IP Dome Cameras

VIVOTEK’s IP9191-HT is a professional H.265 box network camera providing true 3840x2160 resolution at 30 fps. With ultra HD resolution, 30 frames per second, and VIVOTEK’s SNV and WDR Pro technologies, this camera is capable of delivering clear, detailed images in a variety of challenging applications such as city surveillance, transportation and industrial monitoring. VIVOTEK's in-house algorithm brings video compression to next level. With VIVOTEK’s Smart Stream III technology, the IP9191-HT is capable of delivering excellent images while keeping bandwidth and storage consumption at extremely low levels, even smaller than typical 2-Megapixel image size. The IP9191-HT is further equipped with an i-CS (intelligent-CS mount) lens with LSC (Lens Shading Correction) and LDC (Lens Distortion Correction) calibration functions to obtain even better images. When combined with remote focus system, these features enable installers to adjust zoom/focus remotely. These function-rich combinations make the IP9191-HT suitable for a wide range of video surveillance applications. When housed inside the AE Series Enclosures, the IP9191-HT is excellent for long-range outdoor applications. Furthermore, when equipped with the 12-50mm AL-248 lens, the IP9191-HT is an ideal camera that could deliver exceptional images even from surveillance targets that are over 100 meters away.

The Contera Bullet outdoor-ready megapixel camera features 1080p and 5-megapixel (MP) resolution for optimum performance.  The Contera Bullet combines a day/night mechanical IR cut filter with an integrated motorised 2.7–12mm varifocal remote focus and zoom precision iris (P-iris) lens.  Regardless of the time of day, the Contera Bullet is prepared for any lighting condition.  For applications with poor lighting conditions, Enhanced WDR™ (wide dynamic range) at 120dB provides the best visual balance to shaded and bright light conditions.  For clear colour images in low-light, NightView™ offers strong low-light sensitivity for capturing details in extremely poor-lit scenes, and is further enhanced by built-in Smart IR LED illumination that automatically adjusts output in response to the distance of an object in view to prevent over-exposure when the object is very close to the camera.  The Contera Bullet is ONVIF (Open Network Video Interface Forum) Profile S and G compliant, providing interoperability between network video products regardless of manufacturer.

MOBOTIX’s AllroundDual camera balances flexibility and features continuing the trend of modular system design. The MOBOTIX M16 AllroundDual features exchangeable image sensors for day, night and thermal use along with flash memory, microphone, speaker, PIR and optional feature modules. Housed within a weatherproof (IP66) chassis along with a comprehensive set of built-in cyber security controls, the camera offers powerful new application and integration options for both system integrators and end customers. The M16 also proves that standards and innovation can truly co-exist as the MOBOTIX video surveillance camera that brings together the MxPEG video codec specifically developed for security applications and the H.264 industry standard within an ONVIF-ready camera system. For added flexibility, the built-in RTSP/Multicast capability allows simultaneous streaming of MxPEG, M-JPEG and H.264 video to multiple clients without performance loss. Benefiting from an upgraded processor and software, the M16 delivers the highest frame rate of any MOBOTIX camera along with intelligent 3D motion detection and more capacity for on-board software applications. The M16, in common with all MOBOTIX models, benefits from regular software updates to ensure reliability while adding additional feature enhancements that make the M16 one of the most intelligent yet flexible camera systems on the market.

The Avigilon AI Appliance adds patented Avigilon self-learning video analytics and Avigilon Appearance Search technology to almost any IP camera. When connected to Avigilon Control Center (ACC) software, customers can evolve legacy camera systems into powerful AI solutions, with automatic alerts of potentially critical events and the ability to search for and locate a person or vehicle of interest across an entire site.  Engineered for high performance, capacity and resiliency, the AI Appliance will be offered in two models and features leading CPU and GPU hardware that simultaneously support Avigilon video analytics and Avigilon Appearance Search technology for up to sixty 2 MP resolution cameras.

