Geutebruck pictures a world with less data and higher service standards
Geutebruck pictures a world with less data and higher service standards

The H.264 compression process is widely regarded as the most efficient video process for compressing moving images, because, with suitable computer resources, it can generate the lowest band widths for a given image resolution and quality.  However, most H.264 standard compression processes ignore the fact that large amounts of bandwidth and storage capacity could also be saved by avoiding the generation, transmission or storage of images (or extra resolution) which are not going to be required by the user.  This is a pity because it means that considerable wastage and unnecessary infrastructure costs are incorporated into video security systems. To appreciate the extent of this you only have to look at how many workstation monitors out there are being sent four Full-HD resolution data streams when they can actually only display four D1 or one Full-HD feed.  Geutebruck decided to do better. Going back to basics, but remaining within the H.264 standard, it produced H264CCTV, a process much better adapted to video security systems, their routine functions and the needs of their users. So, when H264CCTV is employed in a control centre, H264CCTV-supporting cameras send the four images for the workstation monitor in D1 resolution until such time as the operator asks for full screen display. Then the selected camera switches its data stream to full-HD and the others cease transmitting to the viewer. This eliminates unwanted images and unusable resolution, and slashes bandwidth and processing loads. The unusual way H264CCTV’s video frames are linked together helps it avoid many typical H.264 problems.  It doesn’t produce artefacts if an individual data package is lost in the network.  It doesn’t over-burden the display processor and hang up the system when cameras are switched. - Instead, its fast and easy decoding ensures that switching at 25fps is well within the processor’s comfort zone. - It doesn’t make viewing and investigation difficult with jumps or jerks, but always replays video with smooth motion, even fast forward, backwards and frame by frame. And, with H264CCTV, event searches don’t just offer you the nearest frame with metadata attached, but always deliver precisely the frame you asked for. Then there’s the costly compromise many H.264 system users have to make between recording more frames per second than they really need, or viewing fewer frames per second than they’d really like, or both.  This frustrating situation arises because the chained frame formations in most H.264 implementations make it impossible to discard individual frames to create streams with different picture rates for different purposes. On the other hand, the independent control of recording and live video qualities was a basic requirement in the design of the H264CCTV structure so it ensures that users can have dual streams with exactly the quality of service they require. For more about H264CCTV and products which use it visit www.geutebrueck.com

Add to Compare
Geutebruck's re_porter hybrid recorder out now in a special /econ edition
Geutebruck's re_porter hybrid recorder out now in a special /econ edition

re_porter, Geutebruck's high-performance hybrid recorder is now available in a special edition at a special price, dispatched from the German factory within 24 hours.re_porter/econ processes up to 19 video channels and an audio channel. It supports analogue, network and megapixel cameras from all well-known manufacturers, and enables easy migration from analogue to digital. Ideal for many kinds of application, re_porter/econ is particularly well equipped to deliver event recording with high picture rates per camera. With preconfigured software and a wide range of options, installation is quick and customisation easy. The future-proof design based on digital signal processors and software updates means you can maintain state-of-the-art functionality indefinitely. re_porter/econ comes with a 500 GB hard disk and an English language operating system which you can change via the desktop script if required.Other features:Preinstalled high-grade activity detection and a versatile backup function.Supports virtual matrix control of live and recorded video from analogue and network cameras.Scalable - can have any number of re-porter systems in a network; licensed for simultaneous database access for 10 users.Dual-channel streaming - parallel live quality recording of video and sound with live-stream fed into network.Negligible latency - normal control of PTZ and dome cameras.Superb image quality, irrespective of stream content.Smooth playback with multi-camera synchronisation, live, fast-forward, slow motion and reverse.Very efficient compression - very low data volumes.

Add to Compare
Geutebruck makes multi-standard video processing the new standard
Geutebruck makes multi-standard video processing the new standard

At Security Essen 2010, Geutebruck is showcasing the new re_porter-IP/SE, an entry-level IP server; the GeViScope-AS/R, a new high performance GeViScope-based video analysis platform; as well as a new independent SD card ‘Nano DVR' facility for their IP video sources VIPCAM-DN101/PX and CAM2IP. But perhaps the most significant development on their stand is the new generation of software for GeViStore and GeViScope platforms. Its new ‘omnibrid' multi-standard video processing enables M-JPEG and H.264-based standard as well as specialist video surveillance ones (MPEG4CCTV, H264CCTV) to be used in the same system. It supports the use of analogue, digital, megapixel, ONVIF-compliant and even 16/9 HD-format cameras. And its real-time signal trans-coding enables IP cameras to be used for Geutebruck video analysis processes without needing any additional integral functions. With new operating software, the boundaries are fluid - the future really is 'omnibrid'. The new re_porter-IP/SE is an ideal entry level solution for pure digital video surveillance systems. It supports up to 20 IP cameras and handles M-JPEG, MPEG4CCTV, H264CCTV as well as H.264 standard formats from many different kinds of digital video source. To reduce demands on networks and storage space the re_porter-IP/SE can process and store any data fed into it. It has 16 contacts for event-controlled recording and 8 relays for direct communication with third party systems.

