Bosch CCTV Camera wipers, demisters & heaters

The term ‘marine’ comes from the Latin mare, meaning sea or ocean, and marine habitats can be divided into two categories: coastal and open ocean. Video surveillance (VS) applications can cover both types of marine environment with system for ships, maritime ports, onshore and offshore installations, etc. We should want to further analyse VS for ships and try to explain the types of ships on which it can be used, the ways in which VS can be used on ships, the typical certifications in use and what features a camera station must have to be installed on a ship. Starting with ships that have a minimum tonnage, around the world we have: liquefied natural gas (LNG) tankers, passengers ships, chemical tankers, crude oil tankers, container ships, general cargo ships and bulk carriers.As the LNG market grows rapidly, the fleet of LNG carriers continues to experience tremendous growth, offering more opportunities for VS Video surveillance for all marine vessels An LNG carrier is a tank ship designed for transporting liquefied natural gas. As the LNG market grows rapidly, the fleet of LNG carriers continues to experience tremendous growth. A passenger ship is a merchant ship whose primary function is to carry passengers by sea. This category does not include cargo vessels which have accommodation for a limited number of passengers, but rather includes the likes of ferries, yachts, ocean liners and cruise ships. A chemical tanker is a type of tank ship designed to transport chemicals in bulk. These ships can also carry other types of sensitive cargo which require a high standard of tank cleaning, such as palm oil, vegetable oils, tallow, caustic soda and methanol. An oil tanker, also known as a petroleum tanker, is a merchant ship designed for the bulk transport of oil. There are two basic types of oil tankers: crude tankers and product tankers. Crude tankers move large quantities of unrefined crude oil from its point of extraction to refineries. Product tankers, generally much smaller, are designed to move refined products from refineries to points near consuming markets. Container ships are cargo ships that carry their entire load in truck-size intermodal containers: a technique called containerisation. They are a common means of commercial intermodal freight transport and now carry most seagoing non-bulk cargo. Today, about 90% of non-bulk cargo worldwide is transported by container. A cargo ship or freighter ship is any sort of ship or vessel that carries cargo, goods and materials from one port to another. Cargo ships are specially designed for the task, often being equipped with cranes and other mechanisms to load and unload, and come in all sizes. Bulk carriers make up 15%–17% of the world's merchant ships and they are specially designed to transport unpackaged bulk cargo such as grains, coal, ore and cement in its cargo holds. For all these ships the protection of vessels, cargo and crew is a priority, that’s why the adoption of VS technology plays a key part in terms of security and safety. Human error is regularly named as a major factor in ship accidents, and one way to avoid it is to aid seafarers by providing them with technology and equipment that is reliable and easy to use in all weather and sea conditions. Marine VS encompasses liquefied natural gas (LNG) tankers, passengers ships, chemical tankers, crude oil tankers, container ships, general cargo ships and bulk carriers Emergency security solutions on ship One of the most important applications for camera stations is during “docking”. Mooring is the securing or confining of a vessel in a particular location with a fixed or a floating object (jetty, pier, ship, barge, buoy, etc.) as various cargo operations are carried out. Docking is the final stage of mooring operations when the ship docks to the jetty. This is a very delicate operation and cameras are very helpful in making sure docking is done without accidents.'Man overboard’ is an emergency in which a person has fallen off a boat or ship into the water, and can happen at any time during the day or night Another important application for camera stations is the Man Overboard detection system (MOB). ‘Man overboard’ is an emergency in which a person has fallen off a boat or ship into the water. Man overboard events can happen at any time during the day or night, in all types of weather and sea conditions, and from almost any location on the ship, ranging from a few tens of feet above the water, to over 180 feet.  When these events occur, the immediate availability of important data is crucial. Accurate confirmation of the event including time of occurrence, location on the ship and location in the sea is critical. A proactive detection system must immediately and accurately detect man overboard events and provide prompt, actionable data to response personnel. A typical man overboard detection system can report a MOB event in under 1 second. VS on a vessel can also monitor the engine room at all times and provide a good view of people working on dock, machinery and stowed equipment. But what are the most important features that a camera station must have to work in one of the most aggressive environments in nature? Marine surveillance must operate in one of the most harsh environments in nature Ruggedised reliability in surveillance First of all, and perhaps it’s obvious, but it’s extremely important to have camera stations with amazing reliability. Housing units manufactured from AISI 316L stainless steel, passivated and electropolished, makes the cameras completely impervious to air, water, rusting and corrosion, therefore offering excellent weather protection and increased reliability. Housing units manufactured from AISI 316L stainless steel, passivated and electropolished, makes the cameras completely impervious to air, water, rusting and corrosion Sometimes ships also use cameras constructed entirely from technopolymer, which guarantees high impact resistance and superior protection from external weather agents. Keeping the camera glass clean at all times is another essential feature, and it can be done via a wiper/wash system that greatly reduces the need for maintenance. In the case of PTZ cameras, the best option would be a great pan and tilt speed (up to 100°/s). What is the operative temperature range for the cameras? Sea is everywhere and therefore ships go everywhere, from the Arctic Ocean to the Mediterranean, so we need cameras that have to be fully operational across a wide temperature range.  -40°C to +65°C covers almost all areas. Analogue or IP Cameras? Actually, both options can be used, especially for applications like docking where it’s important to avoid image delay (as can happen with IP cameras due to the natural latency of data communication over a network). Marine certifications Last but not least, the certifications: Certifications guarantee the quality and reliability of camera stations. There is no compromise! One important certification is the Lloyd’s Register Type Approval which subjects cameras to rigorous testing for performance, vibration (critical on ships), humidity, etc. The application field of the LR Type Approval is VS in public places (e.g. passenger ships), open decks, enclosed spaces that are subjected to heat generated from other equipment, and technical premises. Often, VS cameras used in specific areas of ships, such as hazardous areas, are required to have ATEX and IECEX certifications.

