Browse CCTV Multiplexers

Multiplexers - Expert commentary

Technology evolution leads to changes in security control room furniture
Technology evolution leads to changes in security control room furniture

Technology is changing the look and function of today’s security control rooms. Old-school CRT (cathode-ray tube) monitors are giving way to the thinner, flat screen monitors in the control room environment, but the transition is gradual. Randy Smith of Winsted still sees many control rooms that need to make the conversion, which is a boon to his company’s business. Furniture today is designed differently to accommodate the thinner monitors, often with larger screens. Need for integrated rack systems With the increase of IP-based systems comes the need for integrated rack systems that include advanced functionality such as cable management, adds Jim Coleman, National Sales Manager, AFC Industries. Server rooms are environmentally controlled by cooling systems and power systems monitored on the IP network. Low-profile flat screens allow centres to utilise space vertically, thus creating a smaller footprint for the consoles. Additionally, with IP-based systems, workstations will have a smaller footprint because there is less cumbersome equipment. In most cases the servers are stored in a secured, climate controlled environment to eliminate overheating of the servers and maintain their security, says Coleman. This environment also helps with cable and power management. AFC builds technical furniture racks that adhere to the precise needs of computer network server room operators. The company designs and fabricates LAN workbenches with versatile functionalities, and server room workstation racks that are scalable. There is a complete line of IT workbenches, IT computer racks and computer server rack mounts with flexible mounting options. In most cases the servers are stored in a secured, climate controlled environment to eliminate overheating of the servers and maintain their security Flexible control room designs Matko Papic, Chief Technology Officer of Evans Consoles, says the transition from bulky CRT equipment to flat-screen (lower profile) monitors was a major disruption in control room design; it changed the whole dynamic. Another evolution is the use of IP video streaming, which allows more flexibility in manipulation of audio-video content, and requires more flexible control room designs. Another shift, driven by larger, higher-definition monitors, is a shift to fewer monitors that display more information. Instead of a smaller monitor for each information stream, larger monitors now consolidate that information into “dashboard” displays. Looking ahead, control rooms will need to be more flexible, both in the initial design and the ability to adapt to changing technology, says Papic. Legacy customers who are currently using PCs may be moving to more remote applications. Sit-stand equipment will continue to be increasingly prevalent. “There will be more emphasis on flexibility, technology integration, and the ability to change over the life of the system,” says Papic. Consolidation of multiple operations into a single system A trend in security is consolidation of multiple physical operations into a single system, says Papic. As a result, more customers are taking more interest in alarm management and situational awareness. How is the technology being used in terms of alarm triggers? How can the systems react rapidly and provide information to a larger audience in the control room? These questions impact how control rooms are designed, and Evans Consoles can adapt lessons learned from other markets to these trends in the security arena. Greater use of technology is inevitable, says Coleman of AFC Industries. “It is virtually impossible for humans to monitor all security data at the street level in our cities,” he says. “As computers become more powerful and their programs more all-encompassing, we will see a greater shift to robotic and technology uses that will provide enhanced monitoring capabilities and safety Read our Control Rooms series here

Choosing the right power supplies for security installations
Choosing the right power supplies for security installations

