ComNet FVTR1D1A2C1(M,S)1 transceiver

Technical Specification

Features:

Make: ComNet
Model code: FVTR1D1A2C1(M,S)1
Data Transceiver: Yes
No of Fibres: 1 fibres
No of Video Inputs: 1 channels

Additional info:

ComNet FVTR1D1A2C1(M,S)1 transceiver supports simultaneous transmission of short-haul quality 10-bit bi-directional digitally encoded video plus one bi-directional data channel, two channels of bi-directional audio and contact closure over one multimode or single mode optical fibre. The module is universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces, and most major data protocols. The module uses 24-bit 96kHz sample rate digital encoding for superior transmission of balanced line-level audio.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	ComNet
Manufacturer	ComNet Europe Ltd.
Category	CCTV>Fibre optics, telemetry receivers, transmitters, transceivers
Model code	FVTR1D1A2C1(M,S)1
Data Transceiver	Yes
No of Fibres	1 fibres
No of Video Inputs	1 channels
Bandwidth MHz	10 MHz bandwidth
Physical Specifications	Dimensions mm: 155 x 135 x 56 Weight g: 900
Environmental Specifications	Operating Temperature ^oC: -40 ~ +75 C (-40 ~ +167 F) Operating Humidity %: 0 ~ 95
Electrical Specifications	Voltage: 8 ~ 15 V DC Power Consumption: 4 W
Additional info	ComNet FVTR1D1A2C1(M,S)1 transceiver supports simultaneous transmission of short-haul quality 10-bit bi-directional digitally encoded video plus one bi-directional data channel, two channels of bi-directional audio and contact closure over one multimode or single mode optical fibre. The module is universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces, and most major data protocols. The module uses 24-bit 96kHz sample rate digital encoding for superior transmission of balanced line-level audio.
