Cloudvue TCCF303C12 3MP Compact Mini-Dome 2.8mm

Technical Specification

Features:
  • Make: Cloudvue
  • Model code: TCCF303C12
  • Chip Inch Size: 1/2.8 inch
  • Colour Type: Colour / Monochrome
  • Resolution TVL: 3 MP
Read more
Additional info:

The Flex Gen3 Compact Mini-Dome provides crisp and clear high-definition video at 3MP resolution and provides exceptional video quality and low-light performance in a small, compact form factor. Rated IP66/IP67 and IK10 for weather and vandal resistance, the camera can function in hard outdoor conditions. Equipped with Power over Ethernet, the Compact Mini-Dome reduces installation costs by eliminating the need for power cabling.

Read more
Make Cloudvue
Manufacturer Cloudvue
Model code TCCF303C12
Chip Inch Size 1/2.8 inch
Colour Type Colour / Monochrome
Resolution TVL 3 MP
Sensitivity lux 0.005 ~ 0.05 lux
Electrical Specifications Voltage: PoE
Focal length 2.8 mm
Compression MJPEG, H.264, H.264 IntelliZip, H.265 and H.265 IntelliZip
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/4s ~ 1/10,000s
Network Properties Interface: RJ-45(10/100BASE-T)
Network Protocols: TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, RTSP, TLS, Unicast, Multicast, NTP, ICMP, IGMP, SMTP, WS-Security, IEEE 802.1x, PEAP, EAP-TLS, EAPoL, SSH, HTTPS, SOAP, WSAddressing, CIFS, SNMP, UPNP, RTSP, LLDP
Image Frame Rate: 20 fps / 60 fps
Physical Specifications Dimensions mm: 112 x 72
Environmental Specifications Operating Temp oC: -40 ~ +50 C (-40 ~ +122 F)
Operating Humidity %: < 90
Protection: IP66, IP67, IK10
Additional info

The Flex Gen3 Compact Mini-Dome provides crisp and clear high-definition video at 3MP resolution and provides exceptional video quality and low-light performance in a small, compact form factor. Rated IP66/IP67 and IK10 for weather and vandal resistance, the camera can function in hard outdoor conditions. Equipped with Power over Ethernet, the Compact Mini-Dome reduces installation costs by eliminating the need for power cabling.