 Selecting the optimum power supply for a system is critical to an installation  When it comes to selecting power supplies, knowledge is power. Determining the power requirements of every systems product, taking into account their integration with one another is critical to ensure that you are selecting and installing the power solutions most appropriate for your installation. Such information will enable you to select the power supplies that will be required to keep your security system running efficiently in the long run. Paul Rizzuto, Technical Sales Manager, Altronix Corp outlines some of the key factors to consider when choosing the right power solution for security installations - including those of video surveillance systems and access control systems - and fire alarm systems. Questions to consider when selecting the optimum power supply Before commencing the evaluation and selection process, three fundamental questions/issues need be addressed:Approvals and conformance to norms: Are there any specific agency approvals that the installation must conform to?Each state, county and even municipality has their own requirements regarding agency approvals. There are a variety of compliance issues such as UL listings for video, access control and fire/life safety that need to be adhered to along with specific local codes. It's imperative that you check with the local AHJ (Authority Having Jurisdiction) to find out what agency listings you must conform to during the design process to assure your security system is in compliance before installing any components and power supplies. Features required: What are the application specific features required for the installation? Selecting power supplies for a security or fire alarm system is a complex process due to a number of variables Before starting the design process, a comprehensive analysis of the facility's security systems are required to determine feature sets of the power supplies. Up until recently, selecting power supplies often required the need to combine various components to deliver the functionality desired. For example, does the system need battery back-up in case of a power failure?  All that has changed with the introduction of a new breed of integrated power solutions that deliver both cost and installation advantages. Quantity, location and power requirements of the security system componentsWhat is the number of devices in the system, the power requirements for each, and their physical location?This information is necessary to determine the size and quantity of the power supplies, how many security devices they will run, and where they will be physically located.  It is always a good rule of thumb to add 20% more power to your calculations as a safety factor.  Alarm signal generation is a key consideration when dealing with power consumption in fire alarms systems Dealing with power consumption issues in fire alarm systems Power consumption is a primary issue when configuring fire alarm systems. One of the most critical considerations revolves around how alarm signals are activated. When an alarm condition exists, Notification Appliance Circuits (NAC) are output from the Fire Alarm Control Panel (FACP) to activate notification appliances such as strobes and horns commonly used to indicate an emergency situation. The number of notification appliances to be activated, along with the current draw for each device and its distance from the FACP, sometimes makes the deployment of NAC Power Extenders a necessary system component. For example, in large commercial installations or multi-tenant buildings, the total current draw of the notification appliances may well exceed the power output of the FACP. In these instances, one or more NAC Power Extenders need to be installed for those notification appliances where the wire runs are too long for the FACP to deliver sufficient power.  Features to consider when selecting a NAC Power Extender: Number of Class A or Class B indicating circuits.Total power rating (ex. 6.5 amp, 8 amp or 10 amp).Number of Aux. power outputs with or without battery backup.Programmable outputs: SynchronizationTemporal Code 3Input to output follower mode.Enclosure capacity: Room for battery backupAmple knockouts and room for wiringAgency approvals UL, MEA, CSFM and FM.NAC Power Extenders are available with programmable features that maintain horn/strobe synchronization by either producing internally generated sync protocols utilized by major signal manufacturers, or by electronically repeating these sync protocols from the FACP outputs. Power supply requirements for access control systems - key standards to follow    To ensure safety any device designated to lock or unlock an exit must be connected to the fire alarm systemAccess control systems manage entry and exit points at a facility by means of controlled locking devices. NFPA (National Fire Protection Association) requires that any device or system intended to actuate the locking or unlocking of exits, must be connected to the facility's fire alarm system so that all doors will release when an alarm signal is generated.To comply with NFPA requirements, there are two classifications of locking devices that need to be addressed: Fail-Safe and Fail-Secure. Fail-Safe locking devices such as magnetic locks release when they lose power. Fail-Secure locking devices such as electric strikes unlock when power is applied and may be manually released from inside a secured area. This determines the manner in which your power solution removes or provides power and the sequence and timing of each action.Access control power supplies come in both AC and DC versions and some provide multiple voltages simultaneously. Features include independently trigger controlled Fail-Safe/Fail-Secure outputs, power supervision, battery charging and fire alarm interface. Wall and rack mount models are also available.To comply with NFPA requirements, there are two classifications of locking devices that need to be addressed: Fail-Safe and Fail-Secure Some systems may also require the installation of panic hardware devices. Upon activation, the devices' high current power demand can reach up to 16amps, but not all power supplies can handle these high inrush currents.  As a result, you need to specify a power supply designed for this type of application.  Some operate a single panic hardware device and require optional modules to add features like timing functions, output relays, fire alarm disconnect, or power for additional panic hardware devices.  Therefore, these "base" models almost always require additional modules to deliver the functionality you need and may not be cost effective. More advanced models offer integrated features and supply a comprehensive solution. In addition to the convenience of these integrated devices, they are highly cost efficient with respect to total cost of ownership and installation. Video surveillance systems - typical power consumption guidelinesVideo surveillance systems typically run 24/7/365 placing high demands on power supplies. These video power supplies need to deliver a clean and consistent source of 24VAC or 12VDC power to assure uninterrupted operation. Depending on the video component's specific power requirements and its location, there is a wide selection of power supplies to select from. They can be wall or rack mounted, designed for use indoors or outdoors, and feature AC or DC outputs. Configurations typically range from 1 to 32 outputs and some models offer additional features like 115 or 230VAC input with current ratings as high as 25 amps, power LED indicators, and PTC or fused protected outputs. Certain models provide both 24VAC and 12VDC to power both types of surveillance cameras simultaneously. Environmental conditions can affect the performance of video components and the power supply when situated outdoors A few additional variables to consider when selecting video surveillance power supplies include: Environmental conditions: Temperature differences due to change of seasons, day or  night, can often be extreme and can have a direct affect on the performance of both the video components and the power supply when located outdoors. Enclosures for outdoor power supplies should be rated to withstand the elements.Ground Isolation: In some cases, the surveillance cameras are not equipped with internal electrical isolation. Should this be the case, it's important to specify a power supply with this feature. Video Transmission Systems: For years, the use of structured cable has been an inexpensive method for transmitting video and data between head end equipment and camera systems. The introduction of UTP transceiver hubs with integral camera power make it possible to transmit both video and data via structured cable along with the power needed for the cameras. This is accomplished via video balun/combiners which pass the power and data to the camera and send the video back to the head end equipment. New highly versatile devices with integral power provide system designers with a highly integrated solution. This new breed of integrated device greatly reduces the time and expense of configuring and installing separate components while helping to minimize bandwidth requirements for large security systems. Paul RizzutoTechnical Sales Manager Altronix Corp

