Hikvision DS-2CD2512F-I(W)(S) IR mini dome network camera

Technical Specification

Features:

Make: Hikvision
Model code: DS-2CD2512F-I(W)(S)
Chip Inch Size: 1/3 inch
Colour Type: Colour / Monochrome
Resolution TVL: 1.3 MP

Additional info:

HD720p Video Up to 10m IR DWDR/3D DNR/BLC Support On-board Storage, up to 128GB Support Wifi (-W) Built-in Mic Audio/Alarm IO optional (-S) EN50155, EN50102, IK08

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Hikvision
Manufacturer	Hikvision
Category	CCTV>IP Dome cameras
Model code	DS-2CD2512F-I(W)(S)
Chip Inch Size	1/3 inch
Colour Type	Colour / Monochrome
Resolution TVL	1.3 MP
HD	Yes
Megapixel	Yes
Sensitivity lux	0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
Digital (DSP)	Yes
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: 5 W
Compression	H.264, MJPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
Electronic Shutter range	1/3 ~ 1/1,00,000s
Network Properties	Interface: 1 RJ45 10M / 100M Ethernet interface Network Protocols: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,BonjourTCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour Image Frame Rate: 25 fps /30 fps Inclusive DVR/ Web Server: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Physical Specifications	Dimensions mm: 99 x 97 x 53 Weight g: 600
Environmental Specifications	Operating Temp ^oC: -30 ~ +60 C (-22 ~ +140 F) Operating Humidity %: 0 ~ 95 Protection: IP66, IK08
Additional info	HD720p Video Up to 10m IR DWDR/3D DNR/BLC Support On-board Storage, up to 128GB Support Wifi (-W) Built-in Mic Audio/Alarm IO optional (-S) EN50155, EN50102, IK08
