SALTO Electronic Door Locks & Locking Devices

In part one of this feature, we introduced the shotbolt – a solenoid actuator – as the workhorse at the heart of most straightforward electric locking systems. Shotbolts remain at the core of most sophisticated electric locking solutions as well. But they are supplemented by materials and technologies that provide characteristics suited to specialist security applications. Here we look at some more demanding electric locking applications and contemporary solutions. Preventing forced entry Where the end of the shotbolt is accessible, the electric holding force can be overcome by physical force. That’s why anti-jacking technology is now a frequent feature of contemporary electric solenoid lock actuators. Anti-jacking, dead-locking or ‘bloc’ technology (the latter patented by MSL) is inherent to the way the locking assembly is designed to suit the requirements of the end application. The patented bloc anti-jacking system is highly effective and incorporated into many MSL shotbolts deployed in electric locking applications. The bloc technology uses a ring of steel balls in a shaped internal housing to physically jam the actuated bolt in place. A range of marine locks is widely used on Superyachts for rapid lockdown security from the helm Real life applications for MSL anti-jacking and bloc-equipped shotbolts include installation in the back of supermarket trucks to secure the roller shutter. Once locked from the cab, or remotely using radio technology, these shutters cannot be forced open by anyone with ‘undesirable intentions’ armed with a jemmy. A range of marine locks is widely used on Superyachts for rapid lockdown security from the helm. While anti-jacking features are an option on these shotbolts, consideration was given to the construction materials to provide durability in saltwater environments. Marine locks use corrosion-proof stainless steel, which is also highly polished to be aesthetically pleasing to suit the prestigious nature of the vessel while hiding the innovative technology that prevents the lock being forced open by intruders who may board the craft. Rotary and proportional solenoids sound unlikely but are now common A less obvious example of integrated technology to prevent forced override is a floor lock. This lock assembly is mounted beneath the floor with round-top stainless-steel bolts that project upwards when actuated. They are designed to lock all-glass doors and are arguably the only discreet and attractive way to lock glass doors securely. In a prestigious installation at a historic entranceway in Edinburgh University, the floor locks are remotely controlled from an emergency button behind the reception desk. They act on twin sets of glass doors to quickly allow the doors to close and then lock them closed with another set of subfloor locks. No amount of stamping on or hitting the 15mm protruding bolt pin will cause it to yield, thus preventing intruders from entering. Or leaving! Explosion proofing In many environments, electric locking technology must be ATEX certified to mitigate any risk of explosion. For example, remote electric locking is used widely on oil and gas rigs for stringent access control, general security and for emergency shutter release in the event of fire. It’s also used across many industrial sectors where explosion risks exist, including flour milling, In many environments, electric locking technology must be ATEX certified to mitigate any risk of explosionpowder producers, paint manufacture, etc. This adds a new dimension to the actuator design, demanding not only intrinsically safe electrical circuits and solenoid coils, but the careful selection of metals and materials to eliminate the chance of sparks arising from moving parts. Resilience under pressure The technology boundaries of solenoids are always being pushed. Rotary and proportional solenoids sound unlikely but are now common. More recently, while not directly related to security in the traditional sense, proportional solenoid valves for accurately controlling the flow of hydrogen and gases now exist. Magnet Schultz has an extensive and somewhat innovative new range of hydrogen valves proving popular in the energy and automotive sectors (Fig. 2-6). There’s a different kind of security risk at play here when dealing with hydrogen under pressures of up to 1050 bar. Bio security Less an issue for the complexity of locking technology but more an imperative for the effectiveness of an electric lock is the frequent use of shotbolts in the bio research sector. Remote electric locking is commonplace in many bioreactor applications. Cultures being grown inside bioreactors can be undesirable agents, making 100% dependable locking of bioreactor lids essential to prevent untimely access or the unwanted escape of organisms. Again, that has proven to be topical in the current climate of recurring coronavirus outbreaks around the world. More than meets the eye In part one, I started by headlining that there’s more to electric lock actuation in all manner of security applications than meets the eye and pointed out that while electric locking is among the most ubiquitous examples of everyday security, the complexity often involved and the advanced technologies deployed typically go unnoticed.Integrating the simplest linear actuator into a complex system is rarely simple For end users, that’s a very good thing. But for electro-mechanical engineers designing a system, it can present a challenge. Our goal at Magnet Schultz is to provide a clearer insight into today’s electric locking industry sector and the wide range of locking solutions available – from the straightforward to the specialised and sophisticated. Integrating the simplest linear actuator into a complex system is rarely simple. There’s no substitute for expertise and experience, and that’s what MSL offers as an outsource service to designers. One benefit afforded to those of us in the actuator industry with a very narrow but intense focus is not just understanding the advantages and limitations of solenoid technology, but the visibility of, and participation in, emerging developments in the science of electric locking. Knowing what’s achievable is invaluable in every project development phase.