Standards for camera manufacturers presented a new challenge with the introduction of security cameras that require more than 30 Watts of power Standards for camera manufacturers presented a new challenge with the introduction of security cameras that require more than 30 Watts of power. Many of these involve pan-tilt-zoom (PTZ) domes and heaters and blowers that require additional power. This development created two areas of confusion which is highlighted in this article by Neil Heller - Vice President, Vigitron. The first is the ability to define what a 60-watt camera is and what power sources are actually required. The second and more serious is how to provide that power. Both share a commonality in that they lack any form of standardisation. PoE to power 60-watt security camera alone? Let’s start with the definition of the 60-watt camera. As the term suggests, it requires 60 watts or greater, but that doesn’t necessarily mean all the required power comes from a single PoE source. In many cases, camera manufacturers require that PoE only power the camera itself. Looking at these cameras’ power specifications will indicate a required PoE power of 802.3at or 30 watts, thus leaving power to the heaters and blowers requiring a local AC power source. This situation brings into question the value of PoE power if it is restricted to only providing camera power. Another group of PTZ cameras does use PoE for both camera and heater/blower functions, but only when the heater operates within a restricted temperature range. This usually means if your camera is installed in areas where the temperature that can fall below -20 degrees C (approximately -20 degrees F) you will still need a local power AC power source. The third type of security camera relies only on PoE power for both PTZ and heater blower operations.  This is confusing, and is often the source of users finding their PTZ has failed at the most inopportune time. Any attempt to transmit 60 watt power over coax cable that is only a single pair should be considered with a great deal of caution, requesting from the transmission equipment provider that they will accept liability for any damages PoE for greater than 30 Watt applications The three different operations of how these “PoE” cameras are powered brings into question the value of using PoE for greater than 802.3at, 30 Watt applications. Value exists in the ability to centrally control power operations from a single accessible point. Certainly those cameras that are solely dependent upon PoE have the greatest advantage. This brings to the second point of confusion, the composition of the PoE power. To review a brief history, 802.3af (15.4) was the first PoE standard used for IP cameras and is for the most part a standard. 802.3at (30 Watts) was introduced as four different standards, two of which, Type 1 and Type 2 are supposed be compatible, but in reality are not.     Transmission restriction over physical cables 60 watts has no standards. To understand this, we need to look at the limitations of transmitting power over physical cables. Any form of transmission over a physical media has limitations in the form of resistance. As resistance increases, so does the heat generated by this process. The higher the power, the greater the resistance and resulting heat generated. Based on CAT5e cable, a single wire can handle about 0.75 amps. In PoE transmission, power is transmitted on a pair of wires or 0.75amp X 2= 1.5amps.  According to the 802.3at specifications, Class 4 specifications generally are considered to start around 48 volts. So we take 48 x 0.75= 36 watts or 72 watts for the pair. Dual PD (power device) system So how do we get to 60 watts? For “over” 30 watts, camera manufacturers use a dual PD (power device) system. In short, it operates as if it where two IP cameras and requires use of all four pairs within Cat cabling. Exceeding these power limits can be dangerous in overheating the cable and its installation. Therefore, any attempt to transmit 60 watt power over coax cable that is only a single pair should be considered with a great deal of caution, requesting from the transmission equipment provider that they will accept liability for any damages. The need to operate two PDs within a single camera is where the incompatibility exists. There are no standards as to the sequence of turning on  separate PDs in a single camera The need to operate two PDs within a single camera is where the incompatibility exists. There are no standards as to the sequence of turning on separate PDs in a single camera. Most such camera manufacturers provide their own PoE source in the form of a PSE or camera power supply; however, don’t try to interchange these power sources among different cameras from different manufacturers as they will not work. If you attempt to use a third party version, make certain you confirm that the power source manufacturer has actually conducted certification testing and can provide proof of compatibility or provide any operational limitations. Distance of transmission Finally, there is the question of transmission distance. This takes us back to the physics of high-powered PoE transmission. Even with manufacturer-supplied PSEs, the distance limitation is still 328 feet (100m), the Ethernet standard. Most applications such as perimeter and parking lots will be hard pressed to find a power outlet within 328 feet of where the cameras needs to be installed. This is where third-party transmission equipment providers come into play, but again the ability of transmitting 60 watts PoE power for distances greater than 328 is more complex that standard 802.3af and 802.3at, and more limited. This combined with the non-standard make a detailed knowledge and interaction with the manufacturer critical to a successful installation.