Add to Compare
Geutebruck’s new G-Scope/1000 series of compact NVRs
Geutebruck’s new G-Scope/1000 series of compact NVRs

Some projects seem to ask the impossible, they demand high performance video systems but lack space for the hardware. However, now there’s the Geutebruck G-Scope/1000 series of high performance NVRs with enhanced temperature stability and compact, 302 x 250 mm x 2HU cases.  Equipped with a 1TB database and ideal for building into ATMs or fitting into tight spots, this new series of devices is also attractively priced for retail outlets and other operations with just a few video cameras. The units support multiple compression algorithms including H264CCTV, H.264 and MJPEG formats with freely configurable resolutions and offer highly sophisticated recording and networking capabilities. The G-Scope/1044 processes up to 4 analogue and 2 IP video sources at once, while its pure IP equivalent, the G-Scope/1006 supports up to 6 IP inputs. Despite diminutive dimensions these G-Scope/1000 models boast the traditional Geutebruck performance and functionality and punch well above their weight.  Technical features include: TCP/IP based digital video matrix functionality iSCSI support for external storage PLC-based video management functionality (using GeViPLC) Dynamic user interface adaptations triggered by events or user profiles Geutebruck’s Omnibrid multi standard video compression technology Integration of unlimited systems via network (LAN/WAN) using TCP/IP Eight sabotage controlled binary inputs and four relay outputs For more information on this range of NVRs and all Geutebruck video security solutions please visit www.geutebrueck.com

Add to Compare
Geutebruck’s new re_porter model with hot swap HDD for image evaluation outside the network
Geutebruck’s new re_porter model with hot swap HDD for image evaluation outside the network

Geutebruck’s new re_porter-IP/XRdB is designed as an attractive solution for situations where it is necessary or desirable to review image data outside the network. Its two 2TB hard disks are configured for RAID level 1 so they store identical data. One disk is built in, but the other sits in a sturdy hot swap mount which can be removed with the system still running. This hot swap facility enables you to evaluate the whole database at another station, completely separately, away from the CCTV system and the network. – The GSCSpeedView-XRdB evaluation and playback station has been specially conceived for this purpose. With one hard disk removed, the re_porter-IP/XRdB continues to operate storing all video data on its fixed disk until a new HDD is inserted and it can automatically mirror the data onto the new HDD. This system was developed to meet the particular needs of a video surveillance operator with remote sites where there is no network or where the video is to be reviewed by police or other third parties who have no access rights to the operator’s network.  If an incident is reported at a remote location monitored by the re_porter-IP/XRdB then the video surveillance operator informs the police or other security service provider. An officer goes to the site, taking along an empty hard disk unit. To swap the hard disks over, he presses the button on the front, waits a second or two until the flashing light goes out, then uses a special key to release the disk unit, which can then be pulled out and replaced with the empty one.  When the key is turned again and the button depressed, the system automatically mirrors the recorded video onto the new disk. The officer takes the recorded disk to the reviewing station where he just inserts the disk, turns the activation key and the recorded video material can be displayed. For more information visit www.geutebrueck.com

Add to Compare
Geutebruck's re_porter hybrid recorder now with Dual-Sensor high-end video detection for perimeter surveillance
Geutebruck's re_porter hybrid recorder now with Dual-Sensor high-end video detection for perimeter surveillance

