Technical Specification

Features:
  • Make: Everfocus
  • Model code: EFD 300 A
  • Chip Inch Size: 1/3
  • Colour Type: Colour
  • Resolution TVL: 480
Read more
Make Everfocus
Manufacturer EverFocus Electronics AG
Model code EFD 300 A
Chip Inch Size 1/3
Colour Type Colour
Resolution TVL 480
Sensitivity lux 0.4
Dome Type Variable Focus
Mount Type Ceiling
Electrical Specifications Voltage: 12 V DC / 24 V AC
Power Consumption: 200 ~ 300 mA
Focal length 4 ~ 9
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/50 ~ 1/100,000
S/ N (Signal/ Noise) Ratio dB > 48
Synchronisation Internal
Signal Mode PAL
Video Output 1 Vp-p, 75 Ohms
Physical Specifications Dimensions mm: 135 (Dia) x 112
Weight g: 460
Environmental Specifications Operating Temp oC: 0 ~ 50
