Analogue Transmission - Expert commentary

HD over Coax provides cost-effective video surveillance upgrade
HD over Coax provides cost-effective video surveillance upgrade

According to IHS Market, it is estimated that there are over 60 million security cameras in the United States, and other reports say these cameras capture more than four billion hours of footage per week. Over the last decade, IP camera technology has dominated the conversation as it has provided users with a broad offering of enhanced image quality and features. With a large percentage of existing security systems relying on analogue, many end users looking for high definition (HD) video quality have been forced to take on a complete system overhaul. Infrastructure overhaul for HD video To make the switch, customers would need to change everything, from cameras to hardware to wiring– not to mention the lengthy installation process that would ensue. IP cameras also require higher Internet speeds and more cloud space. Whether constrained by budget, bandwidth or storage, many end users have been unable to adopt this new video surveillance method.Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike. By utilising the current Coaxial cables, this offering yields high definition video, while requiring minimal infrastructure changes and is an optimal surveillance choice for security customers. Plus, with new advancements and updates being made frequently to this technology, there is a solution for every security need. The enhanced alternative of HD over Coax has been warmly welcomed in the security industry, thanks to its simple solutions and ever-evolving features. Many new analogue HD cameras are “plug and play,” able to connect directly to existing Coaxial cables. This eliminates the need for a complete system change, creating cost-savings for the end user and an enhanced video quality offering. Easy solutions for HD video As a result, integrators can cost-effectively upgrade their customer’s surveillance solution while using their legacy infrastructure, making it an attractive option for end users and an easy sell for dealers. Latency in video is another common issue with network-based camera systems, where even the slightest delay in video surveillance can hinder security response HD over Coax cameras themselves are always expanding and evolving to meet a wide array of security needs. With the introduction of fisheye and multi-sensor cameras, users now have a multitude of coverage options, not to mention the introduction of 4K bringing resolution options to the same level as IP. Some newer technologies are even touting 4K cameras paired with 4K digital video recorders (DVRs) made specifically for analogue systems. Longer cables grant transmission for up to 1600 feet, double the distance of standard analogue solutions, and triple that of IP systems. This single cable is able to transmit both HD video and audio. Recently, broadcast quality audio over Coax has become available in limited models, a substantial improvement over older analogue technology, which was unable to transmit audio. Stopping video delay Latency in video is another common issue with network-based camera systems. Even the slightest delay in video surveillance can hinder security response. IP cameras are forced to compress and packetise their video for transmission. The outcome of this is a reduced number of images per video, which in turn causes delay. HD over Coax on the other hand, delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity. Additionally, the point-to-point transmission delivers uncompressed video free of lag. Another touted benefit is that, unlike IP networked cameras, analogue systems provide a more secure video transmission. With so much sensitive information housed on a businesses’ network, adding another point of network access through an IP camera can create concerns for cyber security risks. HD over Coax delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity Preventing network hacking With HD over Coax, the physical connections between the camera and DVR prevent network hacking. By keeping the video surveillance system offline, security professionals are able to direct their attention to the physical threats at hand, rather than having to focus on deterring cyber security risks. One of the primary difficulties of deploying HD video solutions is the fact that many older systems utilise a wide variety of HD standards and platforms. To make matters more complicated, after HD over Coax was brought to market, manufacturers raced to create their own version of this technology. Today, the most popular proprietary standards are HD-CVI, HD-TVI and AHD. However, integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible.Integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible Diversifying surveillance through one DVR To combat these issues, manufacturers have introduced products with more flexibility to their portfolios. One example of this is the penta-brid DVR which grants the ability to seamlessly integrate multiple technologies deployed across one application. This means that systems with diverse camera brands and technologies, such as a mix of HD-CVI, HD-TVI, AHD, analogue or IP, can be connected through one DVR. For many end users with legacy analogue systems, penta-brid DVRs give them greater freedom to choose between a variety of solutions, rather than being limited to one option. With video resolution increasing, the space needed to store the footage is similarly rising. Penta-brid technology has been able to adapt to these evolving needs, giving users ample storage space to house the HD and 4K surveillance video with some of the newest models including H.265 compression.  HD casino surveillance made simple For casinos, HD images are critical for identifying unauthorised personnel and unlawful behaviours to create a safe environment for guests and staff While HD over Coax is beneficial to many end users and integrators, those in the casino and hospitality markets find it crucial. With a combination of high profile guests, large amounts of cash on hand, constant crowds and strict industry regulations, reliable video surveillance is a must. Deploying new IP systems comes at a stiff price. When looking to upgrade their video surveillance, casinos must also be mindful of the installation process. When moving to an IP-based system, ripping out old wires and replacing them with new is the standard practice. This practice can be both disruptive and costly, not to mention gaming regulations require casino activities be monitored at all times so a complete system shutdown would result in revenue loss. This cost can be hard to justify, especially when the current legacy analogue system remains in working condition with only the lower image resolution to date it. For these scenarios, the most cost-effective option is to leverage the legacy infrastructure, replace the existing cameras with new devices, and reap the benefits that HD video has to offer without any lapse in security. For casinos, HD images are critical for identifying unauthorised personnel and unlawful behaviours to create a safe environment for guests and staff. HD over Coax cameras now offer the same resolution as IP cameras with a plug and play approach, that cuts down on expense without sacrificing quality. For businesses and applications that are unable to adopt IP technology, whether it be cost or time prohibitive, HD over Coax now features most of the same benefits IP has to offer without breaking the bank. By providing clear images in real time, maximising existing infrastructure, and affording cyber security benefits, HD over Coax provides an attractive solution for many end users and integrators.

