Hikvision DS-7604NXI-K1/4P/VPro Network Video Recorder (NVR) Specifications

Hikvision AcuSeek NVR with AI-Powered Video Search and AcuSense Technology

Product Profile

The Hikvision AcuSeek VPro Series NVR is designed to enhance video search capabilities through the use of a large multimodal AI model. It enables users to perform video searches using both text and voice inputs, making it possible to quickly locate footage featuring specific objects. With integration into the Hik-Connect platform, searches can also be conducted directly from mobile devices.

The system supports up to 4-channel AcuSeek and AcuSearch functionality, allowing flexible and efficient search operations. It adopts Hikvision’s AcuSense technology to help minimise manual effort and reduce overall security-related costs. In addition, accurate perimeter protection capabilities contribute to reducing false alarms.

For simplified deployment, the NVR offers automatic camera connection and configuration. It supports up to 4 IP camera inputs and features plug-and-play functionality with four Power-over-Ethernet (PoE) interfaces.

In terms of performance, the device provides decoding capacity of up to 3 channels at 12 MP, 6 channels at 8 MP, 12 channels at 4 MP, or 24 channels at 1080p. It supports multiple video compression formats, including H.265+, H.265, H.264+, and H.264, and offers up to 40 Mbps incoming bandwidth.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Hikvision
Manufacturer	Hikvision
Category	CCTV>Network video recorders (NVRs)
Model code	DS-7604NXI-K1/4P/VPro
Series	Hikvision VPro Series
Video inputs	4
Hardware solution	Yes
Inbuilt multiplexer	Yes
Recording system	HDD
Storage capacity	Up to 16 TB capacity for each HDD
Secondary storage	USB
Storage rate	30 fps
Resolution	4K
Alarm Handling	4 in, 1 out
Video motion detection	Yes
Electrical Specifications	Voltage: 48 V DC Power consumption (W): ≤ 10 W (without HDD)
Physical Specifications	Weight (kg): ≤ 1 kg Dimensions (mm): 319 x 240 x 48
Environmental Specifications	Operating temperature (°C): -10 ~ +55 C (14 ~ 131 F) Operating humidity (%): 10 ~ 90
Additional info	Up to 4-ch AcuSeek and AcuSearch function Adopt Hikvision AcuSense technology to minimize manual effort and security costs Accurate perimeter protection effectively reduces false alarms Automatic cameras connection and configuration Up to 4-ch IP camera inputs, plug & play with 4 Power-over-Ethernet (PoE) interfaces Up to 3-ch@12 MP or 6-ch@8 MP or 12-ch@4 MP or 24-ch@1080p decoding capacity H.265+/H.265/H.264+/H.264 video formats Up to 40 Mbps incoming bandwidth
Download PDF version Download PDF version

Make

Hikvision

Manufacturer

Hikvision

Category

CCTV>Network video recorders (NVRs)

Model code

DS-7604NXI-K1/4P/VPro

Series

Hikvision VPro Series

Video inputs

Hardware solution

Yes

Inbuilt multiplexer

Yes

Recording system

HDD

Storage capacity

Up to 16 TB capacity for each HDD

Secondary storage

USB

Storage rate

30 fps

Resolution

Alarm Handling

4 in, 1 out

Video motion detection

Yes

Electrical Specifications

Voltage: 48 V DC
Power consumption (W): ≤ 10 W (without HDD)

Physical Specifications

Weight (kg): ≤ 1 kg
Dimensions (mm): 319 x 240 x 48

Environmental Specifications

Operating temperature (°C): -10 ~ +55 C (14 ~ 131 F)
Operating humidity (%): 10 ~ 90

Additional info

Up to 4-ch AcuSeek and AcuSearch function
Adopt Hikvision AcuSense technology to minimize manual effort and security costs
Accurate perimeter protection effectively reduces false alarms
Automatic cameras connection and configuration
Up to 4-ch IP camera inputs, plug & play with 4 Power-over-Ethernet (PoE) interfaces
Up to 3-ch@12 MP or 6-ch@8 MP or 12-ch@4 MP or 24-ch@1080p decoding capacity
H.265+/H.265/H.264+/H.264 video formats
Up to 40 Mbps incoming bandwidth

Download PDF version Download PDF version