A defibrillator can save the life of a person suffering from cardiac arrest – but it is most effective when used in the first few minutes of the patient collapsing. Studies have shown that a shock given within the first three minutes provides the best chance of survival and even one minute of further delay can substantially lower the chances of recovering. Public Access Defibrillators (PADs) were created to allow untrained members of the public to deliver life-saving treatment in those precious minutes before an ambulance arrives. There are currently over 10,000 in the UK, located in parks, offices, high streets and sporting venues, and they are especially popular in rural communities, where ambulance response times are longer. Every second counts Over the years there has been a long-running debate as to whether PADs should be kept openly accessible or locked. Leaving them open could lead to theft, vandalism or misuse. Leaving them locked could mean that precious moments are lost waiting for a local guardian to arrive – and could even cost a life. To save as many lives as possible, it’s clear that PADs need to be available 24/7, fully operational and easily accessible to users and local guardians. But there is a solution that can meet all these conditions – a lock that can protect against vandalism while providing convenient instant access when required. Life-saving solutions Over the years there has been a long-running debate as to whether PADs should be kept openly accessible or lockedDigital locks are ideal for securing PADs because they don’t require a key, and anyone can be given access over the phone. In the case of a cardiac arrest, the user calls 999 and the ambulance controller provides them with a simple, easy-to-remember code. The ambulance controller can then advise them, step by step, what to do. Local guardians, who have responsibility for the PAD, can be provided with an override key to enable them to monitor and maintain the defibrillator. The PAD cabinets built by Duchy Defibrillators show exactly how this works in practice. Based in rural Cornwall, Duchy Defibrillators manufactures, supplies and installs monitored PAD cabinets. To provide public access to the defibrillators, it needed a lock that could keep its cabinets secure, make them easily accessible and withstand the stormy Cornish weather. Codelocks recommended a digital electronic lock that could operate on a standalone battery, making it especially suitable for remote areas. As well as offering flexible access, digital locks come with a range of varying options and functions to suit different applications. As Duchy Defibrillator cabinets are installed in a wide variety of locations and sometimes need to withstand outdoor exposure, it opted for a robust electronic digital lock that is both affordable and easy to set up. A digital-access revolution Using smart locks in combination with a dedicated app or portal allows operators to send time-sensitive codes to end-users The example of Duchy Defibrillators shows how digital locks can be used to keep defibrillator cabinets secure while affording instant access to users when they are needed. But the flexibility of digital locks also makes them suitable for securing property and equipment in a wide variety of situations, especially for shared and public facilities. This is why you’ll increasingly see digital locks used to secure restricted areas in hospitals, schools and offices, as well as shared facilities like hotel and gym lockers, public restrooms and more. Digital locks are available for a number of specific applications, including doors, lockers and cabinets. They can range from simple mechanical locks through to more sophisticated electronic locks and state-of-the-art smart locks. Using smart locks in combination with a dedicated app or portal allows operators to send time-sensitive codes to end users – making them very popular for contactless entry and with facilities managers that need to manage access to buildings and campuses. One thing is certain – whatever your access control requirements are, there’s a keyless lock solution to suit. The digital access revolution is here.