How to use video analytics and metadata to prevent terrorist attacks
How to use video analytics and metadata to prevent terrorist attacks

Today ‘terrorism’ has become a word we use and hear every day. The goal of terrorism is a media product - information delivered to nearly every house in the world. So, the weapon of terrorism is information. Therefore, the way we defend and prevent terrorism must also be based on intelligent processing of information - and an early awareness of potential threats and effective preventive action may eliminate most attacks. Video analytics, automated surveillance and AI decision-making are going to change the rules of the struggle between civilians and terrorists by making attempted attacks predictable, senseless and silent. In this article, we will evaluate to what extent technology can investigate and prevent terror crimes considering the latest technology innovations. Civilian feedback helps terrorists to accomplish mission In order to achieve their main goal - loud media response - terrorists and those who order the attacks use unpredictable tactics and the element of surprise; so that after every attack, the media discusses for months the circumstances and their insanity. Unfortunately, each time it happens our society seems to be unprepared. As the media environment grows, terror attacks attract more attention, and the feedback of civilians actually helps the terrorists to accomplish their mission. Features of terrorist crimes Counter-terrorist specialists highlight, among the others, the following inherent symptoms of terror crimes: Unpredictability Public visibility Enormous social resonance The question is: Are there technological solutions that could treat these symptoms at a low level? Crime investigations are based on objective indisputable facts that can be used against suspects in a court. The facts are: Video surveillance materials Facial recognition and ANPR metadata Audio data (e.g. phone calls) Internet communication logs Other registered human actions Metadata sources and analytical systems To be able to collect and analyse that data, it needs to be in a data format that an analytical system will be able to process. Metadata can be generated by processing data of the above sources. Metadata can be stored in relational databases or in blockchain, so it can be a reference for an analytical system or law enforcement structures. Automatic or semi-automatic investigation can be based on crime scenarios, behaviour patterns, forensic search, face and vehicle recognition and synoptical search Aggregation of metadata sources could be constructive because it would significantly increase metadata availability for analytical systems and will improve metadata quality. This would surely require replacement of most of existing security systems and standardisation of new systems so to ensure maximal compatibility of metadata sources and analytical systems. Offline video analytics As these improvements are difficult to develop and implement globally, replacement solutions are being offered currently in the security market. One of them is the concept of offline video analytics, which generates and analyses metadata from any video source. Video sources may vary from ‘old school’ analogue cameras to high-resolution IP cameras recorded in any digital format. Quality of the metadata generated from offline analytical systems is almost unaffected. High quality metadata can be analysed and investigated automatically or semi-automatically for violations, crimes and terror activity. Automatic or semi-automatic investigation can be based on crime scenarios, behaviour patterns, forensic search, face and vehicle recognition and synoptical search. Fast and effective investigation of terror activities may prevent attacks and also can reduce the number of active terrorists. Human head microvibration is linked with the vestibular-emotional reflex (VER) and depends on emotional status Deep learning and neural network technologies However, realtime crime and terror prevention requires instant metadata generation and analysis. The investigation instruments mentioned above would not be of the same efficiency. Firstly, processing capabilities of analytical system must be very high because the system should be able to record data, generate metadata and analyse it at the same time in realtime conditions. Currently the most powerful server processors can run only tens of detectors so it becomes very costly. That is why these kinds of solutions are only used in critical infrastructure. However, if they were used widely they would dramatically reduce the number of criminal and terror activities. Deep learning and neural network technologies (so-called artificial intelligence - AI) are coming to the security market to replace classic video analytics. These systems are not yet much more efficient hardware-wise; however, they have greater potential and they are cheaper. Behaviour patterns, actions, sounds, speech, faces, car number plates and many other metadata types can be identified and collected and analysed by AI in realtime. Security surveillance and analytical AI systems could know about each person’s life and social background so it could make automatic decisions Emotion recognition/vibraimage technology Emotion recognition (or vibraimage) technology measures micromovements (vibration) of a person by processing video from a camera or any video source. Human head microvibration is linked with the vestibular-emotional reflex (VER) and depends on emotional status. Vibraimage systems detect human emotions by the control of 3D head-neck movements accumulated in several frames of video processing. Vibraimage is a system that detects all human emotions. Blockchain can bring awareness of different views. Imagine if the security surveillance and analytical AI system knew about each person’s life and social background so it could make automatic decisions to give more surveillance priority to those who potentially could take negative action. Although security equipment is becoming more affordable, the budgeting of security systems at a government and private level is still the biggest problem. As the global population is growing and migration is getting more intense, public and private security is becoming a natural need. Meanwhile, the security market is ready to deliver solutions that can instantly investigate and even prevent terror activities.