The Evolution 180 Outdoor Camera is built upon Oncam’s expertise and heritage on 360-degree technology. It is specifically designed for applications that require a dewarped panoramic view of an outdoor scene, without blind spots, from a single sensor camera.  The 12MP high-resolution sensor and the built-in 3D dewarped panoramic video provides industry leading Panoramic+ views. The true day/night functionality allows images to be produced in all lighting conditions, including additional IR lighting. The camera is IP66, IP67, IP68, IP69K and IK10+ rated, making it a robust design.  Its versatile enclosure enables wall and pendant mounting, while the integrated adjustable mounting allows for an angling of up to 45°. When angled, Oncam’s Angle Compensation Technology (ACT) corrects the view, straightening vertical lines in the scene.

The Contera® Micro Bullet outdoor-ready megapixel camera features 1080p and 5-megapixel (MP) resolution for optimum performance.  The Contera Micro Bullet combines a day/night mechanical IR cut filter with an integrated 3.6mm lens.  Regardless of the time of day, the Contera Micro Bullet is prepared for any lighting condition. For applications with poor lighting conditions, Enhanced WDR™ (wide dynamic range) at 120dB provides the best visual balance to shaded and bright light conditions.  For clear colour images in low-light, NightView™ offers strong low-light sensitivity for capturing details in extremely poor-lit scenes, and is further enhanced by built-in Smart IR LED illumination that automatically adjusts output in response to the distance of an object in view to prevent over-exposure when the object is very close to the camera.  The Contera Micro Bullet is ONVIF (Open Network Video Interface Forum) Profile S compliant, providing interoperability between network video products regardless of manufacturer.

System OverviewExperience superior 5MP video and the simplicity of reusing existing coaxial infrastructure with HDCVI. The Lite series 5MP HDCVI camera features a compact design and offers a high quality image with rich details at a friendly price. It offers various vari-focal/fixed lens models with a multi-language OSD and HD/SD switchable output. Its structural flexibility and high cost-performance makes the camera an ideal choice for SMB solutions. Functions Broadcast-quality audioAudio information is used as supplementary evidence in video surveillance applications. The HDCVI camera supports audio signal transmission over coaxial cable. In addition, it adopts unique audio processing and transmission technology that best restores source audio and eliminates noise, guaranteeing the quality and effectiveness of collected audio information. 4 Signals over 1 coaxial cableHDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio*, data and power. Dual-way data transmission allows the HDCVI camera to interact with the HCVR, such as sending control signal or triggering alarm. Moreover, HDCVI technology supports PoC for construction flexibility. * Audio input is available for some models of HDCVI cameras. Long distance transmissionHDCVI technology guarantees long-distance and real-time transmission without any loss. It supports up to 700m for 5MP HD video via coaxial cable, and up to 300m via UTP cable. **Actual results verified by real-scene testing in Dahua's test laboratory. SimplicityHDCVI technology inherits the born feature of simplicity from traditional analogue surveillance system, making itself a best choice for investment protection. HDCVI system can seamlessly upgrade the traditional analogue system without replacing existing coaxial cabling. The plug and play approach enables full HD video surveillance without the hassle of configuring a network. Smart IRThe camera is designed with array LED IR illumination for best lowlight performance. Smart IR is a technology to ensure brightness uniformity in B/W image under low illumination. Dahua’s unique Smart IR adjusts to the intensity of camera's infrared LEDs to compensate for the distance of an object, and prevents IR LEDs from overexposing images as the object come closer to the camera. HD/SD switchableThe camera supports switchable HDCVI high definition video output and CVBS standard definition video output. The two formats can be switched over through OSD menu or by PFM820 (UTC controller). This feature makes the camera to be compatible with both HCVRs and existing analogue DVRs and also facilitates debugging through analog testers. Multi-language OSDOSD menu provides multiple image adjustments and function settings to meet the requirements of different monitoring scenes. The OSD menu includes configurations such as backlight mode, day/night, white balance, privacy mask and motion detect. The camera supports 11 languages for OSD menu, namely, Chinese, English, French, German, Spanish, Portuguese, Italian, Japanese, Korean, Russian and Polish. ProtectionThe camera's outstanding reliability is unsurpassed due to its rugged design. The camera is protected against water and dust with IP67 ranking, making it suitable for indoor or outdoor environments. With working temperature range of -40 °C to +60 °C (-40 °F to +140 °F), the camera is designed for extreme temperature environments. Supporting ±30% input voltage tolerance, this camera suits even the most unstable power supply conditions. Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning.

