Master internal intrusion with the Pyronix KX

Product Profile

Utilising Pyronix’ patented technologies for residential, commercial and light-industrial use, the range consists of Passive Infrared (PIRs), Dual Technology (DT) and DT anti-masking (DT-AM) detectors to provide the ideal solution for any property.

KX features

With detection ranges up to 30m, curtain and volumetric coverages, animal immunity up to 25kg, auto sensitivity and much more, any combination of KX detectors can cover lounges, kitchens, bedrooms, extended corridors, bedroom areas, workshops, garages - whatever the application, there is a perfect KX.

Available in both wired and wireless, every KX detector comes in the same robust and stylish casing, to provide a complete security solution with the same professional, uniform and attractive finish.

Two-way wireless technology

Utilising Pyronix’ multi-award-winning two-way wireless technology, installation could not be easier, with features like one-push-to-learn and signal strength indicators. These allow the installer to check for optimum signal and learn the KX onto the system without having to refer back to the panel. This maximises convenience, accuracy and the speed of the installation.

For light-industrial and commercial use the KX DT range is ideal. Within a DT, both PIR and microwave sensors need to be triggered to sound the alarm, which makes them perfectly suited to harsher environments, such as mechanics workshops, aisles or storage facilities. The range also includes fantastic anti-cloaking, anti-blocking and anti-masking wired variations for Grade 3 installs using the KX15DTAM.

The KX detectors are optimised for performance and presentation to deliver the most stylish, dependable and flexible security solution for any internal environment. The KX really is the master of internal intruder detection.

Read more

Technical Specification

Make Pyronix
Manufacturer Pyronix Limited
Model code KX10DP
PIR Detectors Yes
Dual/ Quad Technology Quad Technology Detectors
Infra Red Beams Yes
Coverage/ Range m 10
Angle of Detection o 85
Pet Tolerance Yes
Quad Element Sensor Yes
Temperature Compensation Yes
Sealed Optics Yes
Mount Type Wall, Ceiling
Vertical Coverage 1.8 ~ 2.4 m
Indoor/Outdoor Indoor
Wall/Ceiling Mount Wall/ceiling
Electrical Specifications Power Supply: 9 ~16 V DC / 13.8 V DC typical
Physical Specifications Dimensions mm: 117 x 69 x 50
Environmental Specifications Operating Temp oC: -10 ~ +40 (14 ~ 104 F)
Power Consumption 16 mA
Additional info
  • 10m pet immune detection, animals up to 24kg
  • Selectable EOL (End Of Line) resistors
  • Blue wave technology
  • Auto sensitivity feature
  • Digital temperature compensation
  • Tamper proof brackets included
  • Sealed optics
  • ABS plastics
  • Complies with EN50131-1
Download PDF version
