Vanderbilt HFG500E Access control reader

Technical Specification

Please note: this is a discontinued product.

Go to Replacement product

Vanderbilt HFG500E Access control reader

Features:

Make: Vanderbilt
Model code: HFG500E
Reader Type: Proximity
Standalone/ Networkable: Standalone
IP Rating: IP64

Additional info:

Frosted Glass Extended Reading Head supplied with a 5270 Integrated Loop Reader ensures easy intergration into most host systems. Suitable for screening customer logo for corporate reception areas etc. Compatible with all Cotag Technology Active and Passive cards & tags. Transmit range adjustment. Easy monitoring of TX & RX status via onboard LEDs. Suitable for screening with corporate logo's etc. Reads through all non-metallic materials. Flexable, easy configuration, compatible with most OEM access control systems.

Contact manufacturer Contact manufacturer

Make	Vanderbilt
Manufacturer	Vanderbilt Industries
Category	Access Control>Access control readers
Model code	HFG500E
Reader Type	Proximity
Standalone/ Networkable	Standalone
IP Rating	IP64
Read Range mm	800 mm
Electrical Specifications	Voltage: 12 V DC Power Consumption: 350 mA
Physical Specifications	Dimensions mm: 300 x 1000 x 9 Weight g: 7.1 kg
Environmental Specifications	Operating Temp ^oC: -40 ~ +70
Additional info	Frosted Glass Extended Reading Head supplied with a 5270 Integrated Loop Reader ensures easy intergration into most host systems. Suitable for screening customer logo for corporate reception areas etc. Compatible with all Cotag Technology Active and Passive cards & tags. Transmit range adjustment. Easy monitoring of TX & RX status via onboard LEDs. Suitable for screening with corporate logo's etc. Reads through all non-metallic materials. Flexable, easy configuration, compatible with most OEM access control systems.