Seagate manufactures hard drives that specifically address the needs of the hyperscale storage market. As the flagship of the Seagate® X class, the Exos™ X12 enterprise hard drive is the highest-capacity hard drive in the fleet.  Scales to meet your growing capacity needs Seagate Exos X12 enterprise hard drives offer the highest rack space efficiency — up to 10 PB of data in a single 42U rack. Enhanced caching makes it perfect for Big Data applications, providing the fastest hard drive data transfers in the datasphere. Hyperscale SATA models are tuned for large data transfers, providing low latency. You can easily customise your bulk storage requirements with innovative technology advancements (PowerBalance™, PowerChoice™ and RAID Rebuild®). Exos X12 drives help provide low data centre TCO, and are architected to offer low power and weight. Simplified infrastructure management is possible with FastFormat™ advanced format feature (4Kn and 512e). Advanced Write Caching helps ensure rapid response rates with a 20% boost in random write performance.  Innovative helium design The Exos X12 hard drive is built on a rock-solid sealed-drive design. A wrought-aluminium base and a helium sealed-drive design with no porosity and uniform density are designed with superior material and wide-weld design for a more robust, hermetically sealed-drive enclosure. Exos X12 hard drives incorporate digital environmental sensors for measuring pressure in the drive, helping to ensure high reliability, performance and quality.  Enhanced enterprise reliability, data protection and security Seagate is the industry leader in data-at-rest protection with the broadest offering of technologies to help ensure reliable, trusted products. Seagate Secure™ models provide hardware-based security to help protect data-at-rest. With Instant Secure Erase, drive retirement is safe, affordable, fast and easy. Seagate Secure models meet the NIST 800-88 media sanitisation specification and support the Trusted Computer Group (TCG) standard.  The X class Exos X12 hard drive is a proven, enterprise-class hard drive with maximum reliability backed by a 2.5 million hour MTBF.

In Mirasys VMS Version 8 particular attention has been paid to security and privacy. Also, pre-existing familiar product features such as audit trail and versatile material management and search functionality brings significant benefits, for example, for the new EU General Data Protection Regulation (GDPR) requirements. Mirasys V8.4 is also a foundation for totally new opportunities related to this; what comes to system management and usage reporting, for example. Functional effectiveness Mirasys VMS is quick and easy to install, and especially effective in networked, IP-based CCTV systems and their operational and management needs, such as centralised management and upgrading/updating of servers, drivers and client applications without requiring on-site travel to remote locations. User profiles are easy to create and change. Servers can be pre-installed and pre-configured before delivering to the deployment location.  The Mirasys VMS V8 modern Spotter for Windows user interface can be adapted to individual and specific needs and preferences and provides more visual space for videos without sacrificing any functionality. The new HTML5 (Hypertext Markup Language, Version 5) based user interface in V8.4 offers easy access to the Mirasys system from anywhere; PCs, tablets or smartphones. Integration with other systems Video management systems are also more and more frequently integrated with other systems such as building management or access control. Video feeds will in the future also often be a replacement for on-site visits or tours by personnel. This reduces operational costs for security and building maintenance. User interfaces Video surveillance camera features are consistently improving. Image quality can be exceptionally good compared to what it used to be only a few years ago. The newest cameras also require much less network bandwidth due to more effective encoding formats, such as H.265/HEVC (from 40% up to 60% of bandwidth and storage space savings, depending on the footage and device without any loss of quality, or increased quality at the same level with the H.264/AVC encoding) that many IP camera manufacturers have started to support. Individual servers can handle more simultaneously connected cameras than before, and the entire system no longer has an actual upper limit. Mirasys VMS V8 is the answer to the scalability and performance needs of new camera technologies from any manufacturer. Thus, the video management system can be designed freely using the best equipment for the customer-specific requirements, and can also support all future needs.  User-specific requirements As video management evolves, traditional command and control (monitoring) services also change. In addition to security monitoring, this will also involve monitoring other systems (building management, access control, fire alarms, or even manufacturing, logistics and operational systems or processes). More and more often these are done by a service provider, and not the organisation whose premises, systems or processes are monitored and/or managed. Further, systems today have more and more different types of users; and variation in user skills or access rights can be significant. This leads to individual, user-specific requirements for system access and use, while simultaneously requiring that the users must be able to access the system from different locations and using different devices. Versatile possibilities and efficiency of management For systems integrations and management, Mirasys VMS Version 8.4 brings new and more versatile possibilities with its new HTTP based Application Programming Interface (API). A particularly significant benefit is that the HTTP API allows also for automation of the system configuration and management. The new HTTP API provides modern REST-compliant (Representational State Transfer, or ”RESTful”) web services which allow requesting systems to access and manipulate textual representations of web resources using a uniform and predefined set of stateless operations from any platform (almost any operating system and practically any programming language). Version 8.4 also brings a new software licensing model that brings remarkable simplification, effectiveness and cost savings, because from V8.4 onwards every server no longer requires its own server-specific software license, but all the software and licence features and limits (such as number of cameras, number of servers, number of simultaneously logged in users or any other functions) can, in any size system, be managed through a single system-wide software licence controlled via the system’s Management servers. The new V8.4 licences are also no longer dependent on the server’s MAC (Media Access Control) address, but uses a multi-factor “License Protection Key” that remains valid even if the hardware system has to be changed (e.g., new or replacement NIC, Network Interface Card, or new or replacement graphics controller, etc).

