Technical Specification

Features:
  • Make: COM One
  • Model code: VM4 IP
  • Series: Viewcom Series
  • Video Inputs: 4
  • Other Inputs: 5
Read more
Additional info:

8 camera inputs available with upgrade.

Read more
Make COM One
Manufacturer COM One
Model code VM4 IP
Series Viewcom Series
Video Inputs 4
Other Inputs 5
Audio Input Yes
Video Outputs 1
No of Other Outputs 4
Compression Type M-JPEG
Network Protocols IP, PSTN, ISDN, GSM, ADSL
Interface 10base-T Ethernet
Resolution TVL 320 x 240
Bandwidth MHz 115.2 Kbps
Image per second (IPS) 10
Control 1 control port
System Requirements System Requirements: Win 95, 98, 2000 with Ethernet card, IE, Netscape
Electrical Specifications Voltage: 12V DC external
Video Inputs Overview 4 multiplexed inputs, NTSC, PAL, Colour/Mono
Additional info 8 camera inputs available with upgrade.
