System Overview MXVR1004 is the new generation of mobile video recorder, it uses H.265 technology and the advantages are lowering the transmission bandwidth and saing the storage. It can support 1080P high-definition real-time recording, real-time vehicle location tracking and monitoring and the face detection. All the information such as GPS and video can be uploaded via wireless network: 3G/4G/WIFI. It has already passed EN50155/ISO16750 in order to meet the requirements of mobile use.This device can be used in kinds ofsolutions for different applications. Functions Anti-vibration- Using shock-absorbing material and structure, the new designed hard disk box can cope with varying degrees of vibration, keeping the system work normally all the time. Wide range of power supply- As the voltage output of vehicle battery changes during driving, the wide range of power supply can protect the device. 3G/4G/WIFI- Embedded with 3G/4G/WIFI module, the device can register into a public network to connect with VMS, and can send all theinformation(video/audio/alarm/gps) through wireless network. GPS- Embedded GPS module can receive location information and upload to VMS. Even when the device is offline, it can upload theinformation after it's online again and the vehicle can be tracked on the electric map of VMS. Multiple ports- With kinds of ports, like RS232, RS485, I/O, the video recorder can connect with various of accessories, such as card reader, fuelsensor, panic button and so on.system), so that the video, audio, alarm and location information can be uploaded to VMS.
March Networks’ new ME3 Pendant IR PTZ camera delivers uncompromising security for large indoor and outdoor spaces, as well as essential features to ensure high reliability, clear image capture and storage efficiency. Ideal for large-footprint environments such as parking lots, big box stores and transit stations, the camera incorporates electronic image stabilisation and HDR, so recorded video is always crisp. Universal Power over Ethernet (UPoE) ensures redundancy and zero downtime by switching to PoE when a camera loses power. And built-in PTZ auto-tracking uses motion detection to automatically track a person or object, keeping the image centred and in focus. Software updates are quick and easy to apply using the mass management feature available in Command Enterprise software, while PTZ-optimised motion histograms speed search capabilities. The 3MP PTZ includes a 40x zoom lens to capture objects 25% further away than industry-standard PTZs, and IR LEDs for uniform illumination in total darkness at a distance of more than 650 feet/200 metres. It also incorporates a Low Bit Rate compression mode to improve bandwidth and storage efficiency by as much as 50% when the camera is in its home position. The ME3 Pendant IR PTZ is protected by a weather-proof enclosure, and generates an alert in the event someone attempts to obstruct or move the camera. It comes with a variety of mounting options, including a 1.5” NPT wall mount and short pendant mount, both with back boxes.
The Evolution Stainless Steel cameras, part of Oncam’s Specialist Camera Range, are unique to the 360-degree video surveillance market as they are the only ones certified for tough environments, indoor and outdoor. The 05MP and 12MP versions have been specifically designed to meet the needs of customers operating in demanding environments such as Food Processing, Industrial, Maritime and Ports and Safe City applications. The cameras’ resilient Stainless Steel 316 housing is manufactured for enhanced corrosion resistance. The IP66, IP67, IP68, IP69K, and NEMA 4X and 6P ratings make the enclosure fit for harsh environments, while its IK10+ rating makes it resistant to impacts of 40 joules. The NSF certification and HCV EU mark make the camera range unique, guaranteeing compliance with standards for commercial food equipment in both North America as well as Europe. The only 360-degree fisheye camera in a stainless steel housing, Oncam’s new and improved camera range is available for surface and pendant mount installations. A matching stainless steel arm allows for wall, corner and pole mounting. Evolution 05 Stainless Steel: EVO-05-SS2 Evolution 12 Stainless Steel: EVO-12-SS2
VIVOTEK’s FE9391-EV is the next generation of market-leading 12-Megapixel 360° panomorph network camera, featuring a detailed 12-Megapixel CMOS sensor which guarantees superb image quality. Utilising the latest in panomorph lens technology for 180° panoramic view (wall mount) or 360° surround view (ceiling/wall/floor mount) with zero blind spots, the camera is able to provide comprehensive coverage of open areas such as airports, shopping malls, parking lots, retail stores, offices and more. Removable IR-cut filter The FE9391-EV (IP66, IK10 rated) is the successor to FE8391-V in the VIVOTEK 360° surround view family. The new model is equipped with a removable IR-cut filter and WDR Enhancement technology, allowing the camera to maintain optimal image quality around the clock for unparalleled visibility under high-contrast lighting environments. 3D Noise Reduction technology enables the camera to capture clear, polished video under low-light conditions. Latest in IR illumination The FE9391-EV's use of the latest in panomorph lens technology has led to much improved image quality with a huge drop in edge distortion. The FE9391-EV is also updated with the latest in IR illumination, VIVOTEK's Smart IR II technology with Adaptive IR. Adaptive IR enables the FE9391-EV's IR illuminators to adjust to the scene together or individually to provide the best possible IR image, reducing glaring hotspots and/or underexposed dark spots. Advanced Video Content Analysis The FE9391-EV is also be the first to include a new wave of advanced Video Content Analysis (VCA). Available in 4Q 2017, this includes better object detection in order to reduce false alarms. Through advanced Video Content Analysis functions including crowd detection features the FE9391-EV is the next steps in elevating surveillance cameras from image capturing devices to advanced notification instruments, allowing users to see more in smarter ways.