Located in the South East of England, Basingstoke and Deane is a local government district and borough in the county of Hampshire. With Basingstoke as its largest town, the area is known for family-friendly living and is home to over 175,000 people. Basingstoke and Deane Borough Council consists of 60 elected members who discuss local politics, municipal budgets and taxes at regular meetings. For full transparency with the members of their constituency, the council streams live video of all its meetings, including public votes, on their YouTube channel. Automatic camera control To ensure a high level of video production, the Borough Council decided to upgrade their conference system. After discussing their requirements with Andover-based system integrator VP Bastion, a fully IP-based DICENTIS Conference System from Bosch was installed. The system meets the council’s key priorities by offering the highest audio quality, full integration of live voting, built-in automatic camera control and direct streaming with speaker-name indication. Council members wanted the freedom to sit anywhere in the council chamber during council sessions Additionally, council members wanted the freedom to sit anywhere in the council chamber during council sessions – while still being automatically identifiable on camera – and the installation needed to accommodate for the limited desk space and cabling voids. The system includes 63 DICENTIS Discussion devices with touchscreens (to support the required voting and identification capabilities for council members), nine DICENTIS discussion-only devices for guest speakers, and automatic camera control software. High directive microphones All the discussion devices are mounted on raised brackets to maximise desk space and are equipped with high directive microphones to deliver crystal-clear audio. Council members have the freedom to sit at any seat in the meeting room, as the system automatically registers their presence at a specific location thanks to the NFC (Near Field Communication) card registration on the discussion devices. When a speaker activates its microphone, the system’s automatic camera control points the camera towards their location, zooming in and displaying their image on the big screen. Additional features were added to the installation thanks to DICENTIS’ compatibility with third-party software. Two companies – Arbor Media, European market leader in conference recording and streaming services, and MVI Engineering, expert in creating conference software solutions – worked together to create a webcasting and conference control software package that was integrated with the DICENTIS system. Integrated conference system The new DICENTIS system has supported a seamless and transparent democratic process This solution helped to fulfil all the Borough Council’s requirements, including report generation via live image feed and identification by name and party affiliation on the council’s YouTube channel. In addition to displaying the DICENTIS-enabled voting results on the council chamber’s big screen, it is now possible to share the voting results on the YouTube Live feed. Since the installation, the new DICENTIS system has supported a seamless and transparent democratic process at Basingstoke and Deane Borough Council. “Having a fully integrated conference system with audio-video feeds from meetings automatically streamed to the council’s YouTube channel was a must,” says Iain Steele, Director of VP Bastion. Behind the scenes, via the third-party MVI Engineering application, the system automatically upgrades to the latest software versions. These centralised updates save time and operating costs. With the potential to increase the system’s functionality and size in the upcoming years, the council has a future-proof and expandable conference solution from Bosch, which already supplies around 50 percent of councils in the United Kingdom and Ireland.