Are your surveillance monitors prepared for the latest video technology developments?
Are your surveillance monitors prepared for the latest video technology developments?

Everybody has been hooked on the discussions about Analogue HD or IP systems, but shouldn’t we really be thinking about WiFi and 5G connectivity, removing the need for expensive cabling? Are wireless networks secure enough? What is the potential range? Even the basic question about whether or not the network is capable of transferring the huge (and growing) amount of data required for High Res Video, which will soon be quadrupled with the advent of 4K and higher resolutions. The future of video surveillance monitors We have seen a massive uptake in 4K monitors in the security industry. While they have been relatively common in the consumer market, they are only now beginning to really take off in the CCTV market, and the advances in Analogue HD and IP technology mean that 4K is no longer the limited application technology it was just a few years ago. Relatively easy and inexpensive access to huge amounts of storage space, either on physical storage servers or in the cloud, both of which have their own positives and negatives, have really helped with the adoption of 4K. Having said that the consensus seems to be, at least where displays are concerned, there is very little need for any higher resolution. So, where next for monitors in CCTV? 8K monitors are present, but are currently prohibitively expensive, and content is in short supply (although the Japanese want to broadcast the Tokyo Olympics in 8K in 2020). Do we really need 8K and higher displays in the security industry? In my own opinion, not for anything smaller than 100-150+ inches, as the pictures displayed on a 4K resolution monitor are photo realistic without pixilation on anything I’ve seen in that range of sizes. The consensus seems to be, at least where displays are concerned, there is very little need for any higher resolution Yes, users many want ultra-high resolution video recording in order to capture every minute detail, but I feel there is absolutely no practical application for anything more than 4K displays below around 120”, just as I feel there is no practical application for 4K resolution below 24”. The higher resolution camera images can be zoomed in and viewed perfectly well on FHD and 4K monitors. That means there has to be development in other areas. Developments in WiFi and 5G What we have started to see entering the market are Analogue HD and IP RJ45 native input monitors. Whilst you would be forgiven for thinking they are very similar, there are in fact some huge differences. The IP monitors are essentially like All-In-One Android based computers, capable of running various versions of popular VMS software and some with the option to save to onboard memory or external drives and memory cards. These are becoming very popular with new smaller (8-16 camera) IP installs as they basically remove the need for an NVR or dedicated storage server. Developments in the area of WiFi and 5G connectivity are showing great promise of being capable of transferring the amount of data generated meaning the next step in this market would maybe be to incorporate wireless connectivity in the IP monitor and camera setup. This brings its own issues with data security and network reliability, but for small retail or commercial systems where the data isn’t sensitive it represents a very viable option, doing away with both expensive installation of cabling and the need for an NVR. Larger systems would in all likelihood be unable to cope with the sheer amount of data required to be transmitted over the network, and the limited range of current wireless technologies would be incompatible with the scale of such installs, so hard wiring will still be the best option for these for the foreseeable future. There will be a decline in the physical display market as more development goes into Augmented and Virtual Reality Analogue HD options Analogue HD options have come a long way in a quite short time, with the latest developments able to support over 4MP (2K resolution), and 4K almost here. This has meant that for older legacy installations the systems can be upgraded with newer AHD/TVI/CVI cameras and monitors while using existing cabling. The main benefit of the monitors with native AHD/TVI/CVI loopthrough connections is their ability to work as a spot monitor a long distance from the DVR/NVR. While co-axial systems seem to be gradually reducing in number there will still be older systems in place that want to take advantage of the benefits of co-axial technology, including network security and transmission range. Analogue technologies will eventually become obsolete, but there is still much to recommend them for the next few years. Analogue technologies will eventually become obsolete, but there is still much to recommend them for the next few years Another more niche development is the D2IP monitor, which instead of having IP input has HDMI input and IP output, sending all activity on the screen to the NVR. This is mainly a defence against corporate espionage, fraud and other sensitive actions. While this has limited application those who do need it find it a very useful technology, but it’s very unlikely to become mainstream in the near future. Augmented Reality and Virtual Reality Does the monitor industry as a whole have a future? In the longer term (decades rather than years) there will definitely be a decline in the physical display market as more and more development goes into AR (Augmented Reality or Mixed Reality depending on who’s definition you want to take) and VR (Virtual Reality). Currently AR is limited to devices such as smartphones (think Pokémon Go) and eyewear, such as the ill-fated Google Glass, but in the future, I think we’ll all have optical implants (who doesn’t want to be The Terminator or RoboCop?), allowing us to see whatever we decide we want to as an overlay on the world around us, like a high-tech HUD (Heads Up Display). VR on the other hand is fully immersive, and for playback or monitoring of camera feeds would provide a great solution, but lacks the ability to be truly useful in the outside world the way that AR could be. Something not directly related to the monitor industry, but which has a huge effect on the entire security industry is also the one thing I feel a lot of us have been oblivious to is the introduction of quantum computers, which we really need to get our heads around in the medium to long term. Most current encryption technology will be rendered useless overnight when quantum computers become more widespread. So, where does that leave us? Who will be the most vulnerable? What can we do now to mitigate the potential upheaval? All I can say for sure is that smarter people than me need to be working on that, alongside the development of the quantum computer itself. Newer methods of encryption are going to be needed to deal with the massive jump in processing power that comes with quantum. I’m not saying it will happen this year, but it is definitely on the way and something to be planned for.

Latest Bosch Security Systems news

Bosch releases a new version of AIoT video software solution supporting safe social distancing
Bosch releases a new version of AIoT video software solution supporting safe social distancing

