Designed for Request-to-exit (REX) applications Provides PIR 2.4 m x 3 m (8 ft x 10 ft) coverage, timers, door monitor with sounder alert, and pointable coverage Sequential Logic Input (SLI) Internal vertical pointability Wrap-around coverage pattern with precise pattern control Up to 64 second adjustable latch time

Bosch DS1102i-CHI glassbreak detector uses microprocessor-based sound analysis technology (SAT) to listen for the specific frequencies associated with breaking glass. The detector can be used to detect breakage of plate, tempered, laminated and wired glass types. A built-in environmental test feature alerts the installer to false alarm hazards in harsh environments. The square detector mounts on the ceiling or walls. For use in China.

Lead battery Shock-resistant plastic enclosure Dry-cell battery Can be used irrespective of its position Low self-discharge Can be used for intrusion alarm systems according to DIN EN 50131-1

The ceiling mount, low profile panoramic DS936 PIR Detector uses alternate polarity pulse count. It also uses a pointable Fresnel lens to provide up to 7.5 m (24 ft) of coverage and can be mounted on the surface, or semi-flush directly to a ceiling or a standard octagonal electrical box. External visible alarm LED. Internal noise voltage test pins provide precise pattern location and background disturbance evaluation using a standard analog meter.

Bosch ZX938Z is a panoramic PIR detector with internal POPIT. It uses  Motion Analyzer II processing to reduce false alarms. Several unique self-test features, including Motion Monitor, provide coverage integrity. Field replaceable mirrored optics allow the detector to be mounted on ceilings.

Bosch ISC-BPR2-W12-CHI PIR motion detector uses two Fresnel lenses designed to produce sharply focused images throughout the field of view providing superior response to intruders. These lenses provide a high density (77 zone) 7-layer pattern, and the selectable lookdown lens provides an additional three lookdown zones. Flexible mounting height reduces installation time and false alarms as well as improves catch performance.

Bosch DS936-FRA is a ceiling mount, low profile panoramic PIR detector. It uses alternate polarity pulse count and a pointable Fresnel lens to provide up to 7.5 m (24 ft) of coverage and can be mounted on the surface, or semi-flush directly to a ceiling or a standard octagonal electrical box. For use in France.



Bosch ISC-PPR1-W16 PIR detector is suited for commercial indoor applications. The sensor data fusion technology ensures that the detector sends alarm conditions based on precise information. Tri-focus optics eliminate coverage gaps and respond efficiently to intruders. The powerful combination of unique features in the detector delivers superior catch performance and virtually eliminates false alarms. The self-locking two-piece enclosure, built-in bubble level, flexible mounting height, and three optional mounting brackets simplify installation and reduce service time.

Bosch DS455Q photoelectric detector provides an outdoor range of 160 m (525 ft), indoor range 320 m (1050 ft). It has separate transmitters and receivers. The transmitter emits an invisible infrared beam to the receiver. If the beam is broken, the receiver signals an alarm. The DS455Q uses four pulsed infrared beams that are designed to activate an alarm only when all four beams are simultaneously blocked. It also features interlocked upper and lower beams, signal voltage LED, and selectable environmental discrimination circuitry.

Bosch DS486Q photoelectric detector provides an outdoor range of 200 m (660 ft), indoor range 400 m (1320 ft). It has separate transmitters and receivers. The transmitter sends an invisible infrared beam to the receiver. If the beam is broken, the receiver signals an alarm. Multiple channel operation provides increased system flexibility.

Uses a combination of passive infrared (PIR) and microwave detection technologies with advanced signal processing 12 m x 12 m (40 ft x 40 ft) coverage Frequency: 10.510 to 10.580 GHz Dynamic Temperature Compensation – superior catch performance in any environment Microwave Noise Adaptive processing – reduce false alarms from repetitive sources Wall to Wall Coverage – superior catch performance Flexible Mounting Height, No Adjustments – reduce installation time and false alarms, improve catch performance

The ISC-PPR1-WA16x professional Series PIR detectors with anti-mask are exceptionally suited for commercial indoor applications. MANTIS anti-mask technology makes obscuring the detector view nearly impossible for intruders. Microwave assist technology provides additional input into the sensor data fusion signal processing algorithm to improve alarm decisions when PIR signals are similar to false alarm sources

UHD “4K” resolution (3840 x 2160 pixels) @ 30fps, 12x zoom with Optical Image Stabilization (OIS) AI-based traffic detection for traffic monitoring (no camera calibration required) Open platform that allows third-party apps from the Application store from Azena Flexible streaming capabilities powering three independent streams Exceptional strength and ruggedness for any outdoor application including traffic monitoring (bridges, tunnels, or highways), perimeter protection, city surveillance, and mining

The Professional Series TriTech Curtain Detectors are exceptionally suited for commercial indoor applications. Sensor data fusion technology ensures that the detector sends alarm conditions based on precise information. The powerful combination of unique features in the Professional Series delivers superior catch performance and virtually eliminates false alarms. The self-locking two-piece enclosure, built-in bubble level, flexible mounting height, and three optional mounting brackets simplify installation and reduce service time.

