Dahua 4CH 1080N WizSense DVR (Cooper Series)

Product Profile

WizSense is a series of AI-powered products and solutions from Dahua, built on independent AI chips and deep learning algorithms. Designed to detect humans and vehicles with high accuracy, it enables quick responses to defined targets. It offers intelligent, user-friendly, and inclusive surveillance solutions.

Series Overview
The Cooper-I/T Series delivers simple, cost-effective HDCVI solutions with 24/7 reliable monitoring and high-quality imaging. It features two-way talk over coaxial cable, Smart Motion Detection (SMD Plus), and excellent value with low labor costs.

Key Features

Two-way Talk
Enables real-time communication between the camera, client, and recorder over coaxial cable, with voice intercom and audio alerts.

SMD Plus
Uses AI to detect and classify moving objects, reducing false alarms caused by irrelevant motion.

Smart Dual Light
Automatically switches between IR and white light modes based on detected activity, minimizing light pollution while adapting to different scenes.

One-click Arming/Disarming
Easily enable or disable alarm functions like message alerts and audio alarms via the mobile app.

Customizable Alarm Audio
Upload and use personalized audio alerts through the app or XVR for flexible, user-defined warnings.

AI Coding-ABR
Reduces storage needs by 50% compared to H.265, while maintaining high image quality, especially in dynamic scenes.

Read more

Technical Specification

Make Dahua Technology
Manufacturer Dahua Technology Ltd
Category CCTV>Digital video recorders (DVRs)
Model code DH-XVR1B04-I/T
Series WizSense Series
Channels 4 channels
Hybrid IP inputs 5
Monitor Outputs 1 HDMI, 1 VGA
Compression Type AI Coding; Smart H.265+; H.265; Smart H.264+; H.264
Recording System HDD
Audio Recording and Properties G.711a; G.711u; PCM
Physical Specifications Dimensions mm: 197 x 204.3 x 41.5
Weight kg: 0.54 kg
Electrical Specifications Voltage: 12 V DC
Power Consumption: <7 W (without HDD)
Environmental Specifications Operating Temp oC: -10 ~ +45 C (14 ~ 113 F)
Operating Humidity %: 10 ~ 90
Additional info
  • *Dolynk cloud compatible version: DMSS V2.0.1 and above, Dolynk Care V2.5.1 and above.
  • 4-channel two-way talk over coaxial cable allows for seamless communication between the camera, client and recorder.
  • 4-channel SMD Plus for analog channels which allows the device to trigger accurate alarms for humans and vehicles.
  • 4-channel AI Coding saves on storage and bandwidth while maintaining the details of targets in videos.
  • Supports HDCVI, AHD, TVI, CVBS and IP video input.
  • Supports up to 5-channel IP camera input and each channel can be up to 2 MP. The incoming bandwidth reaches 20 Mbps.
  • Supports accessing Wi-Fi cameras, making it suitable for a wide range of scenes.
  • Smart H.265+ and H.265 dual-stream video compression.
