Dahua Technology TPC-BF5601 Thermal Network Bullet Camera

Technical Specification

Features:
  • Make: Dahua Technology
  • Model code: TPC-BF5601
  • Series: PRO Series
  • Colour Type: Colour / Monochrome
  • Resolution: 1280 x 1024 resolution
Read more
Additional info:

640x512 VOx uncooled thermal sensor technology Athermalised Lens (thermal), Focus-free  Support Fire detection & alarm  Various lens optional (7.5/13/25/35mm)  2/2 alarm in/out  Micro SD memory, IP67, PoE, ePoE

Read more
Make Dahua Technology
Manufacturer Dahua Technology Ltd
Model code TPC-BF5601
Series PRO Series
Colour Type Colour / Monochrome
Resolution 1280 x 1024 resolution
Specialist Type Thermal
Electrical Specifications Voltage: 12 V DC, PoE
Power Consumption: 13 W
Motion Activated Yes
Focal Length mm 7.5 ~ 35
Wide Dynamic Range Yes
Picture Elements HxV 1280 x 1024
Network Properties Image Frame Rate: 25 ~ 30 fps
Interface: RJ-45
Network Protocols: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Y/ C (Video Output) 1 Port (CVBS/BNC)
Compression Type H.265, H.264 , MJPEG
Physical Specifications Weight g: 1,500
Dimensions mm: 291 x 103 x 97
Environmental Specifications Protection: IP67
Operating Temperature oC: -40 ~ +70 C (-40 ~ +158 F)
Operating Humidity %: 0 ~ 95
System Requirements Web Browser: >IE8,
Additional info
  • 640x512 VOx uncooled thermal sensor technology
  • Athermalised Lens (thermal), Focus-free
  • Support Fire detection & alarm
  • Various lens optional (7.5/13/25/35mm)
  • 2/2 alarm in/out
  • Micro SD memory, IP67, PoE, ePoE
