Aiphone PT-1210NA 12 V AC plug-in transformer

Technical Specification

Features:
  • Make: Aiphone
  • Model code: PT-1210NA
  • Voltage: 12 V AC
  • Power Consumption: 15 W
  • Dimensions mm: 75 x 56 x 48
Additional info:

12 V AC transformer Class II compact plug-in style power source Used for intercom and door release applications UL and CSA Listed Indoor use

Read more
Make Aiphone
Manufacturer Aiphone
Category Access Control>Access control system accessories
Model code PT-1210NA
Electrical Specifications Voltage: 12 V AC
Power Consumption: 15 W
Physical Specifications Dimensions mm: 75 x 56 x 48

Product description

Aiphone PT-1210NA AC 12V Plug-in Transformer

The Aiphone PT-1210NA is a reliable AC 12V transformer designed to provide efficient power for intercom and door release systems. Known for its compact, plug-in style, this Class 2 power source ensures seamless integration into various electrical setups. Its UL and CSA listings attest to its high safety standards, making it a dependable choice for industry professionals seeking quality and trustworthiness.

Key Specifications

  • Power Input: AC 120V, 60Hz
  • Power Output: AC 12V, 10VA (830mA)
  • Power Consumption: 15W
  • Wiring Connection: Screw terminals
  • Dimensions: 2-15⁄16" x 2-3⁄16" x 1-⅞"

This transformer is engineered specifically for indoor use, offering a practical and safe solution for low-voltage power needs.

Ideal Use Cases

The PT-1210NA is compatible with an array of Aiphone communication systems, including CCS-1A, IE-1AD, IE-1GD, IE-2AD, IE-8MD, and LEM-1DL. It also effectively powers the EL-12S door strike, making it versatile for various security and communication applications. This adaptability enhances installation options for professionals in need of reliable power solutions for sophisticated intercom setups.