The Contera NVR Appliance from Arecont Vision Costar is designed to offer powerful IP recording in an affordable, compact chassis. The Contera NVR Appliance is equipped with an on-board 8 or 16 channel PoE switch, that can be upgraded to 24 channels, allowing for Plug and Play connection with ConteraWS™ or ONVIF cameras. With full integration to ConteraWS Web Services, the Contera NVR Appliance offers centralised user management, single sign-on convenience, mobile apps and a web client that allows for easy remote connection to your recorders. Network setup is fast and easy using ConteraWS Web Services, and eliminates the need for port forwarding or DDNS. The Contera NVR Appliance runs on a secure Linux OS and comes preloaded with ConteraVMS™ Server software as a turnkey solution.
Since 2011, the patented Dallmeier Panomera® multifocal sensor technology has provided comprehensive video protection for vast areas in many football stadiums, perimeters, airports and city areas all over the world. The new Panomera® series, the “Ultraline“, has exceptionally high effective resolution for these situations. Dallmeier presents the first model of the new series, the Panomera® S8 Ultraline, which delivers up to 190 megapixel at 30 fps. The Panomera® concept has revolutionised video technology: with up to eight sensors in a single camera, it is possible to capture enormous distances in unprecedented resolution quality. With fewer cameras and considerably less expense for both infrastructure and management, the total cost of ownership of video solutions are reduced significantly. At the same time, customer specifications regarding pixel density and coverage can be satisfied very precisely. Up to 26,000 sqm. coverage with one camera The first model of the new Ultraline series, the Ultraline S8, has an excellent dynamic range of 130 dB UWDR (effective) for an extreme Panomera® effect. This enables a resolution of 125 px/m up to a distance of 160, 104 or 82 m, enabling individuals to be recognised over the entire distance. Identification of persons (250 px/m) is supported up to a distance of 46 m depending on the model, observation (62 px/m) is possible even up to a distance of 322 m. This corresponds to a huge image space of more than 26,000 sqm. with continuous depth of field. Permanent capture The multifocal sensor system captures and stores all regions of the image space in the highest detail resolution. At the same time, it is not important whether the operators are concentrating on a specific region in live mode (multiple detail zoom) or if regions of interest are displayed in detail based on video content analysis (multiple auto-tracking). The Panomera® recordings always include the entire area of interest and allow every operation to be analysed. “Made in Germany” and GDPR-ready Like all Dallmeier cameras the new Panomera® model is manufactured entirely in Germany, at the Dallmeier factory in Regensburg. This in itself is a major factor in the manufacturer’s data protection and data security strategy, since it is then impossible for unauthorised persons to gain access through “backdoors”, for example. In all, 14 functions such as the setup of private zones, People Masking or the very latest encryption-authentication technology in the processing chain of Dallmeier solutions ensure that the strict requirements of the GDPR relating to data protection and data security are met.
The Evolution ExD Cameras, part of Oncam’s Specialist Camera Range, are unique to the 360-degree video surveillance market. Both ATEX, IEC and IECEx certified, the 5MP and 12MP versions have been specifically designed to meet the needs of customers operating in hazardous environmental conditions and potentially explosive atmospheres. The cameras’ housings are manufactured in Stainless Steel 316L, for maximum robustness. The IP66, IP67 and IP68 ratings make the enclosure resistant to harsh environmental conditions. Fit for use in markets such as Offshore and Onshore Environments, Industrial and Chemical Plants, Ports and Marine Applications and Food Processing Areas, the world’s first and only 360-degree ExD camera range is available in four mounting options: Surface Mount, Wall Mount, Pole Mount and Ceiling Mount. With no moving parts, the cameras can be PoE, 12 VDC or mains powered, dependent on whether they will be used indoor, outdoor or in extreme outdoor conditions. A heater is also available in the outdoor models. For enhanced connectivity in extreme outdoor applications, single or multi-mode fibre versions are offered. Indoor: EVO-05-EIP / EVO-12-EIP (PoE) Outdoor: EVO-05-EOA / EVO-12-EOA (115V) EVO-05-EOE / EVO-12-EOE (230V) Extreme outdoor: EVO-05-ESA / EVO-12-ESA (115V, Single Fibre Optic Mode) EVO-05-ESE / EVO-12-ESE 230V, Single Fibre Optic Mode) EVO-05-EMA / EVO-12-EMA (115V, Multi Fibre Optic Mode) EVO-05-EME / EVO-12-EME (230V, Multi Fibre Optic Mode)
Ultra-narrow 1.7mm bezel-to bezel design(1.15mm bezel on the left and top sides and 0.55mm bezel on the right and bottom sides) High contrast and high brightness greatly enhance the video layering, and present the details of the video High fidelity digital processing for a brilliant and vivid video Built-in 3D COMB filter and 3D noise reduction Wide array of connectivity options HDMI, DVI, VGA, BNC, RS232, USB, Audio Infrared, RS232 double mode, supporting remote PC control Brightness smart detection, power-saving Professional thermal design to extend equipment lifespan Built-in power, low energy consumption, ultra-quiet Fast stack installation, professional project design, supporting arc-shaped mounting Widely used in surveillance centre, dispatching platform, safe city, commercial display, etc.
