Takex PB-30TK Intruder detector Specifications

Takex PB-30TK Photoelectric Beam Sensor

Technical Specification

Features:

Make: Takex
Model code: PB-30TK
Series: PB-TK Series
Infra Red Beams: Yes
Coverage/ Range m: 30m / 100ft

Additional info:

2 x Synchronised high power beams Double modulation for unsurpassed light immunity Auto-gain control (AGC) 50,000 lux sunlight immunity IP55 housing

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Takex
Manufacturer	TAKEX Europe Ltd.
Category	Intruder Alarms>Intruder detectors
Model code	PB-30TK
Series	PB-TK Series
Infra Red Beams	Yes
Coverage/ Range m	30m / 100ft
Electrical Specifications	Power Supply: 10 ~ 30 V DC
Download PDF version Download PDF version

Make

Takex

Manufacturer

TAKEX Europe Ltd.

Category

Intruder Alarms>Intruder detectors

Model code

PB-30TK

Series

PB-TK Series

Infra Red Beams

Yes

Coverage/ Range m

30m / 100ft

Electrical Specifications

Power Supply: 10 ~ 30 V DC

Download PDF version Download PDF version

Product description

The Takex PB-30TK is an advanced photoelectric beam sensor designed to deliver exceptional security performance in various environments. With outdoor coverage of 30 metres (100 feet) and indoor coverage of 60 metres (200 feet), this sensor ensures robust intrusion detection. Known for its reliability, the PB-30TK utilises unique synchronised twin beams which enhance range and stability, even under adverse weather conditions. This technological synergy reduces false alarms typically caused by environmental factors like flying birds or falling leaves.

Key Features

Insect Protection: A sealed optical system prevents interference by insects.
Light Protection: The advanced filter cuts visible rays, ensuring excellent operation despite fluctuations in external light, including sunlight and headlights.
Frost/Dew Prevention: Special hoods on the sensor maintain beam protection, even in frost conditions.
Installation Ease: Features like a rotary optical system and a special viewfinder assist in quick alignment and flexible mounting.
Additional Components: Automatic Gain Control circuit and broad adjustment angles support varied installation scenarios.

Ideal Use Cases

Ideal for securing perimeters in both commercial and industrial settings, the PB-30TK provides peace of mind by effectively detecting intrusions without the interruption from common environmental challenges. Its robust design and extensive features make it suitable for high-security applications both indoors and outdoors.
