Hanwha Multi-sensor/Multi-directional Camera
Product Profile
Hanwha Techwin’s Wisenet PNM-9000VD multi-sensor/multi-directional camera provides quality images and modular lens configuration at an affordable price. This camera supports 30fps image capture and true 120 dB WDR without compromising frame rate for each of its two 5MP sensors. Each sensor has its own Wisenet 5 chip, providing a full suite of built-in video analytics including loitering, directional detection, fog detection, tampering, motion detection and objects entering or exiting an area.
Technical Specification
| Make | Hanwha Techwin |
|---|---|
| Manufacturer | Hanwha Techwin Europe |
| Model code | PNM-9000VD |
| Chip Inch Size | 1/2 inch |
| Colour Type | Colour / Monochrome |
| Resolution TVL | 2x 5MP |
| Megapixel | Yes |
| Sensitivity lux | 0.16 lux |
| Digital (DSP) | Yes |
| Indoor/Outdoor | Outdoor |
| Electrical Specifications |
Voltage: PoE Power Consumption: 12 W |
| Compression | H.265/H.264 : Main / Baseline / High, MJPEG |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | 2~1/12,000sec |
| Video Output | CVBS : 1.0 Vp-p / 75Ω composite, 720 x 480 for installation |
| Network Properties |
Interface: RJ-45 (10/100BASE-T) Network Protocols: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour Image Frame Rate: 30 fps |
| Physical Specifications |
Dimensions mm: 197 x 84 Weight g: 1250 |
| Environmental Specifications |
Operating Temp oC: -40 ~ +55 C (-40 ~ +131 F) Operating Humidity %: < 90 Protection: IP66, IK10 |
| System Requirments |
Operating System: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 Web Browser: Recommended Browser : Google Chrome, Supported Browser : MicrosoftInternet Explorer 11, Microsoft Edge, Mozilla Firefox (Windows 64-bit only), Apple Safari (Mac OS X only) |
| Additional info |
|
| Download PDF version Download PDF version | |