AI-based traffic detection for traffic monitoring (no camera calibration required) Open platform that allows third-party apps from the Application store from Azena Starlight camera technology with excellent lowlight sensitivity (colour = 0.0047 lx) and High dynamic range (120 dB) (to see details in bright and dark areas simultaneously) Flexible streaming capabilities powering three independent streams Edge intelligence and object detection even when the camera is moving

Easy-to-install standoff location for mounting supported modules Made with cold-rolled steel with a white semi-gloss finish Easy access locations for battery placement Optional tamper switch mounting location

For monitored connection of conventional detectors (2 primary lines) on the local security network LSN The point type can be programmed in the control panel Onboard internal EOL 12.1 kΩ resistors The circuit board is equipped with a tamper contact

Bosch Security Systems has become one of the first companies to seek tests by independent accredited laboratories based on new European EN 50131 standards for intrusion alarm products.The new standards have been introduced by CENELEC (European Committee for Electrotechnical Standardisation) to meet growing demands for EN compliant products from users and installers of security systems.  The European standards will gradually replace existing national standards within Europe, and will also extend to European countries that currently do not have an established standard of their own.  The aim of the new EN standards is to guarantee a consistently high level of performance for electronic security systems throughout Europe.Commenting on the independent testing, Darren Cox, Intrusion Product Manager for Bosch Security Systems said, "For these new standards to gain credibility and become widely accepted throughout the industry, it is essential for products to be tested by independent laboratories and not by the manufacturers themselves.  A self-declaration of compliance to EN 50131 provides absolutely no guarantee of product quality or product features.  For this reason, many national laboratories such as CNPP (Centre Nationale de Prevention et de Protection) in France, VdS in Germany and ANPI in Belgium have already initiated product testing based on the available EN standards and Technical Specifications."Bosch is a strong supporter of the EN 50131 standards as an important quality label on which installers, distributors and end-users can rely, and we are one of the first companies to submit products for independent compliance testing.""The CNPP laboratories in France have recently tested the Bosch Blue Line and Tri Focus Professional Series motion detectors as well as its wLSN wireless technology and Easy Series alarm panel for EN 50131 compliance.  All products submitted passed the relevant tests.  The test reports are available on request to provide a guarantee of product quality," adds Paul, "which is not solely based on a self-declaration but on rigorous testing by an independent organisation."Currently, requirements and test procedures are available for alarm systems (EN 50131-1), passive IR detectors (EN 50131-2-2), passive IR/microwave detectors (EN 50131-2-4), alarm panels (EN 50131-3), warning devices (EN 50131-4), wireless links for alarm systems (EN 50131-5-3) and power supplies (EN 50131-6).  Opening Contacts (TS 50131-2-6) and Combined PIR / ultrasonic detectors (TS 50131-2-5) are in preparation to be published as EN - Standards.  Others will follow, including requirements for transmission systems and related products for alarm systems.Bosch has expressed a commitment to submit all its intrusion-detection products for EN 50131 compliance as and when the requirements for these other products are issued.

Bosch TP161 is a black trim plate used when mounting the sensor over a standard single-gang box.

Uses a combination of passive infrared (PIR) and microwave detection technologies with advanced signal processing 6 m x 6 m (20 ft x 20 ft) coverage Frequency: 10.525 GHz Pet‑friendly – optimise installation for pet (45 kg [100 lb]) and non‑pet applications Dynamic Temperature Compensation – superior catch performance in any environment Microwave Noise Adaptive processing – reduce false alarms from repetitive sources Wall to Wall Coverage – superior catch performance Flexible Mounting Height, No Adjustments – reduce installation time and false alarms, improve catch performance

Easy-to-install standoff location for mounting supported modules Made with cold-rolled steel with a gray finish Easy access locations for battery placement Optional tamper switch mounting location Use the enclosure for residential fire and burglary installations and commercial burglary applications that do not require attack resistance

Water and dust resistant Sends panic alarms by user for unique identification Two-button version, reduces false activations Supervised for low battery and removal from monitored areas

Flexible design accommodates a number of input, output and receiver modules Supports modules with circuit boards with either through‑hole or three‑point mounting systems Mounts to multiple gang box types

Water and dust resistant Sends panic alarms by user for unique identification Single-button version, reduces false activations Supervised for low battery and removal from monitored areas

Blue Line Gen 2 Motion detectors include the passive infrared (PIR), the Quad PIR detectors and the TriTech detectors that combine PIR and microwave technologies for more advanced analysis. All models use an interchangeable mounting base, enabling easy upgrades to more advanced detection technology in areas prone to false alarms. In addition, pet-friendly models can be set to “No Pet” to allow customers to use the same product in multiple applications, reducing inventory for security dealers. For easy installation, the self-locking, two piece enclosure, integrated biaxial bubble level and removable terminal strip in the base reduce mounting time to mere seconds. The commercial grade terminal strip is designed to prevent incorrect wiring and eliminate future service calls. A flexible mounting height allows the detectors to be positioned from2.3 to 2.7 meters (seven to nine feet) without adjustment, assuring no coverage gaps up to twelve meters (40 feet) away from the detector. Pet-friendly Selectable model available – optimize installation for pet (20 kg [45 lb]) and non-pet applications Dynamic Temperature Compensation – superior catch performance in any environment Wall to Wall Coverage – superior catch performance Flexible Mounting Height, No Adjustments – reduce installation time and false alarms, improve catch performance Self-locking Enclosure with Integrated Bubble Level – reduce installation time

A rechargeable 12 VDC sealed lead‑acid power supply used as a secondary power supply or in auxiliary or ancillary functions Maintenance‑free Long service life Suitable for supplying backup power for fire, security, and access control systems during AC power failures

AI-based traffic detection for traffic monitoring (no camera calibration required) Open platform that allows third-party apps from the Application store from Azena Starlight camera technology with excellent lowlight sensitivity (colour = 0.0047 lx) and High dynamic range (120 dB) (to see details in bright and dark areas simultaneously) Flexible streaming capabilities powering three independent streams Edge intelligence and object detection even when the camera is moving