The latest release of ‘Intelligent Insights’ from Bosch offers a software widget update that supports safe social distancing. Intelligent Insights is an ‘AIoT’ video software solution – which combines the connectivity of physical products with the application of artificial intelligence (AI) – that gives customers the power to predict based on live and historical data. Intelligent Insights taps data from Bosch video cameras with built-in AI and pulls it into a single dashboard to support informed decision-making before a potential situation occurs. Minimising coronavirus spread One of the most notable changes caused by the current pandemic is social distancing. Maintaining a precise distance and upholding a maximum threshold of people in gathering areas such as workplaces, shopping centers, and train stations has become critical to minimise coronavirus spread (COVID-19). In light of the challenges imposed by this situation, Intelligent Insights supports social distancing regulations with its latest software widget update. Intelligent Insights supports social distancing regulations with its latest software widget update The new Area fill level traffic light widget offers an intuitive graphical interface that helps users comply with social distancing regulations. The widget visualises the current and maximum number of people allowed in a particular area at a specific time. It illustrates three different states – normal, serious, and critical – as green, yellow, or red, along with corresponding info text, so the user instantly knows when to take action. Traffic light widget Users can opt to live stream the Area fill level traffic light widget on a monitor at an entrance to a supermarket or grocery store, for example, to inform customers whether they may enter the store. When a threshold is reached, the widget can activate and trigger a connected device that will inform visitors with a public announcement, simple alert, or message displayed on a monitor. Intelligent Insights uses built-in AI from Bosch cameras to interpret video images and captures camera metadata from situations involving moving objects, people counting, and crowd detection. The software tool then collects, aggregates, and displays this information using a series of pre-defined widgets enabling users to visualise and evaluate a complete scene from a simple overview screen. Intelligence beyond security Users can select the needed widgets to provide the required information to help predict unwanted situations The dashboard enables users to quickly understand what they see, which helps them respond before a potential situation occurs and delivers business intelligence beyond security. For detailed post-analysis and to help users adjust and alter future actions, Intelligent Insights offers a report function. Intelligent Insights comes with a series of intuitive dashboard widgets that enable users to evaluate a complete scene to support security, safety, and well-being in varying applications. Depending on the application, users can select the needed widgets to provide the required information to help predict unwanted situations or uncover new opportunities. Object positioning widget Area fill level, Occupancy counting, and Crowd detection offer the ability to monitor and detect crowds accurately and count individuals and objects. The user can specify the desired occupancy rate of an area by determining the maximum number of people allowed to be in that area within a given time. Intelligent Insights also offers Object counting and People counting to count objects or people accurately such as when entering or leaving a building. These widgets help identify peak and low times on specific days or over an extended period. Intelligent Insights uses only anonymous data from cameras, ensuring people’s privacy is protected at all times. With the Object positioning widget, users can get a real-time overview of all objects