Technical Specification

Features:
  • Make: Sony
  • Model code: SNC-DF50P
  • Series: SNC-DF Series
  • Chip Inch Size: 1/3
  • Colour Type: Colour / Monochrome
Read more
Make Sony
Manufacturer Sony Professional Solutions Europe
Model code SNC-DF50P
Series SNC-DF Series
Chip Inch Size 1/3
Colour Type Colour / Monochrome
Resolution TVL 480
Dome Type Variable Focus
Sensitivity lux 0.35
Digital (DSP) Yes
Indoor/Outdoor Indoor
Mount Type Ceiling, Wall
Electrical Specifications Voltage: 12 V DC / 24 V AC
Power Consumption: 9 W
Focal length 2.8 ~ 10.0
Compression JPEG, MPEG-4, H.264
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/50 ~ 1/10,000
S/ N (Signal/ Noise) Ratio dB > 50
Signal Mode PAL
Video Output 1.0 Vp-p, 75 Ohms
Network Properties Interface: 10BASE-T / 100BASE-TX (RJ-45)
Network Protocols: TCP/IP, ARP, ICMP, HTTP, FTP (client/server), SMTP
Image Frame Rate: 25 fps
Physical Specifications Dimensions mm: 126 (Dia) x 140.5
Weight g: 920
Environmental Specifications Operating Temp oC: -10 ~ +50
System Requirments Operating System: Windows 2000/ Windows XP
Web Browser: Microsoft Internet Explorer Ver6.0 or higher
Hardware and System related properties: Pentium4 1.5GHz or higher