AI series products adopt the most advanced AI technologies, including deep learning algorithms that primarily target people and vehicles, which provides higher flexibility and accuracy for end-users. This enables the Dahua AI series to offer various advanced applications such as Face Recognition, ANPR, Metadata, People Counting, traffic data statistics, etc. The complete line up of Dahua AI series includes network (PTZ) cameras, network video recorders, digital video recorders, servers, and platform management products. Beyond seeing the world, the power of AI allows devices to perceive the environment and understand the world in a better way. System overview Dahua new XVR8000-4KL/4K-I series XVR delivers excellent performance and high recording quality that is ideally applicable to a wide range of industries ranging from retail to banking and real estate. Holding Dahua Technology’s patented HDCVI signature technology, these new AI XVR products are featured with long distance transmission, seamless upgrading, and IoT into analogue monitoring—all while maintaining perfect 4K resolution over coax. With build-in deep learning module, XVR8000-4KL/4K-I series products adopt video image structuring technology based on deep learning algorithms, achieving high-precision human face recognition and perimeter protection. By applying deep learning artificial intelligence, XVR8000-4KL/4K-I allows users to focus on what matters most, improves event response time and helps make video actionable. With its extensive portfolio of front-end and back-end products with HDCVI technology, Dahua solutions can be easily integrated into self-contained systems to satisfy the needs of both system integrators and users. Functions Perimeter protection Automatically filtering out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improving alarm accuracy. Real time face recognition Video stream real time face recognition. Facial attributes analysis features including gender, age, expression, glasses, moustache, mouth mask. Identify people and also capture, record faces with metadata. Facial feature filtering while real time display, only show faces with target features. Face database management Configurable multiple face databases. Powerful face database management. Face database can be applied to video channels independently. Name, gender, birthday, nationality, address, ID information can be added to each face picture. Common/stranger mode Supports regular and stranger mode. In stranger mode, when XVR detects a strange face(not in device's face database), it can trigger alarm, buzzer, snapshot, record, etc. Similarity threshold can be set manually. This function is developed for important infrastructure sites for which access control is critical. Smart search Supports search by metadata of human face. Support uploading face pictures to XVR and compare them with recorded faces in XVR by similarity. Enable operators to quickly and easily search through multi channels and long duration, efficiently find out when and where a person of interest appeared.
System Overview Experience 1080P full HD colour video and the simplicity of reusing existing coaxial infrastructure with HDCVI. The full-colour starlight HDCVI camera presents a high quality colour image with rich details even in total darkness conditions. It offers various fixed lens models with a multi-language OSD and HD/SD switchable output. It adopts two powerful warm white LED illuminators, covering an effective range up to 40m(131ft). The LEDs switch on automatically in darkness to capture detail-packed full-colour images 24/7, ensuring anthentic identificaiton of objects. It is an ideal choice for applications such as schools, retail centers and parking lots. Functions Full-colour Starlight The camera adopts F1.0 large aperture lens and 1/2.8" high performance sensor. With higher amount of absorbed light and advanced image processing algorithm, the camera presents an impressive lowlight performance with an exceptional balance between noise reduction and the blur of moving object. Warm Supplemental lights With two warm supplemental LED lights, the camera is able to provide a colourful and vivid image even in total darkness. By default, the camera is set to smart light mode, in which the camera can automatically adjust the exposure time and light sensitivity simultaneously to avoid overexposureing of the objects in the image center. Also, the sensitivity and intensity of the LED lights can be remotely controlled by OSD menu. Broadcast-quality Audio Audio information is used as supplementary evidence in video surveillance applications. The HDCVI camera supports audio signal transmission over coaxial cable. In addition, it adopts unique audio processing and transmission technology that best restores source audio and eliminates noise, guaran-teeing the quality and effectiveness of collected audio information. 4 Signals over 1 Coaxial Cable HDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio*, data and power. Dual-way data transmission allows the HDCVI camera to interact with the HCVR, such as sending control signal or triggering alarm. Moreover, HDCVI technology supports PoC for construction flexibility. * Audio input is available for some models of HDCVI came Long Distance Transmission HDCVI technology guarantees long-distance and real-time transmission without any loss. It supports up to 800m for 1080P Full HD video via coaxial cable, and up to 300m via UTP cable.* *Actual results verified by real-scene testing in Dahua's test laboratory. Simplicity HDCVI technology inherits the born feature of simplicity from traditional analogue surveillance system, making itself a best choice for investment protection. HDCVI system can seamlessly upgrade the traditional analogue system without replacing existing coaxial cabling. The plug and play approach enables full HD video surveillance without the hassle of configuring a network. Multiple-formats The camera supports multiple video formats including HDCVI, CVBS, and other two common HD analogue formats in the market. A DIP switch located on the cable allows you to quickly toggle formats, further simplifying installation and debugging. This feature makes the camera compatible with not only XVRs, but also most existing HD/SD DVRs. Wide Dynamic Range Embedded with industry leading wide dynamic range (WDR) technology, vivid pictures are achieved even in the most intense contrast lighting conditions. True WDR (120dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video. Advanced 3DNR 3DNR is noise reduction technology that detects and eliminates random noises by comparing two sequential frames. Dahua’s advanced 3DNR technology allows remarkable noise reduction with little impact to sharpness, especially under limited lighting condition. Besides, the advanced 3DNR effectively decreases the band width and saves the storage space. Protection The camera's outstanding reliability is unsurpassed due to its rugged design. The camera is protected against water and dust with IP67 ranking, making it suitable for indoor or outdoor environments. Supporting ±30% input voltage tolerance, this camera suits even the most unstable power supply conditions. Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning.
