CCTV Storage System / HDD

By 2020, video surveillance using fixed, body and mobile cameras is expected to capture an astounding 859 PB of video daily. Increasing retention regulations and higher resolution cameras, are forcing the video surveillance industry to reassess its approach to data storage. Large capacity primary storage tends to be expensive to procure and costly to implement – especially without a sound architecture that can balance storage performance levels with the speed of access needed to recall video footage. Active archive strategy These challenges are thrusting storage tiers to the forefront of system design. Storage tiers in video surveillance had previously meant simply using a separate archive or attaching add-on capacity directly to network video recorders. Many of the new storage options designed for video surveillance are pulling together different storage tiers into a single storage architecture Many of the new storage options designed for video surveillance are pulling together different storage tiers (and in some cases storage media) into a single storage architecture, such as an active archive solution. This balance can be achieved with an active archive strategy that automates migration of data between different storage types, to ensure the data is on the correct storage type at the correct time to meet performance and retention requirements without blowing the budget. This approach also ensures ease of access while automatically moving content from more expensive tiers of storage to more cost-effective long-term tiers of storage. This allows for greater efficiencies in how recorded footage is treated throughout its lifecycle. In some cases, it includes moving data from edge devices to centralised storage, and then to the public cloud. Scalable video storage solutions As storage demands have increased, video management vendors have turned to storage specialists for solutions that can accommodate large numbers of high-resolution video files, metadata associated with the footage for easy searching, along with much needed scalable solutions. In terms of video management software, this means the integration of video content from different storage types, tiers and physical locations is required, and which considers the performance profile of each storage type. With an active archive solution, video content is searchable and accessible directly by the end users regardless of where it is stored. Deploying an active archive solution enables surveillance users to reduce the complexity and costs of managing data for long term retention As seen in many product categories, camera and storage vendors continue to provide extremely competitive offerings. But, storage-specific solutions for video surveillance have lagged behind the roadmaps for video equipment and, as more and more cameras have entered the market, less attention has been placed on video storage capacities. Tiered storage strategy The surveillance industry has evolved considerably from the days of the 8mm video recorder; however, enterprise storage solutions will be forced to evolve further to cope with changing storage retention requirements. Video storage is quickly becoming one of the most expensive parts in a surveillance solution, but there is hope. Deploying an active archive solution will enable surveillance users to reduce the complexity and costs of managing from terabytes to petabytes of data for long term retention. By finding a storage solution that delivers the ability to implement a tiered storage strategy, users can adhere to regulation requirements to retain video footage and meet their safety and security objectives, while also significantly reducing storage costs and operational expenses.

In the physical security space, video analytics have historically over-promised and under-delivered, often leaving end users sceptical about their capabilities. However, increased integration with security solutions and other business systems, as well as developments in deep learning and artificial intelligence (AI), have given video analytics a significant boost in recent years. Here, we take a look at the key trends putting video analytics in the spotlight, and how this opens up new opportunities for increased security and business intelligence. Deep learning and AI will enhance video analytics capabilities At the start of 2018, our security industry experts commented on how deep learning technology and Artificial Intelligence (AI) would extend to the video surveillance industry, allowing security professionals to gain very specific insights into human behaviour. Our experts predicted that this would permit organisations to reduce risk, enable efficiencies, reduce costs, ensure compliance and provide faster access to stored video. With AI-enables video systems, video analytics are set to perform more complex applications at a higher level of accuracy. Image processing developments allow intelligent analytics  According to Ambarella’s Chris Day, advancing chip technology combined with the neural network approach to computer vision is game changing for video analytics. Since the problem of higher resolution has already been solved, the key differentior for video surveillance systems will be the ability to add computer vision in parallel with image processing and high-resolution encoding – ideally in a chip that is low-power. Integration with security systems increases video analytics value Video systems produce an immense amount of data that is often wasted, says Bosch Security Systems’ Sean Murphy. When video analytics alerts are integrated with other security systems, video events can trigger responses from other parts of the security solution. For example, cameras with video analytics can initiate intrusion detection system events initiate intrusion detection system events, prompting the panel to take action by alerting the central station or sending video to security personnel.   Video analytics add value with actionable business intelligence Adding network video to the current generation of Internet of Things (IoT) solutions provides actional value beyond situational intelligence for security purposes. With increasingly intelligent sensors, interactions between business systems are becoming more sophisticated, providing a value greater than the sum of the parts. Organisations can use smart applications to reduce energy consumption, allocate workspace, and reduce operating costs. In a retail environment, analytics are now capable of assessing a scene for occupancy and crowd control, even generating reports of trends over time. Video analytics detect abnormalities to predict incidents Camera-based video analytics can go beyond assessing a current scene to predicting potential risks before they occur, explains Pelco’s Jonathan Lewitt. Based on predetermined factors or analysis of prior events, systems can collect all available information to determine the level of severity of a situation and whether an action needs to be taken. At the same time, systems can correlate data from video and other sources to help analyse similar occurrences in the future. Video analytics increasingly supplemented with audio analytics Audio analytics are often overlooked, notes Hanwha Techwin’s Paul Kong, perhaps due to differing privacy laws from video surveillance. However, audio analytics processed in a camera can help provide a secondary layer of verification for events, as well as identifying gunshots, screams, or other sounds indicating an incident is taking place. This makes audio analytics ideal for dealing with active shooter events at schools and campuses. As Louroe Electronics’ Richard Brent explains, audio analytics software can detect rising levels of human aggression, as well as recognising firearm discharge. This can trigger alerts to ensure incidents are dealt with swiftly.

