Ajax Relay radio channel controller

Technical Specification

Features:
  • Make: Ajax
  • Model code: Relay
  • Relays: Yes
  • Voltage: 7 ~ 24 V DC
  • Dimensions mm: 39 х 33 х 18
Additional info:

Radio channel controller for remote control of low current equipment. It is used to activate electric locks, gates and swing gates, rolling shutters and blinds, and to restart modems and routers. Principle of operation The device controls electric power supply by means of relay, which closes and opens the dry contact. Features Operates from 7—24 V DC voltage sources. The dry contact is not galvanically connected to the device itself. Installation and set up The device is installed in junction boxes, distribution boards, and enclosures of switching units.

Read more
Make Ajax
Manufacturer Ajax Systems
Model code Relay
Relays Yes
Electrical Specifications Voltage: 7 ~ 24 V DC
Physical Specifications Dimensions mm: 39 х 33 х 18
Environmental Specifications OperatingTemp oC: 0 ~ 64 C (32 ~ 147 F)
Protection: IP20
Additional info

Radio channel controller for remote control of low current equipment. It is used to activate electric locks, gates and swing gates, rolling shutters and blinds, and to restart modems and routers.

Principle of operation

The device controls electric power supply by means of relay, which closes and opens the dry contact.

Features

Operates from 7—24 V DC voltage sources. The dry contact is not galvanically connected to the device itself.

Installation and set up

The device is installed in junction boxes, distribution boards, and enclosures of switching units.
