As buildings become more complex and smarter, the age-old traditional maintenance methods that are based mostly on hands-on human monitoring are becoming more and more inadequate. Instead, the world is fast adopting building automation as a key component of smarter and more proactive maintenance strategies.

The aim is to free up maintenance staff and give them time to focus on other tasks while machines monitor the different systems that work together to make the facility functional.

Specifically, Internet of Things - or, IoT - enablement appears set to transform the way facility managers deliver service to building occupants. The trends are many and the possibilities are almost mind-boggling, from inventory management, to work scheduling and energy efficiency, the list goes on and on. Below, we look at a few ways in which IoT is being used for Facility Management and Security.

Revolutionise maintenance through condition-based maintenance

For years now, the norm among maintenance professionals has been a time-based approach, or in simpler terms, performing maintenance operations after a set period of time. But a major flaw of this system is that components were being replaced periodically whether the parts were actually worn out or not.

Of course, that meant some of these maintenance activities simply weren’t cost-effective. To avoid this waste from continuing, a subset of IoT known as IIoT can now be used to optimise the maintenance process. IIoT works as a centralised network of connected systems and devices that can talk to one another and generate and relay data

Rather than changing parts on a time-based schedule, IIoT works as a centralised network of connected systems and devices that can talk to one another and generate and relay data. Selected equipment are fitted with sensors that monitor specific operational parameters and let maintenance professionals know how the machines under supervision are working, understand their current condition, and then pinpoint the optimum time they need to be maintained.

The information generated this way is vital as it allows maintenance staff to intervene just in time to avoid costly downtime and other associated inconveniences. This is, in a nutshell, the basics of predictive maintenance and condition-based maintenance.

These days, by implementing condition-based maintenance, IIoT is being used to effectively monitor a wide range of systems such as lighting, HVAC, fire suppression, security, etc.

The applications are numerous and so are the benefits. On page 52 of this guide by the US Department of Energy, they state that a functional predictive maintenance program could yield up to 10 times ROI, reduce maintenance costs by 25% to 30%, and reduce downtime by 35% to 45%

implementing condition based maintenance
Along with fire suppression, IIoT is effectively monitoring a wide range of systems such as lighting, HVAC and security

Remote monitoring of facilities

Physical inspections have been a critical condition for the success of conventional maintenance programs, even in hazardous environments. But, with the increasing emphasis on personnel safety, organisations want alternative solutions that allow staff to examine assets without being physically present.

Facility managers and their team working in industries like manufacturing, oil and gas, and mining can relate with these constraints. And these industries can benefit greatly from deploying predictive maintenance solutions.

For example, in the oil and gas industry, IIoT sensors can be used to monitor remote and highly critical assets. These sensors can be used on pipelines to detect anomalies (especially corrosion) and pass that information to supervisors for necessary action. By doing this, potential failures are quickly predicted to avoid often disastrous incidents.

Managing energy consumption

Sensors are also being embedded in building components and devices like HVAC systems, lights, doors, windows to understand energy consumption and proactively manage it. Facilities that use this technology could achieve substantial energy savings. In a press release by IT research and advisory company, Gartner, they stated that IoT can help reduce the cost of energy - as well as spatial management and building maintenance - by up to 30%. Looking at HVAC systems very closely, we see that they are a major source of energy usage in any building

These sensors work by monitoring different conditions in the building and causing a power-saving action based on the data received. For instance, occupancy sensors can order lights to turn on when it senses motion in a room and then turn off the same lights when there is no presence there. That way, there is no need to wait for someone to remember to switch off the lights when they are not needed.

Another very common use is in HVAC monitoring. Looking at HVAC systems very closely, we see that they are a major source of energy usage in any building. So, the issue is how can one use IIoT to manage HVAC and possibly reduce their energy usage? Well, in its most common form, IoT-enabled HVAC works as a connection of sensors and thermostats that monitor factors like indoor air quality, temperature, and environmental changes then communicate with the rest of the HVAC equipment and make needed adjustments for occupants’ comfort. Not only that.

thermostat and HVAC IoT
IoT-enabled HVAC works as a connection of sensors and thermostats that monitor factors like indoor air quality, temperature, and environmental changes

The technology can be configured to:

  • Track energy consumption at different distribution points throughout the building.
  • Track usage from the power source right down to the consumption point.
  • Detect sudden voltage drops or spikes (usually an indication of some fault).

These are essential benefits because HVAC units are notorious for consuming large amounts of energy when they are working inefficiently.

Security and access control

Smart surveillance is another important area of application for IoT in facilities management. It takes several forms such as the monitoring of life-saving systems like intruder or fire alarms, invisible barriers, and other safety installations. Facility managers are using IoT across different industries to obtain live information about potential emergency situations with a view to responding before the issue escalates.

In such cases, quick detection of any strange activity is key because many of these installations have tangible negative effects when they fail or when they are intentionally sabotaged.Smart surveillance is another important area of application for IoT in facilities management

Fortunately, the surveillance equipment can also be setup to send alerts to mobile phones to aid emergency response or evacuation as the case may be. Smart surveillance is also priceless for monitoring the situation in partially or fully automated remote facilities (especially oil and gas installations and mines), and in hostile environments with critical equipment where humans cannot work for extended periods of time. If you are not yet using IoT in your facility, you may be wondering where to start from.

To avoid getting overwhelmed, a good place to start would be to try a small-scale deployment of this technology then review its ROI and impact on your operations before adopting a more widespread IoT implementation. This way you can gradually scale up as you and your staff come to understand and adapt and to this new way of doing things.

Share with LinkedIn Share with Twitter Share with Facebook Share with Facebook
Download PDF version Download PDF version

Author profile

Bryan Christiansen Founder and CEO of Limble CMMS, Limble CMMS