Geutebruck's re_porter hybrid recorder for small and medium-sized projects is now also available with licence activation for high-end outdoor VMD and Dual-Sensor detection. The new re_porter_sensor range of DSP-based recorders with up to 19 video channels and an audio channel are specially configured for perimeter surveillance applications and ideally suited for event triggered recording with high picture rates per camera.  The Dual-Sensor is an exceptionally reliable detection system in which Geutebruck's virtual video motion detector and its video analysis package both monitor the same video signal. This arrangement combines their different technological strengths, eliminates weaknesses and halves unwanted alarms. Dual-Sensor recognises objects by size, speed, direction of movement and status, and reports when selected target types exhibit particular behaviours. Previously only available for GeViScope platforms, Dual-Sensor is proven to outperform rivals, deliver genuinely useful information and get very, very close to eliminating all unwanted alarms. Like other re_porters, these recorders support dual channel streaming, digital matrix functionality, and come with high-grade activity detection and flexible backup functions. Thanks to the DSP-based design, easy software upgrades can maintain the state-of-the-art functionality indefinitely.Features / technical data:Application specific system reporter_sensor. The flexible hybrid recorder for digital storage and transmission of video signals using GEUTEBRUCK's optimized MPEG4CCTV compression. Especially suitable for perimeter surveillance using video motion detection and video analysis. The unit can handle up to 16 analog or digital video signals and 1 audio channel. It offers a versatile backup function and is equipped with pre-installed activity detection. The unit supports DualChannelStreaming to simultaneously record picture and audio data in live quality as well as send a live stream out to other systems via the 1 Gbit Ethernet port. The unit offers all required functions needed for a TCP/IP real virtual digital matrix switcher.MPEG4CCTV comes with the following feature list: Variable GOP length (VGL), variable frame rate (VFR), variable bit rate (VBR) with constant quality, low latency times, optimized picture presentation even in rewind mode and time synchronous playback. Supports recording and display of IP cameras from different vendors.

Add to Compare

Digital video recorders (DVRs) - Expert commentary

ONVIF Profile T and H.265: the evolution of video compression
ONVIF Profile T and H.265: the evolution of video compression

In today’s market, efficient use of bandwidth and storage is an essential part of maintaining an effective video surveillance system. A video management system’s ability to provide analysis, real time event notifications and crucial image detail is only as a good as the speed and bandwidth of a surveillance network. In the physical security industry, H.264 is the video compression format used by most companies. Some companies also employ H.264 enhancements to compress areas of an image that are irrelevant to the user at a higher ratio within a video stream in order to preserve image quality for more important details like faces, license plates or buildings. The H.265, H.264’s successor, will be increasingly used for compression in the future. Some companies are already using H.265 in their cameras and video management systems, while a host of other manufacturers are certainly preparing for its broader adoption in the years to come. Video compression technologies Reduced bandwidth and storage requirements are the primary benefits of video compression technologies Reduced bandwidth and storage requirements are the primary benefits of video compression technologies. In some cases, H.265 can double the data compression ratio of H.264, while retaining the same quality. Increased compression rate translates into decreased storage requirements on hard drives, less bandwidth usage and fewer switches – all of which reduce overall costs of system ownership. H.265 compression delivers a lower bitrate than H.264, which is relevant to end users and integrators because the lower bitrate reduces strain on hardware and can reduce playback issues. It’s very important that the compression format that is used is supported in all of the different components of a system: cameras, desktop computers on which the VMS is running and the VMS itself. It is also good for end users and integrators to understand the basics of video compression. Having a basic understanding of compression allows users to tweak settings to reduce bandwidth usage even more. Many cameras come with default settings that can be changed to ultimately reduce costs. ONVIF physical security In the physical security industry, ONVIF is working to incorporate into its specifications the use of new formats such as H.265 but is not directly involved in developing the compression standards themselves. With Profile T, the new ONVIF video profile released will employ a new media service that is compression agnostic. This means that it can support new video compression formats, including H.265, as well as new audio compression formats, with the ability to include new video and audio codecs as needed in the future without having to redesign its media service. In the physical security industry, ONVIF is working to incorporate into its specifications the use of new formats such as H.265 Standardisation organisations that are directly addressing new compression standards include the International Telecommunication Union (ITU), the Moving Picture Experts Group (MPEG) and a joint commission of the International Organization for Standardization (ISO)/International Electrotechnical Commission (IEC), which is addressing the coding of audio, picture, multimedia and hypermedia information. Other compression formats on par with H.264 and H.265 are being developed by companies such as Google. H.265 compression formats Using products that employ H.265 compression will reduce costs through bandwidth reduction, as will changing default settings on cameras, which are often conservative. Having a basic understanding of compression formats and how to tweak camera factory default settings also gives integrators the ability to further reduce bandwidth for added costs savings and increased system performance. These enhancements will analyse which parts of an image are most important and adjust local levels of compressions accordingly It is also worth noting that H.265 enhancements will likely be developed by camera manufacturers to further reduce bandwidth, as was the case with H.264. These enhancements will analyze which parts of an image are most important and adjust local levels of compressions accordingly. While H.265 itself is ready for prime time, its value as a tool for IP-based surveillance systems is dependent on support for the codec in all parts of the system – the VMS, server hardware, graphics cards and camera. Though widespread H.265 adoption is predicted, providers of these components are jumping on the H.265 bandwagon at different rates of speed. ONVIF is including support for H.265 in its new video profile, Profile T, because it believes it will become the most widely used compression format and ONVIF recognises the need to anticipate that migration as a future need of the industry. The new media service, which will be implemented with Profile T, will be future-proof in that when new compression formats are released in the future, ONVIF can adopt them very quickly. That flexibility will definitely help integrators.

