India’s Western Railway is one of the 17 zones of the country’s railway systems and is among the most-travelled rail networks in India. The Surat Railway Station, for example, is one of the busiest among the Western Railways where more than 160 trains pass each day. This segment of the immense railway network is headquartered in Baroda, now also known as Vadodara, a few hours south and east of Ahmedabad in Western India.
The Indian Railways has some 150 remote installations for the railway’s signaling systems. Located alongside the tracks at about every 5 km, there is a battery hub that powers each of these standalone systems.
Theft of batteries
Recently, in many places, the powerful batteries have been stolen, causing train signals to malfunction
Recently, in many places, the powerful batteries have been stolen, causing train signals to malfunction, which threatens travellers’ security and leads to stoppage of the trains, as personnel wait for confirmation of safety signals.
It is nearly impossible to secure all locations 24/7, by way of personnel alone. In many locations, chances of theft and damage seem to be inevitable. Jignesh Shah, System Integrator for Mehulendra Corporation, was called upon to stop the theft of the batteries.
Major security concerns included concern regarding human life, assets, and property loom, not the least of which is securing the battery system on which the signaling depends. Maintenance of the various systems at remote locations was also a significant concern.
Hikvision’s all-in-one, integrated solution
Railway administrators wanted to monitor all sites at the head office located in Vadodara, Gujarat, India and the standard solutions on the market – where CCTV and alarm systems are separate – could not meet their requirements for this project.
Mehulendra, however, proposed unique Hikvision technology, demonstrating its all-in-one, integrated solution. More than that, since the after-sales service was an equally important consideration, Hikvision’s joint venture company in India, Hikvision-Prama, helped to secure this solution as the best one available.
Intrusion Monitoring System (IMS) for Railways
What Mr. Jignesh Shah and Mehulendra Corporation proposed was an Intrusion Monitoring System (IMS) for Railways. This would make use of Hikvision’s integrated security alarm system, using the all-in-one Security Control Panel, a powerful device that packs multiple features into one accessible unit.
Basically, the security hardware needed at each signaling station included an integrated security control panel, video surveillance cameras, door alarm components, and a 4G SIM-based, four-port router. Finally, Hikvision’s video management platform would tie the operations together for personnel at the head office.
Hikvision’s 1.3 MP Fixed Dome Network Camera
Hikvision’s 1.3 MP Fixed Dome Network Camera were chosen for their 24/7 monitoring capabilities
The control panel (model #DS-19508N-04F-I) ties together intrusion detection, two-way audio, and mobile messaging, and it can be managed remotely using an app on a connected mobile device. The panel can host up to four IP camera inputs and provides PTZ control as well.
Hikvision’s 1.3 MP Fixed Dome Network Camera (model #DS-2CD211OF-I) were chosen for their 24/7 monitoring capabilities, including 30 metres of IR range for night time surveillance and on-board micro-SD card digital recording.
Panic switches installed
Doors at each station were wired with alarm contacts and connected to a 109 dB siren. Panic switches were also installed for personnel to use in emergencies. The internet router keeps the systems connected across the vast Indian landscape and enables the automated SMS messaging via mobile apps to alert nearby personnel of security needs.
After the successful completion of the pilot project (complete installation at one of the stations), the client was satisfied and gave the green light for installation in the remainder of railway locations. Timeline for the completion was one month. Since no major challenges stood in the way, Mehulendra Corporation was able to successfully complete the project as required.
All-in-one panels with motion sensors and smart cameras
Menhulendra installed the Hikvision all-in-one panels, all with motion sensors and smart cameras. The smart cameras are triggered by movement. Using a phone dialer and GPS SIM card, a triggered panel sends an SMS alert to the nearest RPF staff, who can respond with security protocols, during the security event. After initiating the security systems, reports from the installation sites show robbery attempts have declined to almost zero.
“The Integrated Solution from Hikvision has helped us not only to get a perfect solution with a combination of hardware and software, but controlling & maintaining the same from one location,” said Mr. Jignesh Shah of Mehulendra Corporation, adding “Additionally, it is a hassle-free solution, easy to install and use, with intrusion detection, CCTV, sensors, and hard drives all coming from one vendor along with software to manage and control the system from a central location.”