Latest ComNet Europe Ltd. news

ComNet expands their line of Cybersecurity products by adding intelligent media converters
ComNet expands their line of Cybersecurity products by adding intelligent media converters

ComNet, Communication Networks of Danbury, Connecticut, an ACRE company, and a USA-based manufacturer of fibre optic transmission and networking equipment, is expanding the line of Cybersecurity products by adding to its line of intelligent media converters. These intelligent media converters with Link Guardian create a physical layer of protection that limits network traffic to one-way communication between the source and destination networks. The ComNet CNGEUMC4+2(TX, RX)/M is designed to prevent cybersecurity attacks by limiting data flow to one direction between a secured and unsecured network. External cyber threats How the devices are deployed will determine which direction the data will flow. Called a ‘Unidirectional Media Converter’, this physical security is more effective than software-enabled network firewalls. This data connection is un-hackable and invulnerable to malware. The ComNet CNGEMUMC4+2(TX, RX)/M is a hardened four-port all-gigabit intelligent Media Converter. This product is designed to provide deterministic data transfer in only one direction (unidirectional), to segment and protect networks, devices, and other digital assets (databases, historians, SCADA, PLCs, DCS, etc.) from external cyber threats. Distance extending device The primary purpose is as a distance extending device, but they can also be used as an entry point to a network" It has four 10/100/1000Base-T(X) copper ports and two 1000Base-FX SFP ports. It effectively only allows data to travel in one direction. The CNGEMUMC4+2(TX, RX)/M provides exclusive functionality for easy field deployment including DIP switch-based operation of RSFP (redundant SFP) for creating redundant fibre connections. According to Andrew Acquarulo Jr., ComNet CEO and President, “Media converters are generally simple to use. The primary purpose is as a distance extending device, but they can also be used as an entry point to a network. By adding features such as Link Guardian, we are offering our customers another way of making their network more reliable and secure from unauthorised access. This keeps us front and centre in terms of innovation.” More competitive position The company believes that these features give them a more competitive position in the market and allows ComNet to be unique and differentiate the product line. “Making any network operate more efficiently and effectively is another way of how ComNet moves the market. Cybersecurity/ unauthorised access is a monumental concern for all security networks.” “By leading with our advanced technology, such as Link Guardian, we position ComNet and our solutions as the company to turn for ‘new and better’ transmission options. Our position is that if you are concerned about the long-term success of your application, choosing ComNet ensures it will be,” said Skip Haight, ComNet VP of Marketing.