The experience of the COVID-19 pandemic has made us all more conscious of who is coming and going from our property. Whether it is a family home, business premises or public building, property owners want full control over access for protection and peace of mind. As a provider of access control technologies, we are seeing a growing demand for automated gates with a variety of access control systems. There are a number of considerations that buyers need to make when investing. And as an installer, there is advice that you can offer to help your clients make the right choice for their property. Here are some of the key considerations you’ll need to make and discuss with your client. Whomever you buy from, you should be offered more than a simple instruction manual. Electronic locks, magnetic locks and code security In the first instance, you’ll need to advise on the type of lock and access control available. Electronic locks release on the operation of the automation system to allow the gates to open. Locks are required for all non-locking (also known as reversible) operators and are recommended for any gate on a multi-user site or any gate over 2.5m. Apply the same logic to an automated gate as you would to a domestic door – for example, you wouldn’t fit your front door with a lock on the same side as the hinges or a drop bolt at the hinge end of a manual gate so why dispense with this logic when the gate is automated? Electronic locks release on the operation of the automation system to allow the gates to open There are a number of locks on the market including magnetic locks, drop locks that “shoot” a bolt into the ground and side latching locks. These are all designed for external use. While the gate itself will provide physical security, the customer will want to feel in control of who enters their property, when and for what purpose. Consider access for post and deliveries, waste disposal and visitors arriving on foot etc. There is a range of options available. Intercom systems will allow the user to vet visitors, keypad entry can allow remote access for visitors with a specific code, remote controls allow an oncoming driver to open the gates without getting out of the vehicle, and a timer control can be used to open or close the gates at certain times of the day. Vehicle detection loops can be installed discreetly under the tarmac allowing the presence of vehicles to exit the gates and prevent closing whilst obstructed. Sliding gates versus swinging gates There are a number of locks on the market including magnetic locks, drop locks that “shoot” a bolt into the ground and side latching locks Gates can be automated to either swing or to slide open and in the case of swinging gates, the opener may be concealed underground or gate mounted. The most suitable opener for your installation will depend on the space available and the type of gate selected. Concealed underground automation is ideal for highly ornate gates. However, where gates are fully infilled (typical of many timber designs), gate mounted openers are concealed from the front of the gate by the gate leaf and present a cost-effective option. The choice between slide and swing is largely down to space - swing gates require a clear space for their opening arc whilst sliding gates require space to one or both sides of the gate. Sliding gates are perhaps the best choice where the drive slopes or when drive space is limited, as they use the least space when opening. Voltage Most swing gate and sliding systems are available in 24v or 230v. The 24v systems still need 230v mains power – there is a transformer built into the 24v control panels. Deciding which voltage to use can include a combination of factors such as the material of the gates, the location of the system and the safety features you want. Concealed underground automation is ideal for highly ornate gates With wrought iron gates, the wind can pass through them whereas with fully boarded wooden gates (popular because they give full privacy) the wind has nowhere to go, so they act like sails. For commercial or industrial applications with larger entrances and a heavy gate, you may need 3 Phase 400v power (sliding gates only). Installing gate motors in confined spaces The environment in which you are fitting may well influence which gate and motor you recommend. Will it be in an exposed area which is subject to the elements? Will it be positioned on a slope? Sliding gates are perhaps the best choice where the drive slopes or when drive space is limited Installers have always faced the challenge of installing gate motors in confined spaces. When fitting a pedestrian gate, there is often limited space in which to work – potentially making an installation time consuming and technically demanding. If this is the case for you, consider a gate operator which is designed specifically for installations with limited space for manoeuvre. An example of this is the E5 compact gate operator. The operator is not only small but has an optional slide lever attachment designed for installations where there is extremely limited space, meaning that just 8cm of the pillar is needed for installation. What’s more, improved fixing points and a simple ‘hook and fasten’ process means assembly is safe, quick and straight forward. Ultimately, you’ll be looking for a good quality, reliable product with good service. Work with a supplier that offers more than just a manual. If they are happy to offer training, their time and advice when you buy, the chances are you’ll get their support long term.

SALTO Systems, front-runners in wire-free networked, wireless, cloud and smartphone-based access control solutions; announce that the SALTO Neo electronic cylinder is their latest product to gain the coveted BSI Enhanced Level IoT Kitemark™ for access control systems. Designed for doors where fitting an electronic escutcheon is not possible or required, the compact SALTO Neo Cylinder can be installed on standard doors, server racks, gates, cabinets, electric switches, sliding doors, and more. It’s also available in an extensive range of models, including a new tough next-generation electronic padlock, and is suitable for use on almost any kind of door from Europe to ASIA to the Americas. IoT security IoT is a network of smart devices and systems when connected, enables the exchange of data to provide services, efficiency and innovation BSI (British Standards Institution) has been part of this collaborative work to give clarity on best practices for IoT security, subsequently developing a scheme to assess connected/IoT devices. The scheme determines whether a product has the appropriate security controls for its intended use and is suitably supported throughout its intended life. This cyber/physical security scheme forms the security element of the BSI Kitemark for IoT/Connected products. The IoT is typically a network of smart devices and systems that can be connected, enabling data to be exchanged to provide services, efficiency, and innovation. Its technology can positively enhance lives and businesses, but the complexity of IoT also means that those of criminal intent may attempt to access it to steal data, hack cameras, enter buildings or otherwise breach security. Advanced security testing Like the already approved XS4 One electronics locks product family and BLUEnet wireless peripherals, SALTO controllers and readers, to achieve certification the SALTO Neo family of electronic cylinders had to undergo advanced security testing for vulnerabilities and security flaws in BSI’s state of the art IoT laboratory enduring BSI’s most in-depth and exacting testing and analysis. The SALTO Neo Cylinder provides an effective and convenient way of securing a building or assets. The clutch system is energy efficient, dropping power consumption to impressively low levels resulting in 100,000 / 130,000 operations from just one set of batteries. Standby power consumption is also reduced, further extending battery life. IP66-rated and certified Now IP66-rated, the SALTO Neo Cylinder is weather-resistant, making it especially suitable for outdoor use, even in the harshest of environments. Inside the tough SALTO Neo Cylinder exterior is the latest in electronic lock technology. Certified to the highest security standards, and incorporating ever-higher quality and reliability, the SALTO Neo Cylinder offers value far beyond security, however. It also provides greater control over the door by offering users access to audit trails, reports, alerts and much more. SALTO Systems Limited MD Ramesh Gurdev said, “We’re proud that our SALTO Neo cylinder family now holds both ‘Secured by Design’ accreditation and IoT Kitemark™ status as both are increasingly important in the specification of access control systems. The award means we now exceed the market standard for a number of security products across our access range which provides SALTO customers with confidence that they are buying one of the most secure products available on the market today.”