Only Seagate has been making drives specifically for surveillance storage for ten years. SkyHawk™ is built to keep systems in the field longer and reduce the need for post-deployment support. Key Advantages ImagePerfect™ firmware ImagePerfect™ firmware supports 24×7 surveillance-optimized workloads tuned to record ~90% of the time and play back video footage the remaining 10%, and supports more cameras recording at higher resolutions than traditional drives. Workload rating Workload rating of 180TB/year allows SkyHawk to perform reliably in write-intensive surveillance systems—3× the workload rating of a desktop-class drive. NVR-ready design NVR-ready design allows drives to maintain performance in RAID and multi-drive systems, giving customers the flexibility to grow with the booming NVR market and scale their systems when more storage is needed. ATA streaming ATA streaming support sustains recordings from up to 64 HD cameras for smooth, uninterrupted footage. 2000 hours of storage Up to 10TB or over 2000 hours of HD video storage supports an increased number of cameras and helps to ensure longer data retention periods are met. One million hours MTBF 1M hours MTBF, 3-year limited warranty represents an improved total cost of ownership (TCO) with reduced maintenance costs. Low power consumption Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions. Ruggedised design Tarnish-resistant components help protect drive from environmental elements, increasing field reliability ImagePerfect firmware avoids dropped frames 180 TB Workload per year - true 24/7 operation Supports up to 64HD Cameras, 8+ Drive bays Rotational Vibration (RV) Sensors, RAID Compatible Optional Data Rescue Services 3 Year Warranty