With 16ch perimeter protection, the XVR intelligently avoids false alarms to less important objects such as falling leaves and rain, and send alarms only when identifying human or vehicle. Face Recognition function enables alarm for suspects on blacklist, allowing passing for authorised people on whitelist, also alert for approaching of strangers. Besides, utilising 4ch Metadata Search functions, the new XVR products are smart search enabled, capable of automatically extracting face feature attributes. Offering incomparable perimeter protection, face recognition and metadata search technology, Dahua AI XVR is applicable to a wide range of industries ranging from retail to banking and real estate.
The Avigilon H4 Multisensor camera combines self-learning video analytics with exceptional coverage, featuring 3 or 4 individually-configurable sensors that can be positioned to monitor virtually any area. With 9-32 MP total resolution, it delivers broad coverage and high image detail, and uses H.265 compression technology to reduce bandwidth and storage requirements while maintaining clear images. Each camera sensor incorporates Avigilon self-learning video analytics and works with Avigilon Appearance Search™ technology, our award-winning AI video search engine.
The Contera™ Outdoor Dome megapixel camera features 1080p and 5-megapixel (MP) resolution for optimum performance. The Contera Outdoor Dome combines a day/night mechanical IR cut filter with an integrated motorised remote focus and zoom precision iris (P-iris) lens for excellent, optimal image quality. Regardless of the time of day, the Contera Outdoor Dome is prepared for any lighting condition. For applications with poor lighting conditions, Enhanced WDR™ (wide dynamic range) at 120dB provides the best visual balance to shaded and bright light conditions. For clear colour images in low-light, NightView™ offers strong low-light sensitivity for capturing details in extremely poor-lit scenes. Built-in Smart IR LED illumination automatically adjusts output in response to the distance of an object in view to prevent over-exposure when the object is very close to the camera. The Contera Outdoor Dome is ONVIF (Open Network Video Interface Forum) Profile S and G compliant, providing interoperability between network video products regardless of manufacturer.
System OverviewThe multi-sensor camera provides added flexibility for capturing wide area CCTV. With four 2MP adjustable lenses can provide a flexible choice of the angle, the camera can replace multiple single-sensor cameras providing a higher return on investment. The multi-sensor camera features contrast, backlight compensation, white balance, and resolution control to create a crystal-clear image even in the most challenging lighting conditions. FunctionsStarlight TechnologyFeaturing Dahua’s Starlight Technology, this camera is ideal for applications with challenging lighting conditions. Its low-lightperformance delivers usable video with minimal ambient light. Even in extreme low-light conditions, Starlight Technology is capable of delivering colour images in near complete darkness (less than 0.01 lux). Wide dynamic rangeEmbedded with industry leading wide dynamic range (WDR) technology, vivid pictures are achieved even in the most intense contrast lighting conditions. For applications with both bright and low lighting conditions that change quickly, True WDR (120dB) optimises both the bright and dark areas of a scene at the same time to provide usable video. Intelligent video system (IVS)With built-in intelligent video analytics, the camera has the ability to detect and analyse moving objects for improved CCTV. The camera provides optional standard intelligence at the edge allowing detection of multiple object behaviours such as abandoned or missing objects. IVS also supports Tripwire analytics, allowing the camera to detect when a pre-determined line has been crossed, ideal for business intelligence, and Facial Detection, for searching or identification of individuals. EnvironmentalWith a temperature range of -30 °C to +60 °C (-22 °F to +140 °F), the camera is designed for extreme temperature environments. The camera complies to an IK10 impact rating making it capable of withstanding the equivalent of 55 kg (120 lbs) of force. Subjected and certified to rigorous dust and water immersion tests, the IP67 rating makes it suitable for demanding outdoor applications. For environments with rain, sleet, snow, and fog, an integrated wiper provides users with clear visibility at all times. ProtectionSupporting ±30% input voltage tolerance, this camera suits even the most unstable conditions for outdoor applications. Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning. HEVC (H.265)H.265 ITU-T VCEG is a new video coding standard. H.265 Following standard developed around the existing video coding standard H.264 , some retain the original technology, while some of the relevant technology to improve the new technology uses advanced technology to improve the relationship between the code stream, encoding quality, and the delay between algorithm complexity, optimise settings specific contents include: Improve compression efficiency, improve the robustness and error recovery capabilities, real-time to reduce the delay, reduce channel acquisition time and a random access delay, reduce complexity, etc.
