Vicon V2008D-VF411-B IP Dome camera Specifications

Vicon V2008D-VF411-B 8MP outdoor IR HD IP dome camera

Technical Specification

Features:

Make: Vicon
Model code: V2008D-VF411-B
Chip Inch Size: 1/1.8 inch
Colour Type: True Day / Night
Resolution TVL: 8 MP

Additional info:

8MP Resolution Al Engine Gen 2 (Deep Neural Network Accelerated Engine) Motorised zoom and focus varifocal lens Quad Streaming True Day/Night function (ICR) Micro SD/ SDHC/ SDXC Card support Zero-Down-Time(ZDT) Power Switching ONVIF Profile S/ G/ T/ M support Weatherproof (IP66) and Vandal Proof (IK10 Rating) 164 ft/50 m IR range; Smart IR/Adaptive IR H.265/H.264 compression; M-JPEG compression Multi Exposure HDR

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Vicon
Manufacturer	Vicon Industries
Category	CCTV>IP Dome cameras
Model code	V2008D-VF411-B
Chip Inch Size	1/1.8 inch
Colour Type	True Day / Night
Resolution TVL	8 MP
HD	Yes
Megapixel	Yes
Sensitivity lux	Colour: 0.08 lux; BW: 0.008 lux, IR On
Indoor/Outdoor	Indoor/Outdoor
Digital (DSP)	Yes
Mount Type	Ceiling mount
Electrical Specifications	Voltage: PoE, 12 V DC, 24 V AC Power Consumption: 12.9 W (PoE), 15.2 W (12 V DC), 13.2 W (24 V AC)
Focal length	3.6 ~ 11 mm
Compression	H.264; H.265; M-JPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1 ~ 1/67,500 sec
S/ N (Signal/ Noise) Ratio dB	> 50
Built-in IR LED	Yes
Network Properties	Interface: 10/100/1000 Mbps Base-T; RJ-45 Network Protocols: ARP, PPPOE, IPV4/V6, ICMP, IGMP, QOS, TCP, UDP, DHCP, UPnP, SNMP, SMTP, RTP, RTSP, HTTP, HTTPS, FTP, NTP, DDNS, Config, ONVIF Profile S/G/T/M Image Frame Rate: 30 fps / 25 fps Inclusive DVR/ Web Server: Micro SD/SDHC/SDXC
Physical Specifications	Dimensions mm: 134 x 117 Weight g: 760
Environmental Specifications	Operating Humidity %: 10 ~ 90 Protection: IP66, IK10
System Requirements	Web Browser: Microsoſt® Edge®; Google® Chrome®, Mozilla® Firefox®
Download PDF version Download PDF version

Make

Vicon

Manufacturer

Vicon Industries

Vicon V2008D-VF411-B Roughneck Pro Network Dome Camera

The Vicon Roughneck® Pro V2008D-VF411-B is an advanced 8MP HD IP Dome Camera designed for professional-grade surveillance applications. Equipped with the second-generation AI Engine, it offers sophisticated video analytics to meet contemporary security demands. Its motorised varifocal lens with remote zoom and focus ensures superior image quality and installation versatility.

Featuring multi-exposure HDR technology, this camera excels in challenging lighting conditions, while the True Day/Night ICR function ensures vibrant daytime colour accuracy and crisp monochrome night-time imaging. The Smart/Adaptive IR LEDs provide illumination up to 164 feet (50 meters), allowing for excellent low-light visibility.

Key Features

8MP resolution with Al Engine Gen 2
Multi-exposure HDR and True Day/Night function
Motorized zoom and focus varifocal lens
Support for H.265/H.264/M-JPEG compression and quad streaming
ONVIF Profile S/G/T/M support and Zero-Down-Time power switching
Weatherproof (IP66) and vandal proof (IK10 rating) construction

Ideal Use Cases

This dome camera is ideal for both indoor and outdoor installations in commercial, industrial, or high-security environments. Its robust design is compliant with IP66 and IK10 standards, providing reliable performance in harsh conditions. It's perfect for areas requiring 24/7 monitoring and advanced video analytics.