Since 2011, the patented Dallmeier Panomera® multifocal sensor technology has provided comprehensive video protection for vast areas in many football stadiums, perimeters, airports and city areas all over the world. The new Panomera® series, the “Ultraline“, has exceptionally high effective resolution for these situations. Dallmeier presents the first model of the new series, the Panomera® S8 Ultraline, which delivers up to 190 megapixel at 30 fps.  The Panomera® concept has revolutionised video technology: with up to eight sensors in a single camera, it is possible to capture enormous distances in unprecedented resolution quality. With fewer cameras and considerably less expense for both infrastructure and management, the total cost of ownership of video solutions are reduced significantly. At the same time, customer specifications regarding pixel density and coverage can be satisfied very precisely.    Up to 26,000 sqm. coverage with one camera The first model of the new Ultraline series, the Ultraline S8, has an excellent dynamic range of 130 dB UWDR (effective) for an extreme Panomera® effect. This enables a resolution of 125 px/m up to a distance of 160, 104 or 82 m, enabling individuals to be recognised over the entire distance. Identification of persons (250 px/m) is supported up to a distance of 46 m depending on the model, observation (62 px/m) is possible even up to a distance of 322 m. This corresponds to a huge image space of more than 26,000 sqm. with continuous depth of field.  Permanent capture The multifocal sensor system captures and stores all regions of the image space in the highest detail resolution. At the same time, it is not important whether the operators are concentrating on a specific region in live mode (multiple detail zoom) or if regions of interest are displayed in detail based on video content analysis (multiple auto-tracking). The Panomera® recordings always include the entire area of interest and allow every operation to be analysed.  “Made in Germany” and GDPR-ready Like all Dallmeier cameras the new Panomera® model is manufactured entirely in Germany, at the Dallmeier factory in Regensburg. This in itself is a major factor in the manufacturer’s data protection and data security strategy, since it is then impossible for unauthorised persons to gain access through “backdoors”, for example. In all, 14 functions such as the setup of private zones, People Masking or the very latest encryption-authentication technology in the processing chain of Dallmeier solutions ensure that the strict requirements of the GDPR relating to data protection and data security are met.

System overviewExperience 1080P full HD video and the simplicity of using existing cabling infrastructure with HDCVI. The Cooper series 1080P HDCVI camera features a compact design and offers a high quality image at a friendly price. It offers various varifocal/fixed lens models with a multi-language OSD and HD/SD switchable output. Its structural flexibility and high cost performance makes the camera an ideal choice for SMB solutions. Functions Four signals over one coaxial cableHDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio*, data and power. Dual-way data transmission allows the HDCVI camera to interact with the HCVR, such as sending control signal or triggering alarm. Moreover, HDCVI technology supports PoC for construction flexibility.* Audio input is available for some models of HDCVI cameras. Long distance transmissionHDCVI technology guarantees real-time transmission at long distance without any loss. It supports up to 800m(1080P)/1200m(720P) transmission via coaxial cable, and up to 300m(1080P)/450m(720P) via UTP cable.**Actual results verified by real-scene testing in Dahua's test laboratory. SimplicityHDCVI technology inherits the born feature of simplicity from traditional analogue surveillance system, making itself a best choice for investment protection. HDCVI system can seamlessly upgrade the traditional analogue system without replacing existing coaxial cabling. The plug and play approach enables full HD video surveillance without the hassle of configuring a network. Smart IRThe camera is designed with microcrystalline LED IR illumination for best lowlight performance. Smart IR is a technology to ensure brightness uniformity in B/W image under low illumination. Dahua’s unique Smart IR adjusts to the intensity of camera's infrared LEDs to compensate for the distance of an object, and prevents IR LEDs from overexposing images as the object come closer to the camera. Multi-formatsThe camera supports multiple video formats including HDCVI, CVBS and other two common HD analogue formats in the market. The four formats can be switched over through OSD menu or by PFM820 (UTC controller). This feature makes the camera to be compatible with not only HCVRs but also most end users’ existing HD/SD DVRs. Multi-language OSDOSD menu provides multiple image adjustments and function settings to meet the requirements of different monitoring scenes. The OSD menu includes configurations such as backlight mode, day/night, white balance, privacy mask and motion detect. The camera supports 11 languages for OSD menu, namely, Chinese, English, French, German, Spanish, Portuguese, Italian, Japanese, Korean, Russian and Polish. ProtectionThe camera's outstanding reliability is unsurpassed due to its rugged design. The camera is protected against water and dust with IP67 ranking, making it suitable for indoor or outdoor environments. With working temperature range of -40 °C to +60 °C (-40 °F to +140 °F), the camera is designed for extreme temperature environments. Supporting ±30% input voltage tolerance, this camera suits even the most unstable power supply conditions. Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning.