The Evolution 180 Outdoor Camera is built upon Oncam’s expertise and heritage on 360-degree technology. It is specifically designed for applications that require a dewarped panoramic view of an outdoor scene, without blind spots, from a single sensor camera. The 12MP high-resolution sensor and the built-in 3D dewarped panoramic video provides industry leading Panoramic+ views. The true day/night functionality allows images to be produced in all lighting conditions, including additional IR lighting. The camera is IP66, IP67, IP68, IP69K and IK10+ rated, making it a robust design. Its versatile enclosure enables wall and pendant mounting, while the integrated adjustable mounting allows for an angling of up to 45°. When angled, Oncam’s Angle Compensation Technology (ACT) corrects the view, straightening vertical lines in the scene.
Tamron has been long recognised as an innovative source for mega-pixel lenses for critical ITS applications, affording them keen insight into industry needs and trends. Trending steadily higher are projections for the worldwide number of installed ITS cameras. Increasing in concert with forecasted camera count is growing demand for substantially higher ITS installation versatility – without compromise in optical performance. As part of an ongoing initiative to serve this dynamic market, Tamron has developed a new 1/1.8”, 15-50mm, F/1.4 zoom lens featuring a continuous range of focal lengths which includes the most widely used angles of view for traffic surveillance. A compact design enables PTZ dome installations, making the Tamron DE005 3 mega-pixel integrated zoom lens ideal for new systems and an efficient means to seamlessly upgrade existing cameras. 1. Ideal focal length for traffic surveillance Rugged and durable construction assures peak performance over an extended life cycle Ideal 15-50mm focal length is suitable for license plate recognition, identification of vehicles and individuals Designed to match 1/1.8” sensors common to traffic surveillance system cameras Accommodates larger imager sizes 2. Enhanced versatility PTZ dome compatibility. Even while realising a 50mm telephoto focal length, a 90mm chassis can be accommodated Lens-to-camera integration simplifies installation and eliminates back focus adjustment requirements Advanced stepping motors enable precise remote control operation and reduce installation time Auto focus enabled 3. Optics engineered for low light surveillance Specialised optical formula minimises narrowing of aperture at higher zoom ratios F/1.4 is achievable from 15-35mm and F/1.6 at 50mm Outstanding image integrity is realised by eliminating colour smear and diminishing chromatic aberrationAdd to Compare
Tamron Co., Ltd., total optics manufacturer and a leader in the security industry, announced the release of a near IR corrected / 5 mega-pixel board mount type zoom lens. Development concept Security cameras today offer rapidly improving picture quality and many manufacturers of security devices are now developing cameras with high-pixel image sensors. In light of this trend, Tamron has developed a high-performance zoom lens for PTZ’s and bullet cameras. This zoom lens has the resolving power to support high pixel counts and can support 1.8µm pitch image sensors. It promises three desirable characteristics: super-wide-angle support for high pixel counts, and high performance. With an angle of view of over 100°, this 5 mega-pixel lens is a new type of board mount zoom lens. The lens, moreover, not only offers 5 mega-pixel picture quality under visible light, but the same high level of quality is accomplished with near-infrared light conditions. Day or night, this lens, for the new age ensures high-resolution and high-performance monitoring with no compromise of picture quality. Tamron will lead the market for high-definition security with the newly developed zoom lens supporting 5 mega-pixel and near-infrared lighting. Key features 1. Super-wide-angle, high-picture-quality 3.5 x zoom lens for PTZ Achieves a wide 123.1° angle with 1/2.7” sensors (16:9) and 100° angle with 1/3” sensors (4:3). Enables wide-area monitoring with a single camera. 2. Maintains 5 mega-pixel high performance even in near-infrared light Achieves 24-hour, 5 mega-pixel monitoring without loss of picture quality. Lighting conditions are not a concern as the lens will provide uniform picture quality and resolving power day or night. Clip picture quality remains excellent as high pixel count is maintained, helpful for recognising persons. 3. Aperture mechanism supporting P-Iris Stepping motor enables precise aperture control. Depending on the application, aperture range can be controlled to a desired position to optimise the image quality. 4. Compact body, with overall length of just 64.25 mm Uses new iris mechanisms to maintain compact form with high picture quality. Tamron’s years of technical experience have achieved a form that is smaller but maintains super-wide-angle support for high pixel counts, and high performance.Add to Compare
Browse CCTV Lenses
CCTV camera lens products updated recently
According to IHS Market, it is estimated that there are over 60 million security cameras in the United States, and other reports say these cameras capture more than four billion hours of footage per week. Over the last decade, IP camera technology has dominated the conversation as it has provided users with a broad offering of enhanced image quality and features. With a large percentage of existing security systems relying on analogue, many end users looking for high definition (HD) video quality have been forced to take on a complete system overhaul. Infrastructure overhaul for HD video To make the switch, customers would need to change everything, from cameras to hardware to wiring– not to mention the lengthy installation process that would ensue. IP cameras also require higher Internet speeds and more cloud space. Whether constrained by budget, bandwidth or storage, many end users have been unable to adopt this new video surveillance method.Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike. By utilising the current Coaxial cables, this offering yields high definition video, while requiring minimal infrastructure changes and is an optimal surveillance choice for security customers. Plus, with new advancements and updates being made frequently to this technology, there is a solution for every security need. The enhanced alternative of HD over Coax has been warmly welcomed in the security industry, thanks to its simple solutions and ever-evolving features. Many new analogue HD cameras are “plug and play,” able to connect directly to existing Coaxial cables. This eliminates the need for a complete system change, creating cost-savings for the end user and an enhanced video quality offering. Easy solutions for HD video As a result, integrators can cost-effectively upgrade their customer’s surveillance solution while using their legacy infrastructure, making it an attractive option for end users and an easy sell for dealers. Latency in video is another common issue with network-based camera systems, where even the slightest delay in video surveillance can hinder security response HD over Coax cameras themselves are always expanding and evolving to meet a wide array of security needs. With the introduction of fisheye and multi-sensor cameras, users now have a multitude of coverage options, not to mention the introduction of 4K bringing resolution options to the same level as IP. Some newer technologies are even touting 4K cameras paired with 4K digital video recorders (DVRs) made specifically for analogue systems. Longer cables grant transmission for up to 1600 feet, double the distance of standard analogue solutions, and triple that of IP systems. This single cable is able to transmit both HD video and audio. Recently, broadcast quality audio over Coax has become available in limited models, a substantial improvement over older analogue technology, which was unable to transmit audio. Stopping video delay Latency in video is another common issue with network-based camera systems. Even the slightest delay in video surveillance can hinder security response. IP cameras are forced to compress and packetise their video for transmission. The outcome of this is a reduced number of images per video, which in turn causes delay. HD over Coax on the other hand, delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity. Additionally, the point-to-point transmission delivers uncompressed video free of lag. Another touted benefit is that, unlike IP networked cameras, analogue systems provide a more secure video transmission. With so much sensitive information housed on a businesses’ network, adding another point of network access through an IP camera can create concerns for cyber security risks. HD over Coax delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity Preventing network hacking With HD over Coax, the physical connections between the camera and DVR prevent network hacking. By keeping the video surveillance system offline, security professionals are able to direct their attention to the physical threats at hand, rather than having to focus on deterring cyber security risks. One of the primary difficulties of deploying HD video solutions is the fact that many older systems utilise a wide variety of HD standards and platforms. To make matters more complicated, after HD over Coax was brought to market, manufacturers raced to create their own version of this technology. Today, the most popular proprietary standards are HD-CVI, HD-TVI and AHD. However, integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible.Integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible Diversifying surveillance through one DVR To combat these issues, manufacturers have introduced products with more flexibility to their portfolios. One example of this is the penta-brid DVR which grants the ability to seamlessly integrate multiple technologies deployed across one application. This means that systems with diverse camera brands and technologies, such as a mix of HD-CVI, HD-TVI, AHD, analogue or IP, can be connected through one DVR. For many end users with legacy analogue systems, penta-brid DVRs give them greater freedom to choose between a variety of solutions, rather than being limited to one option. With video resolution increasing, the space needed to store the footage is similarly rising. Penta-brid technology has been able to adapt to these evolving needs, giving users ample storage space to house the HD and 4K surveillance video with some of the newest models including H.265 compression. HD casino surveillance made simple For casinos, HD images are critical for identifying unauthorised personnel and unlawful behaviours to create a safe environment for guests and staff While HD over Coax is beneficial to many end users and integrators, those in the casino and hospitality markets find it crucial. With a combination of high profile guests, large amounts of cash on hand, constant crowds and strict industry regulations, reliable video surveillance is a must. Deploying new IP systems comes at a stiff price. When looking to upgrade their video surveillance, casinos must also be mindful of the installation process. When moving to an IP-based system, ripping out old wires and replacing them with new is the standard practice. This practice can be both disruptive and costly, not to mention gaming regulations require casino activities be monitored at all times so a complete system shutdown would result in revenue loss. This cost can be hard to justify, especially when the current legacy analogue system remains in working condition with only the lower image resolution to date it. For these scenarios, the most cost-effective option is to leverage the legacy infrastructure, replace the existing cameras with new devices, and reap the benefits that HD video has to offer without any lapse in security. For casinos, HD images are critical for identifying unauthorised personnel and unlawful behaviours to create a safe environment for guests and staff. HD over Coax cameras now offer the same resolution as IP cameras with a plug and play approach, that cuts down on expense without sacrificing quality. For businesses and applications that are unable to adopt IP technology, whether it be cost or time prohibitive, HD over Coax now features most of the same benefits IP has to offer without breaking the bank. By providing clear images in real time, maximising existing infrastructure, and affording cyber security benefits, HD over Coax provides an attractive solution for many end users and integrators.