moving in a specific area. Based on their GPS position, which can be determined by cameras that feature built-in AI, the objects are plotted onto a map and classified with icons. Video management system Intelligent Insights, an AIoT video software solution from Bosch, supports social distancing regulations, helps customers respond before a potential situation occurs, and delivers business intelligence beyond security. Intelligent Insights is not only a powerful standalone software package but also designed for seamless integration with other software solutions like the video management system of Bosch (BVMS).

Bosch secures Granarolo plant at Soliera with their Intelligent Video Analytics system
Bosch secures Granarolo plant at Soliera with their Intelligent Video Analytics system

Situated near the picturesque small town of Soliera in northern Italy, the dairy plant of Italian food company Granarolo is anything but small: More than 600 farmers, 70 trucks for the collection of milk and 720 vehicles handle 850,000 tons of milk every year. Its dairy products such as milk, yogurt, ice cream, cheese, and lately also ham and pasta, supply several million Italian families every day. The plant’s huge production capacity is reflected in the size of the perimeter: The Soliera facility stretches out over 45,000 square metres. Furthermore, it is located near a wooded land which is important when it comes to designing a security system aimed at protecting the plant against intrusion. Video surveillance system Granarolo wanted to replace an old analogue video surveillance system by a digital one as its security challenges exceeded the limits of the old installation. The project posed several challenges. The most significant being the vast area of the factory itself, as well as the location of the perimeter near an area that can only be poorly overseen. Since the factory is located in a heavily wooded area, building an appropriate video security system is more challenging because it needs to be safeguarded against false alarms, triggered by ever-changing lights, shadows and the constant movement of trees and plants. Tackling these challenges, Naples-based Bosch partner Gruppo Sirio worked out the modernisation of the plant’s security system, with Bosch cameras featuring built-in Intelligent Video Analytics (IVA) at the heart of the system. Detecting suspicious objects Bosch provided a video surveillance system with 48 cameras of the Dinion series With the help of the security cameras’ integrated video analytics, virtual lines were drawn around the area to be protected against intrusion. When these lines are crossed by intruders, the programmed rules automatically generate alarms, alerting on-site security personnel to intervene. Whether the cameras are tasked with detecting suspicious objects or unusual movements in daylight or night-time, constant surveillance with a special focus on sensitive areas ensures security. In total, Bosch provided a video surveillance system with 48 cameras of the Dinion series. The system, which is managed on one central platform, is completely autonomous and entirely separate from any other system or network in the plant. This ensures maximum security even in the event of potential failures of other systems on site. Perimeter protection solution As a result of the modernisation process, Granarolo can now rely on a system specifically designed for its needs. The newly established, digital video surveillance and perimeter protection solution supports the security personnel in maintaining maximum levels of security through the entire area. It also guarantees that food safety standards in the protected facility are guarded against outside influences. Ultimately, the system allows the staff to fully focus on keeping the production running at all times, thereby contributing to secure the sensitive chain of the Italian food supply against interruptions.