ComNet announces that its parent company, ACRE has acquired Razberi Technologies’ product line
ComNet announces that its parent company, ACRE has acquired Razberi Technologies’ product line

ComNet, Communication Networks of Danbury, Connecticut, a USA-based manufacturer of fibre optic transmission and networking equipment and an ACRE brand, announced that ACRE has acquired Razberi Technologies and the product line will be added to and sold under the ComNet brand and portfolio of products. ComNet will now be selling Razberi products through its established channels. Intelligent video appliances The Razberi product line of intelligent video appliances, automated security software, and health monitoring software is designed to protect and monitor IP-based surveillance systems and complements the ComNet line of innovative network communication solutions. The Razberi appliance allows cameras, access control points, and other devices to add layers of protection while lowering the threat of cyber security risks to businesses. According to Tom Galvin, Razberi founder and Chief Product Officer, “We’re excited to join with ComNet and add more value to their deep network product line. ComNet can now offer a more comprehensive infrastructure for video transmission, storage, management, and cyber security.” Open video surveillance platform Bringing Razberi Technologies into the ComNet product portfolio made sense on many levels" Razberi’s open video surveillance platform includes intelligent appliances combined with automated cyber security and health monitoring software. In combination with a wide range of top third-party video management software (VMS) applications and IP cameras, enterprises can flexibly deploy a best of breed solution that reduces their total cost of ownership and reduces the likelihood of a costly cyber breach. “Bringing Razberi Technologies into the ComNet product portfolio made sense on many levels,” said Andrew Acquarulo Jr., ComNet’s Chief Executive Officer and President, adding “ComNet has strongly considered adding an enhanced surveillance product line that would make a significant impact on the market and bring a measurable improvement to any application. We believe Razberi is that product.” Enhancing cyber security and securing business networks ComNet believes the Razberi product line is a cost-effective solution and its cyber security products can complement ComNet’s emphasis on securing business networks. “With the intense focus on cyber security, the unique Razberi products directed to cyber threats, CameraDefense and ApplianceDefense now combined with ComNet Port Guardian, present a formidable defence against unauthorised network access,” said Skip Haight, ComNet Vice President of Marketing, adding “Our position is that if you are concerned about the long-term success of your application, choosing ComNet ensures it will be.”

ACRE announces the acquisition of Texas-based Razberi Technologies for strengthening its product portfolio
ACRE announces the acquisition of Texas-based Razberi Technologies for strengthening its product portfolio

ACRE, a global brand providing state-of-the-art security systems, announced the acquisition of Razberi Technologies based in Farmers Branch, Texas. This purchase will enhance ACRE’s strategic expansion plans for strengthening its video and communications business and product portfolio. This is the latest M&A transaction since ACRE completed the acquisitions of two access control businesses - Open Options in December 2018 and RS2 in May 2019; both of which have continued to prosper and build ACRE’s overall market position. Razberi will significantly increase ACRE’s position in the communications and video market, enhancing the ComNet portfolio and providing complementary technologies to its access control brands. System health monitoring technology In addition, Razberi provides increased cyber security protection and threat response times Razberi, which was founded in 2011, has developed a portfolio of products that enable enterprises to deploy a simple, secure best-of-breed video surveillance system. Razberi’s open product platforms work with third-party video cameras, video management and video analytics software. In addition, Razberi provides increased cyber security protection and threat response times. ACRE will leverage the technology and expertise of Razberi beyond video across its access control brands for providing server builds, cyber security and system health monitoring. ACRE CEO Joseph Grillo stated that this transaction will continue to expand ACRE’s competitive position in a highly fragmented market with great growth potential. Advanced cyber security “The acquisition of Razberi boosts ComNet’s reach in the communications space and enhances our product portfolio with the addition of advanced cyber security and system health monitoring technologies,” said Grillo. “We are excited to join the ACRE organisation with its strong global reach that will open new opportunities for the Razberi product range,” said Tom Galvin, Founder and Chief Product Officer, Razberi.  Tom Galvin will remain as the General Manager of the business post-acquisition and will be instrumental in integrating Razberi into ACRE. Imperial Capital were the advisors to Razberi on this transaction. Financial details of the transaction were not released.