When people think of control rooms, images from James Bond movies or intense action stories come to mind. What they fail to realise is the incredible level of ergonomics, technology, precision and craftsmanship required to create a top-notch command and control room. “These are rooms of complex functionalities, where hundreds of elements must be integrated and function in sync,” says Jim Coleman, National Sales Manager, AFC Industries. Professional teams from several different industries must coordinate every single detail in order to ensure that functionality occurs each and every time. Reconfigurable furniture for control rooms AFC Industries is one company that specialises in equipping control rooms for security and other applications. AFC Industries was established in 1994 as a family-owned business that focuses on the design and construction of ergonomic products. Their height-adjustable units guarantee the right height for standing desks as well as traditional sitting levels. The company produces an array of Command and Control ergonomic security consoles and mounting solutions. Modular racking systems facilitate efficient storage of electronic and audio-visual equipment. As technology changes, older traditional consoles are no longer a necessity. Many organisations instead are choosing to use lighter, less costly, reconfigurable furniture that allows more flexibility. Command Centres need to be able to reconfigure the space at will. Because most systems are housed in secure data centres, users should be able to quickly move their positions by relocating their workstations, utilising different network connections. Simple control room features, like those addressing lighting or operator comfort, can make the difference in a correct or incorrect decision during a crisis Emergency operations centres A positive trend driving the market for control rooms is an increase in emergency operations centres (EOCs), says Randy Smith, President of Winsted. “Everybody is concerned about what happens in an emergency,” says Smith, and the centres are popping up as a tool for emergency preparedness. It’s another environment where sit-stand work stations are the rule. Winsted’s product lines include stock modular and customised elements in good-better-best categories – from basic to lots of “bells and whistles;” jobs can be configured from modular elements or customised as needed. Customised control rooms for seamless operation There is a lot at stake in control room design: Lives can depend on how effectively a control room functions in an emergency. Control rooms should seamlessly accommodate both everyday occurrences and crisis situations, says Matko Papic, Chief Technology Officer of Evans Consoles. Better-operating control rooms can increase efficiency and reduce and/or mitigate risk. Simple control room features, like those addressing lighting or operator comfort, can make the difference in a correct or incorrect decision during a crisis. Addressing operator comfort can reduce the possibility of workers’ compensation claims. End users are seeing multiple benefits of creating a better operating environment, better sightlines, more comfort and attention to ergonomics. As a fully integrated control room solutions provider, Evans Consoles approaches the needs of a control room environment beginning in the conceptual/operational planning stage. They consider broad issues such as how information will be processed, the interface between technology and operators, and the cognitive and physical interactions of operators – understanding that these factors drive the layout and function of control rooms. After analysing tasks to be performed in the environment, Evans lays out the consoles to meet those needs. Rather than a predesigned solution, each installation is tailored around a specific application. Read part 2 of our Control Rooms series here
Many end-users shell out the cash to acquire the newest high-end devices, plug in, and expect to be wowed A well-developed surveillance system can give a single security guard the power to see what otherwise might take a hundred pairs of eyes to see. But what happens when all the components are all connected and powered up, and the resulting image on the screen is, well, indiscernible, or, at the very least, terribly pixelated? Many end-users shell out the cash to acquire the newest high-end devices, plug in, and expect to be wowed. Often enough, however, what they see on the screen is not what they were expecting – and they wonder what they just paid for. In a good high-definition system, what factors actually create the best image quality? With so many variables involved, from the camera’s lens to the imaging algorithms to the monitor resolution – just to name the obvious ones – how do system integrators achieve the best on-screen images? The lens The first component to handle light from an object, this may be the one most taken for granted in cameras of any sort. (Just try scratching or cracking one and you’ll agree.) In the days of analogue cameras, it seemed that any old lens would do just fine. However, as the technology inside cameras evolved and more powerful sensors (more pixels) became available, engineers and programmers demanded more from lenses. Moreover, intelligent video content analyses would be impossible without high-accuracy lenses.In what way do lenses impact the image quality? The key factor here is light transmission. The quality of light passing through the lens itself will forever be critical to the quality of image reproduced. A lens made using ultra-precision molding aspherical technology achieves more accurate colour, better light, and clearer images. Multilayer broadband anti-reflection coating further maximises a lens's light transmission while minimising the residual reflection of light on the surface of each optical lens. Variables involved include the camera’s lens, the imaging algorithms and the monitor resolution When it comes to fabricating a megapixel lens that hits the mark, the materials used and the processes by which lenses are produced are the two most critical criteria. The materials most often used to create lenses are glass and specialised plastics. An HD lens made of ultra-low-dispersion optical glass – which, by using dispersion characteristics that are different from those of conventional