, it is not unknown for sensitive facilities such as laboratories and banks to insist that a supplier should have the certification.” “As such, Wisenet7’s CAP certification enables us to more actively promote our cybersecurity features as one of Hanwha Techwin’s strengths.”