With roots dating back to the year 1948, Italian pharmaceutical company Alfasigma is dedicated to advancing the state of healthcare under the company motto, ‘Pharmaceuticals with Passion’. Headquartered in Bologna, the multinational corporation was created in 2017 by the merger between Alfa Wassermann and Sigma-Tau. As a result, Alfasigma now employs about 3,000 people and markets a wide range of therapeutic drugs in 18 countries including the US, China, Russia and several European countries with annual revenues of EUR 1.06 billion. In order to keep up with the company’s ongoing evolution while emphasising building protection, Alfasigma decided to update the infrastructure of its corporate offices in Milan and Bologna. This large-scale remodelling project also required updating the fire alarm, intrusion detection and video security systems at both facilities to the highest standards. Security cameras for outdoor surveillance On the exterior of the buildings, FLEXIDOME IP starlight 7000 VR cameras were installed to provide 24/7 securityAssuming a long-term perspective, Alfasigma management headed into the project with three key requirements: First, saving cost by refurbishing already installed system components such as intrusion and fire alarm detectors. Second, accommodating for future building expansions and saving additional costs by installing a future-proof and scalable system. And third, adding around-the-clock security to the building’s exterior through modern security cameras built for outdoor use. For this reason, Alfasigma commissioned Bosch as the one-stop provider to equip the Milan office – home to the International Division – as well as corporate headquarters in Bologna with an IP-based solution. The video security set-up includes high-definition DINION IP 5000 HD cameras connected to recording stations and offering 1080p resolution images at 30 fps. On the exterior of the buildings, FLEXIDOME IP starlight 7000 VR cameras were installed to provide 24/7 security. Recording at 1080p and 60fps, the cameras incorporate starlight technology to deliver relevant images even in challenging light conditions. Extremely weather-resistant, water-tight and able to withstand high impacts, the cameras are highly suited for outdoor use, confirmed by IP66, NEMA type 4X and IK10 rating and installation in mission-critical environments such as airports and government buildings worldwide. MAP 5000 installed with LSN detectors The new fire alarm system is interfaced with the voice alarm system Plena via Smart Safety Link“The video surveillance products are excellent and have impressed me the most. We are very satisfied, above all, with the high quality of the products,” said Stefano Borsarini, Facility, Maintenance and EHS Manager at Alfasigma facilities in Bologna and Milan. The cameras are supplemented by the intrusion panel Modular Alarm Platform MAP 5000 installed with LSN detectors – a large portion refurbished from the legacy system – to safeguard Alfasigma’s offices at night. Fire alarm is provided by the Modular Fire Panel 5000 Series with four loops, processing signals from 190 fire alarm detectors and 28 manual call points. The new fire alarm system is interfaced with the voice alarm system Plena via Smart Safety Link thus optimising the operational security via a monitored connection. Successfully installed and customised according to client specifications, the Bosch fire alarm, intrusion detection and video security solution maintains the safety of Alfasigma’s employees and property at both sites. It also fulfils the key customer requirement of accommodating for future expansions in a modular, IP-based system that is able to keep pace with Alfasigma’s rapid evolution as an innovative multinational company.

Decades of experience, innovative ideas, a strong commitment to quality, and a full range of first-class offset printing services: Mohn Media Mohndruck GmbH, a company of the Bertelsmann Printing Group, is one of Europe’s providers of printing and media services. At its facility in Gütersloh, Germany, some 2,000 employees are involved in professionally creating and executing tailored solutions for customers across a variety of industries. To avoid endangering staff and production, the company also has extremely high standards where the plant’s safety and security are concerned. And Bosch has supported the print specialists with advanced technology and services through multiple system generations. Cutting-edge solution The latest new project involved implementing a networked solution to improve fire safety “Again and again, we’ve been impressed by the innovative solutions that Bosch comes up with for us,” says Jörg Naumann, who heads the company’s fire brigade. “Bertelsmann has been partnering with Bosch for over 35 years, and for good reason.” The latest new project involved implementing a networked solution to improve fire safety in the eight-meter-high waste paper warehouses. On average, around 300 tons of paper are stored there at any given time. Problems in waste paper removal would directly impact production. To enable prompt responses to any fire events in these sensitive areas, the Bosch experts planned and implemented a cutting-edge solution. Fire detection system AVIOTEC, the first video-based fire detection system to be certified by VdS Schadenverhütung GmbH (the VdS is an independent, renowned institution for enterprise safety and security, and harmonised body for international safety standards) plays a key role in it. Intelligent algorithms directly integrated in cameras reliably detect the first signs of any smoke or flame. This technology detects fires at their source much more reliably than conventional detectors Particularly in challenging large-volume buildings, this technology detects fires at their source much more reliably than conventional detectors, which are not triggered until smoke reaches them. The data generated by the new fire protection solution come together in the Bosch Video Management System. If AVIOTEC identifies a potentially dangerous situation in any of the waste paper warehouses, it immediately alerts the continuously staffed emergency service desk of the plant fire brigade. Building integration system The situation can then be checked on a video screen and appropriate steps will be initiated. The use of this innovative technology permits very early detection of any fires. This prevents major damage and resulting production downtimes, thus saving the company a great deal of time and money. To additionally enhance security and efficiency, all of the integrated on-site systems for fire protection and video security are managed by the Building Integration System from Bosch. As required, the security systems can be centrally or locally monitored and controlled by staff as appropriate. Not only Mohn Media benefits from this, but also all of the other companies of the Bertelsmann Printing Group operating at the same site.