The Wave XS is a smart, fast and reliable access control solution with a touchless button that permits easy and clean operation for a large number of activator devices. Upgrading to touchless access control allows for hands-free entry, eliminating the need to make contact with common touchpoints upon entry and creating a more hygienic environment for everyone. Wave XS reader technology offers 100% touch-free automated access control. Depending on the configuration, the Wave XS reader’s capacitive technology can sense hand gestures. All the user has to do is approach the door and their hand activates the door to open, which makes for simple operation and eliminates the need to touch any surface. Automatic door opening hardware With the Wave XS standard reader range, one can easily install hands-free automatic door opening hardware on an existing electrified door to eliminate that added touchpoint and promote a touchless, disability compliant workplace. The solution can also be integrated with the SALTO Systems controller (CU) product range which delivers seamless integrations with lifts, turnstiles, and parking garages to further reduce touchpoints throughout a building. Push-button technology Automatic door technology is expected to revolve around innovation along with the development of smart touchless access Contactless push-button technology has advanced in recent years, with devices activated by proximity using microwave, infrared, and laser sensors. Within the context of the global pandemic, automatic door technology is expected to revolve around innovation and the development of smart touchless access that avoids contact and creates safer spaces. Some of these systems allow doors to be opened by simply bringing the hand to within just a few centimetres from the reader device. As SALTO Systems has long leveraged electronic locking solutions that enhance any door or building with elegant electronic locks, cylinders, locker locks, and readers, they do so again with the SALTO Wave XS reader. Wave XS features and characteristics Developed by the Conlan SALTO Group Company, the Wave XS reader will help combat the spread of the COVID-19 coronavirus as well as future germ threats and help reinforce safety within building spaces. Hands-free wave to unlock touchless technology (Infrared) 2 Outputs (Open collector) Black and white faceplate & surface mounting Compact design with standard wiring IP65 protection rated for indoor and outdoor use Several design, text and symbol configurable options Operating temperature: -20°C ~ +70°C Voltage interval: 12 – 24 VDC, 30 mA Compatible with SALTO Space and SALTO KS technology platform

SALTO Systems’ access control door lock components and system peripherals are definitely keeping in step with the latest and best new building design trends. The new Dark Bronze option for the XS4 Original and Mini ANSI product range matches some of the new design trends and blends perfectly with both white and dark doors, modern styles, and sophisticated wooden decorations. SALTO door locking solutions The SALTO door locking product range is available in a variety of finishes to complement each other and other hardware that may be installed in a building on wood or steel doors. The SALTO MyLock online configuration tool, which allows users to choose and see potential door configuration finishes to match specific project needs, has added a new Dark Bronze Finish option to the platform. MyLock users can now visualise this stunning finish for several product models MyLock users can now visualise this stunning finish for several product models, including the XS4 Original, the XS4 Mini, and the XS4 Keypad ANSI model electronic locks with the new Dark Bronze finish. Real-time electronic access control When planning an access control project that requires real-time electronic access control, it is important to be able to visualise the different locks, finishes, and door styles and how they look together. From traditional to contemporary, SALTO hardware comes in a variety of architectural styles and finishes to meet any aesthetic needs and design goals. SALTO MyLock SALTO MyLock enables specifiers, architects, partners, and end users to individually configure SALTO‘s wire-free electronic door lock components and visualise them on different door types or styles. In addition to the electronic hardware, they can choose from several door models and a wide range of colours, finishes, handles, and functions. Once completed, a MyLock user can preview and download 3D and 2D files including BIM files in a variety of industry formats, such as Revit, STP, DWG, JPEG, PDF, and more. As SALTO adds locks and finishes like the new Dark Bronze, the MyLock Configurator is updated to reflect the absolute latest in SALTO electronic lock technology.
