Dahua Technology EVS5024S-R 512 channel embedded video storage
Dahua Technology EVS5024S-R 512 channel embedded video storage

Dahua Technology EVS5024S-R 512 channel embedded video storage features: Dual controller architecture ensures system reliability 64-bit high-performance multi-core processors ensure massive data processing stability Modular, poll-out, Cablese Design keeps system easy-maintainability Supports SAS multiple cascade, external SAS interface bandwidth bi-directional 192Gbps ensures system storage capacity expansibility 24 HDDs in Single device, single system up to 240 HDDs, capacity up to 1440TB Up to 10-1000Mbps Ethernet ports and 4-10000Mbps Ethernet ports Internal backboard bandwidth bi-directional 288Gbps Supports 3.5 inch, 2.5inch SAS/SATA (1T / 2T / 3T / 4T / 6T), Supports mixed capacity HDDs Supports HDD hot-swap, online replacement, online expand Supports standard iSCSI protocol storage and video stream direct storage Under video stream direct storage mode, supports 1024Mbps video storage; supports 128Mbps network playback Under video stream transmit mode, supports 4096Mbps front-end access; 4096Mbps network transmit Under IPSAN working mode, storage bandwidth ≥ 3.6Gbps Supports RAID0 / 1 / 5 / 6 / 10 / 50 / 60 / JBOD, hot standby, ensures data storage safety Supports standard protocol such as ONVIF / GB28181, ensures front-end compatibility from different manufacturers Adopts WEB configuration, easy to setup Software and hardware optimisation aim at monitoring field, supporting other monitoring products form a complete solution Completely standard equipment, compatible with various software platforms