Bosch Security Systems unveil version 4.8 of its Building Integration System to enable a safe and contactless access control environment
Bosch Security Systems unveil version 4.8 of its Building Integration System to enable a safe and contactless access control environment

Bosch Security Systems has released version 4.8 of its Building Integration System (BIS) which offers safe, touchless access control solutions to curb the spread of viruses like Covid-19. Secure access control solution BIS 4.8 supports biometric and mobile device authentication and provides building managers enhanced integration of fire panels and intrusion panels to ensure the security of buildings. The global COVID-19 pandemic has caused building operators to rethink their access control solutions In light of the global COVID-19 (coronavirus) pandemic, building operators need to rethink their access control solutions. Instead of systems that require physical touch and thereby increase the risk of virus transmission, contactless solutions that still meet the highest security guidelines are preferable. BIS 4.8, Building Integration System In response to these requirements, BIS 4.8 expands on the trusted features and benefits of version 4.7 to now work with three different touchless solutions that safeguard personal health: Face recognition - BIS 4.8 has been redesigned to work with the face recognition solution from Idemia. The face recognition device obtains a biometric scan from a safe distance and matches facial features with credentials in an encrypted database. Doors and gates open via the BIS Access Engine and the Bosch Access Modular Controller (AMC2). Touchless fingerprint readers - Integrated with Idemia’s Morphowave reader, BIS 4.8 controls access via a touchless fingerprint scan. A simple wave of the hand in front of the touchless sensor triggers a 3D scan of four fingers. Access rights are confirmed within less than one second by the system's fingerprint database for a clean and highly secure solution. Access via mobile phones - In conjunction with the mobile access control solutions from STid and HID, BIS 4.8 allows users to use their mobile phone instead of a card for access at the secure reader. For STid’s Mobile ID, the method requires a STid reader, while a Bosch Lectus secure reader works with HID’s Mobile Access solution. Users only need to install an app to verify access rights and use the safe, wireless technology. Aside from facilitating contactless access, all three solutions are also intuitive, quick and convenient compared to keycards and similar methods as there is no need to carry an access card or remember a password in order to gain entry to a building or area. Seamless fire and intrusion panel integration Combining BIS 4.8 with Bosch B and G Series intrusion panels unlock a new level of convenience Combining BIS 4.8 with Bosch B and G Series intrusion panels or MAP 5000 panels unlocks a new level of convenience. Users require only one authorisation badge to control two systems. Disarming areas of the intrusion system and granting access can be realised with the same badge on the same reader, without entering a PIN code for easy, one-step authorisation. Improved flexibility and efficiency With the introduction of version 4.8, BIS continues to unify the management of multiple security and safety domains and maximise flexibility for key customer requirements. New features include: Integration of the latest Bosch Avenar 2000 and 8000 fire panels and peripherals, along with command and control via BIS, with devices and status shown on maps, and events managed more intuitively via an alarm list. User authorisation for Bosch B and G Series intrusion panels are managed directly within BIS for up to 2,000 users on as many as 25 intrusion panels, instead of handling authorisations separately on each of the 25 panels. Central overview of all existing access and B and G Series intrusion authorisations for the complete installation within one system. With these updates, BIS 4.8 helps operators meet the health and safety demands of the new reality without compromising on functionality and security. As a centralised platform for operational building management, the new version of BIS offers greater convenience, flexibility, and efficiency.

Related white papers

Security investments retailers should consider for their 2021 budget