optical glass – will deliver better HD performance. Machine-automated lens production using specialised plastics results in high output for camera producers, and the lenses produced are more uniform in design and quality. For an HD vari-focal lens, its image quality depends largely on the precision of the cam. The cam rotates to drive the zoom and focus lens groups forward and backward for a smooth continuity of focal length and adjustment of the focal point. A lack of precision with the cam inevitably causes an offset or tilt of the lens' optical axis during zooming and focusing, leading to a serious loss of image quality. Lens production is a delicate balancing act. The slightest errors or imperfections will be very noticeable when tested Lens production is a delicate balancing act. The slightest errors or imperfections will be very noticeable when tested. The features of a lens that affect image resolution, clarity, and contrast must be perfect. Achieving uniformity of image resolution at the centre and the edges of a lens requires high-precision machinery. And once a lens has been properly crafted, the assembly of the camera, the lens housing materials, and the alignment of the optical axis demand utmost accuracy. To put it mildly, quality control must be rigorous. Image signal processing As light passes through the lens, the sensor captures it and converts it to data. Raw RGB data is transmitted by the camera sensor and undergoes Image Signal Processing (ISP) such as noise reduction, white balance, WDR, curve correction and colour correction, etc. The data is then transformed to true colours for each pixel point, for people to see images that look “normal” to the human eye. It is the Image Signal Processing that defines the final image quality on the screen. Collecting data in different conditions is vital, for instance, outdoor data should be analysed with natural light on days with sun, overcast, rain, and fog, at dawn, at dusk, and so on. Similarly, when using cameras equipped with infrared sensors, testing the IR light signals in various conditions is necessary as well. Actual image performance depends upon variables such as low light illumination, signal to noise ratio, dynamic range of light, and more. ISP algorithms aim at increasing the signal data and decreasing noise. Cameras with Wide Dynamic Range (WDR) will yield improved video imaging with both background and foreground objects in high contrast or high-backlight environments, maximising the amount of detail in brighter and darker areas in one field-of-view. In scenes with low contrast and low light, the sensors deliver digital image signals and at the same time send some amount of digital noise that directly hinders image clarity. Three-dimensional digital noise reduction (3D DNR) removes unwanted artifacts from an image, reducing graininess. Where cloudy weather poses a challenge, auto-defogging technology helps to identify the density of fog or rain with gray-white colour ratio analysis, and imbues images with true colour reproduction. Ramping up the megapixels and frame rates yields great video, but also results in more bandwidth used and more storage occupied Matching megapixels to image quality When the factors mentioned above line up well, correlating cameras and monitors creates the best viewing experience. When a high definition camera is in place, a monitor with a high resolution will display images much more clearly. But if the monitor’s resolution is low, it will not deliver the high-quality images expected – or possible – from that HD camera. For an 8 MP camera, for instance, users do best to apply monitors with 4K × 2K resolution. Though common sense, this deserves to be mentioned because users might decide to upgrade their systems with 4K monitors, but with perhaps 1.3 MP cameras installed. In such a scenario, there’s no guarantee the on-screen image quality will automatically improve. Managing data and bandwidth In terms of a complete, high definition surveillance system, when the right factors come together and the calibrations are set, image quality – even in a standard HD 1080p setup – can be extremely good. The final piece of the puzzle is managing the data. Ramping up the megapixels and frame rates yields great video, but also results in more bandwidth used and more storage occupied. Squeezing bandwidth threatens image quality and clarity, but keeping ample room for signal transmission and storage will eventually increase the overall cost for customers. Is it possible for integrators to optimise their customer’s system and, at the same time, stay within budget constraints? Luckily, it can be done. Squeezing bandwidth threatens image quality and clarity, but keeping ample room for signal transmission and storage increases the overall cost for customers To do this, a more efficient video encoding solution would allow an improvement in compression efficiency of 40–50% over H.264. Improvements to algorithms that are adaptive to a particular scene give users control over bitrate. Another option would be to start recording video only when an event triggers an alarm, since most security guards are primarily concerned with moving objects rather than a scene’s generally stagnant background. This intelligently helps optimise bandwidth and storage consumption. Another method is to use a single panoramic or fisheye camera in place of several HD cameras for coverage – the reduced number of security devices will reduce bandwidth demands and the rate of storage consumption as well. Getting the best image quality Now let’s put this all together. Naturally, integrators and users will refer to their product specs to understand features and functions, fine-tuning each component for best results. Also, as suggested above, users should select an HD camera comprehensively in terms of lens performance, pixels, image quality, and overall system compatibility and performance. Next, matching the backend device and management platform should be carefully considered in a complete security system. Installing equipment that has been engineered for a given scene is a must, along with strategising how to get the most coverage out of the lowest number of cameras. Finally, product quality, warranty, price, and on-going customer service are all important factors that customers should take into account as well.