As anyone who has ever flown on a commercial airline since 2001 knows, security measures at airports are well enforced and the emphasis on traveller safety is all around the airport and its grounds. Mass transportation, meanwhile, presents a special but not any less significant challenge when it comes to determining security issues. These facilities need to develop the means to protect a constantly changing and large population of passengers. And unlike airports these facilities often have hundreds of points of entry and exit on multiple modes—buses, subways, light rail, commuter trains, even ferries. About 2 million Americans will use the nation’s airways on a given work day, while 35 million people will board some form of public transportation. In fact, statistics have shown that nearly 11 billion trips are taken on public transportation every year. In some large metropolitan areas in North America where mass transit is well established, more than 20 percent of the area’s inhabitants get around via public transportation.About 2 million Americans will use the nation’s airways on a given work day, while 35 million people will board some form of public transportation Solving mass transit security For transportation officials and their security providers, solving the mass transit security issue begins with determining the key concerns and then creating the proper responses via security systems, policies and procedures to mitigate the risks. Although vandalism and graffiti are very visible signs of criminal behaviour in mass transit settings such as bus stops and subway stations, this is not where transportation officials typically focus their energy. Fences and gates can secure out-of-service buses and train cars, as can remote surveillance methods to keep such vandalism at a minimum. Instead, it is the day-to-day safety and security of transit riders and employees that should become the highest priority. This begins with creating the safest environment possible that is highlighted with appropriate signage and, when necessary, audible warnings, and supporting that with technology, such as surveillance cameras, that will document what has happened if an incident occurs.Analytics can also be useful in alerting security about other suspicious behaviours at a transit stop, such as an untended bag or package Crime prevention in transportation Analytics can also be useful in alerting security about other suspicious behaviours at a transit stop, such as an untended bag or package Incidents of concern within a transit setting can take several forms, ranging from legitimate accidents or crimes to false claims such as faked fall down the stairs to potential and actual suicides. Bus and subway stations also have become magnets for homeless people who may put themselves and others in harm’s way by trying to access less secure public areas within a station as temporary shelters. If someone is injured on a subway platform and the transit provider is held liable, it could be on the hook for hundreds of thousands, if not millions of dollars. Suicides are a major concern for operators, with personnel now being trained to look for individuals who seem distressed, are loitering in the area or are intentionally putting themselves in a dangerous situation, such as standing too close to the edge of a platform. The deployment of video analytics, which can be programmed to send alerts when certain pre-set actions occur, can help determine when such dangerous behaviours come into play. Analytics can also be useful in alerting security about other suspicious behaviours at a transit stop, such as an untended bag or package or a person going into a restricted area. Whether it is on the bus, train or ferry or at the stops themselves, cameras and intuitive video management systems are the key to both active and forensic transit security. Some cities use buses that are up to 60 feet long and those can be equipped with up to a dozen cameras Train security and safety By using the proper cameras and recording systems in a transit environment, quick-acting personnel can locate a person of interest who boarded a train at one station, follow him during his trip and produce a crisp, clear identifiable image at the end. Those setting up the system thus should keep in mind proper camera positioning, resolution and motion-based changes to framerates or other compression settings. A typical 30-foot bus often has six cameras—one each at the front and middle doors, two more within the bus and then one looking forward and another looking behind the bus. The latter two are important in the event of accidents to verify liability. Some cities use buses that are up to 60 feet long and those can be equipped with up to a dozen cameras.Train stations often deploy high-definition cameras to better support facial recognition software to get that actionable image Train cars are similarly equipped with two to four cameras to view activity down the centre aisle. Within the stations themselves, there can be from 15 to 30 or more cameras capturing wide-angle shots. Train stations, which have a restricted point of egress, often deploy high-definition cameras to better support facial recognition software to get that actionable image. Installing the right technology for the solution Although bandwidth and storage can be a concern, with motion-based recording, the resolution can be bumped up during event, resulting in a 1-megapixel stream jumping to 4 or even 8mbps when needed. By changing the resolution on demand, end users can cut their storage needs significantly. Transportation settings often rely on the same technology used in other security installations, primarily mini dome cameras, although there are some mini transit domes built specifically for the environment with the proper aesthetics. Because of vandalism threats, transit typically avoids pendant mounts, which can be more easily grabbed and damaged. Temperature ratings for cameras also come into play in cold climates with cameras often getting outdoor exposure.Today’s new buses and trains are constructed with the cameras onboard and newer stations also take security into consideration at the earliest design stage As trains and buses move along their routes, especially those that service outlying areas, Internet connectivity becomes an issue as well. Because it may be difficult for video to be sent in transit, security bus barns are equipped with Wi-Fi so video from onboard cameras can be downloaded at the end of the day. And the use of hardened recorders at the stations allows security personnel to retrieve recorded video. Transit security with modern technology Today’s new buses and trains are constructed with the cameras onboard and newer stations also take security into consideration at the earliest design stage. Older infrastructure from long-standing subway and bus terminals can prove to be a challenge when adding security, but these issues aren’t insurmountable. Often the solution is to add more cameras to cover the same square footage because of less-than-ideal sight lines and to place conduit wherever it works best, which may mean positioning it under platforms or in other out-of-the-way places within older stations. Looking ahead, transit security will continue to evolve, not only as new stations and modes of transportation are added to the system, but in terms of communicating with commuters. People can expect to get mass notification alerts on their mobile devices, and those same devices can provide vital data to transportation entities to better develop their overall systems.
