Large fences and locked gates can be effective deterrents, but they are not a guaranteed method of security to deter intruders. They could still gain access to the property, so why not raise an alarm before they can attempt to break into the building? It’s time to deliver true peace of mind and install the first wireless low-mount external detector from Pyronix, the XDL12TT-WE.
XDL12TT-WE wireless intrusion detector
Combining Pyronix’ multi-award-winning Enforcer two-way wireless technology with their established external detection protocols, including: Dual-Vision, Tri-Signal Detection Logic and Gaussian Frequency Modulation (GFM), the XDL12TT-WE delivers a completely reliable external detector, with a completely flexible and simple installation.
This multi-award-winning technology delivers easy installation and superior security, with full supervision, anti-jamming and 128-bit wireless protocol encryption to maximise reliability and ensure the signals transmitted by the system are protected and any code-grabbing is prevented. Each Pyronix two-way wireless device is both a transmitter and a receiver and there is a wealth of installation benefits.
Enforcer two-way wireless devices The high sensitivity receiver used in Enforcer two-way wireless devices allows a wireless signal range of up to 1.6km in open space
The high sensitivity receiver used in Enforcer two-way wireless devices allows a wireless signal range of up to 1.6km in open space, which eliminates the need for repeaters and therefore reduces the installation costs. The high-sensitivity antenna of the XDL12TT-WE ensures that the signals being transmitted and received are as strong as possible. Utilising Gaussian Frequency Modulation (GFM) to spread the signal, while reducing unwanted noise and harmonics, enables the XDL12TT-WE to meet stringent European, ETSI and other worldwide standards.
Consisting of two independent Passive Infrared (PIR) sensors and one microwave (MW) sensor in one common housing, the Tri-Technology (TT) of the XDL12TT-WE delivers advanced outdoor protection. To identify the presence of an intruder, the XDL12TT-WE utilises Tri-Signal Detection Logic alongside TT, whereby to identify the presence of an intruder, all three sensors of the detector need to be activated sequentially in quick succession to create an alarm.
Tri-Signal Detection Logic
The two PIRs of the XDL12TT-WE have a dedicated volumetric field of view. The top PIR detects outwards and up, while the bottom PIR detects outwards and down, without either crossing the central horizontal plane between them. This setup of non-overlapping PIR sensors alongside Tri-Signal Detection Logic, delivers highly secure sequential detection and increases its tolerance to pet immunity.
