HID EHRP40-K single door networked access controller

Technical Specification

Features:
  • Make: HID
  • Model code: EHRP40-K
  • Series: EDGE EVO
  • Controller Type: Networkable
  • Max No. of Doors per Controller: single
Read more
Additional info:

As part of HID Global’s networked access solutions family, the EDGE EVO® EHRP40-K controller/reader and interface module package is a single-door access control panel with reader and separate discrete door interface that enables cost effective installation and high performance access control functionality. The EHRP40-K controller/reader is installed at the door, and the included Hi-O interface module is mounted separately in a secure location.

Read more
Make HID
Manufacturer HID Global
Model code EHRP40-K
Series EDGE EVO
Controller Type Networkable
Max No. of Doors per Controller single
Networkable Yes
Universal / Wiegand Reader Interface Yes
Electrical Specifications Voltage: 12 VDC
Power Consumption: 18W
Physical Specifications Dimensions mm: 84 x 122 x 31
Weight g: 180
Environmental Specifications Operating Temp oC: 0 ~ 50
Operating Humidity %: 5 ~95
Additional info

As part of HID Global’s networked access solutions family, the EDGE EVO® EHRP40-K controller/reader and interface module package is a single-door access control panel with reader and separate discrete door interface that enables cost effective installation and high performance access control functionality. The EHRP40-K controller/reader is installed at the door, and the included Hi-O interface module is mounted separately in a secure location.
