Dahua DHI-LPH65/75/86/98-MC470-P 65/75/86/98'' DeepHub Pro Smart Interactive Whiteboard
Product Profile
System Overview
Dahua DeepHub Pro Smart Interactive Whiteboard is a new generation of smart interactive whiteboards that have a high performance main controller and multiple intelligent functions. It adopts direct-type LED backlight technology and has a 4K LED display that is built of anti-dazzle tempered glass with a hardness of 7 on the Mohs scale. The display comes in 65”, 75”, 86” and 98”. This ultra-thin whiteboard supports up to 20 multi-user writing points and is equipped with a 48 MP motorized lens, speakers, 8 microphone arrays, and is touchscreen. It offers various functions such as video conferencing, writing on the whiteboard, wireless screen sharing and allows you to scan codes to access content on the whiteboard.
Functions
4K Camera with Ultra-wide FOV
8-MP camera with a maximum resolution of 4K@30 fps. It supports live view, and has an ultra-wide field of view (diagonal 112.7°, horizontal 104°, and vertical 70.2°), capturing vivid details even in relatively large meeting rooms. AI Recognition of Drawings Identifies hand-drawn structures such as straight lines, dotted lines, arrow-straight lines, arrow-dotted lines, triangles, parallelograms, trapezoids, rectangles, circles, pentagons, cylinders, entagrams, semicircles, and rounded rectangles.
Easy to Share
Enhances the experience of sharing files by scanning a code. It automatically determines the network of the device to readily share the QR code across the extranet and the intranet. QR code encryption and extraction are also featured, providing privacy and data security through the required entry of a 6-digit password for verification.
Non-contact Motion-controlled System
Recognizes various types of body movements, such as grabbing, up, down, left and right motions, to interact with elements on the screen without touching the screen. You can motion to turn pages, scroll in different directions in a document, and take screenshots.
Screen Sharing
The content on your screen can be freely shared with one other device through a wired connection.
Similar to Real Writing Experience
The electronic whiteboard supports pen-point writing. It comes equipped with specialized pressure-sensitive writing pens, designed to enhance the writing experience. With its soft, comfortable nib, writing on the whiteboard feels natural, similar to the real writing experience.
Text Recognition
Converts written letters into text in real time, using the default font of the system.
Wireless Screen Sharing
In addition to basic file sharing, the device offers wireless screen sharing, interactive operations between two screens, and reverse transmissions. It also supports screen grouping (multiple transmission), host mode (for overall permission control), real-time transmission of images, videos and audios from the wireless camera of the mobile phone to the device, and split-screen mode that displays up to 9 splits on the same screen.
Strong Security System
Designed with a strong security system, the device features digital password, gesture password and fingerprint password for added protection. These unlock methods can all be applied to USB permissions, the lock screen, touch lock and the factory restore settings. Up to 100 fingerprint passwords can be set, and the false acceptance rate is less than 0.001%.
Technical Specification
Make | Dahua Technology |
---|---|
Manufacturer | Dahua Technology Ltd |
Category | CCTV>CCTV monitors |
Model code | DHI-LPH65/75/86/98-MC470-P |
Monitor Type | LED |
Effective Screen Size Inches | 65-inch; 75-inch; 86-inch; 98- inch |
Colour Type | Colour |
Resolution | 4K |
Signal Mode | NTSC |
Touchscreen | Yes |
Housing Material | Metal casing |
Built-in Speaker | Yes |
Monitor Mount Type | Wall |
Weight kg | 65-inch: 40 kg , 75-inch: 54 kg , 86-inch: 67 kg , 98-inch: 91 kg |
Scanning Frequency Hz | 150 Hz ~ 20 kHz |
Front Controls | 1 × power button (right side), 1 × USB 3.0 (left side) |
Environmental Specifications |
Operating Temperature oC: 0 ~ 40 C (32 ~ 104 F) Operating Humidity %: 10 ~ 90 |
Electrical Specifications |
Power Consumption: 65-inch: 200 W; 75-inch: 300 W; 86-inch: 400 W; 98-inch: 600 W Voltage: 100 ~ 240 V AC |
Video Input | 1 × HDMI IN |
Additional info |
|
