Hikvision 2-Wire Modular Video Intercom
Hikvision is launching its new 2-Wire modular IP Intercom for retrofitting in multi apartment buildings. This is an extension solution to already successful 2-Wire kits that are mainly used for small residential houses, using the same housing and components from the recently launched 2nd Generation IP intercom technology, also ‘inheriting’ it’s modular nature, which makes it flexible for any scenario.
The Intercom delivers all the benefits of IP surveillance through just two wires – data and power. This makes it simple to install, saving time and cost - great for retrofitting and modernising large residential and office building projects.
Full HD images give a clear picture of the door area on your indoor station. IR provides excellent night vision, and the inclusion of WDR (wide dynamic range) means there’s no problem if the camera is faced with direct light from outside. All in all, your indoor station screen will give you a clear overview of your doorstep, and a mobile app means you can manage entry from anywhere you like.
The modular nature of the Intercom gives the system massive flexibility, with a range of modules to choose to build the right system for the scenario. This can also be integrated with video surveillance, access control and intrusion systems so it can be a seamless part of any total security solution. The 2-Wire system can be combined with IP intercoms through a network that is connected to power and data distributors while also sharing common accessories and modules.
Other features include:
- Great looking image from camera that can be recorded in Video Surveillance system
- High quality of audio even on noisy streets
- Remote control via common mobile application
- Simplified configuration
- Optional wall or flush mounting installation
- Common Hikvision software and application
- Up to 16 additional cameras can be observed at the indoor station.
Typical applications for this new product will be in modernization of residential apartment buildings, school buildings and office buildings.
“This extension to our intercom range is a great example of Hikvision as a smart home security solution provider, combining intercoms with Video Surveillance, Access control and intrusion”, says Cenek Maly, EU Channel Product Manager at Hikvision, “It brings a variety of modern functions such as mobile app control, high resolution images delivered at high speed, and audio quality to bring residential intercom systems to the next level.”
|Type of Kit/ System||Video & Audio|
|Mount Type||Wall Mount mount|
|Panel Material||Stainless Steel panel material|
Operating Temperature oC: -10 ~ +55 C (14 ~ 131 F)
Operating Humidity %: 10 ~ 90
Voltage: 24 V DC
Power Consumption: ≤10 W
|Physical Specifications||Dimensions mm: 196 x 133 x 26|
|Download PDF version Download PDF version|