HD over Coax provides cost-effective video surveillance upgrade
HD over Coax provides cost-effective video surveillance upgrade

According to IHS Market, it is estimated that there are over 60 million security cameras in the United States, and other reports say these cameras capture more than four billion hours of footage per week. Over the last decade, IP camera technology has dominated the conversation as it has provided users with a broad offering of enhanced image quality and features. With a large percentage of existing security systems relying on analogue, many end users looking for high definition (HD) video quality have been forced to take on a complete system overhaul. Infrastructure overhaul for HD video To make the switch, customers would need to change everything, from cameras to hardware to wiring– not to mention the lengthy installation process that would ensue. IP cameras also require higher Internet speeds and more cloud space. Whether constrained by budget, bandwidth or storage, many end users have been unable to adopt this new video surveillance method.Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike. By utilising the current Coaxial cables, this offering yields high definition video, while requiring minimal infrastructure changes and is an optimal surveillance choice for security customers. Plus, with new advancements and updates being made frequently to this technology, there is a solution for every security need. The enhanced alternative of HD over Coax has been warmly welcomed in the security industry, thanks to its simple solutions and ever-evolving features. Many new analogue HD cameras are “plug and play,” able to connect directly to existing Coaxial cables. This eliminates the need for a complete system change, creating cost-savings for the end user and an enhanced video quality offering. Easy solutions for HD video As a result, integrators can cost-effectively upgrade their customer’s surveillance solution while using their legacy infrastructure, making it an attractive option for end users and an easy sell for dealers. Latency in video is another common issue with network-based camera systems, where even the slightest delay in video surveillance can hinder security response HD over Coax cameras themselves are always expanding and evolving to meet a wide array of security needs. With the introduction of fisheye and multi-sensor cameras, users now have a multitude of coverage options, not to mention the introduction of 4K bringing resolution options to the same level as IP. Some newer technologies are even touting 4K cameras paired with 4K digital video recorders (DVRs) made specifically for analogue systems. Longer cables grant transmission for up to 1600 feet, double the distance of standard analogue solutions, and triple that of IP systems. This single cable is able to transmit both HD video and audio. Recently, broadcast quality audio over Coax has become available in limited models, a substantial improvement over older analogue technology, which was unable to transmit audio. Stopping video delay Latency in video is another common issue with network-based camera systems. Even the slightest delay in video surveillance can hinder security response. IP cameras are forced to compress and packetise their video for transmission. The outcome of this is a reduced number of images per video, which in turn causes delay. HD over Coax on the other hand, delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity. Additionally, the point-to-point transmission delivers uncompressed video free of lag. Another touted benefit is that, unlike IP networked cameras, analogue systems provide a more secure video transmission. With so much sensitive information housed on a businesses’ network, adding another point of network access through an IP camera can create concerns for cyber security risks. HD over Coax delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity Preventing network hacking With HD over Coax, the physical connections between the camera and DVR prevent network hacking. By keeping the video surveillance system offline, security professionals are able to direct their attention to the physical threats at hand, rather than having to focus on deterring cyber security risks. One of the primary difficulties of deploying HD video solutions is the fact that many older systems utilise a wide variety of HD standards and platforms. To make matters more complicated, after HD over Coax was brought to market, manufacturers raced to create their own version of this technology. Today, the most popular proprietary standards are HD-CVI, HD-TVI and AHD. However, integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible.Integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible Diversifying surveillance through one DVR To combat these issues, manufacturers have introduced products with more flexibility to their portfolios. One example of this is the penta-brid DVR which grants the ability to seamlessly integrate multiple technologies deployed across one application. This means that systems with diverse camera brands and technologies, such as a mix of HD-CVI, HD-TVI, AHD, analogue or IP, can be connected through one DVR. For many end users with legacy analogue systems, penta-brid DVRs give them greater freedom to choose between a variety of solutions, rather than being limited to one option. With video resolution increasing, the space needed to store the footage is similarly rising. Penta-brid technology has been able to adapt to these evolving needs, giving users ample storage space to house the HD and 4K surveillance video with some of the newest models including H.265 compression.  HD casino surveillance made simple For casinos, HD images are critical for identifying unauthorised personnel and unlawful behaviours to create a safe environment for guests and staff While HD over Coax is beneficial to many end users and integrators, those in the casino and hospitality markets find it crucial. With a combination of high profile guests, large amounts of cash on hand, constant crowds and strict industry regulations, reliable video surveillance is a must. Deploying new IP systems comes at a stiff price. When looking to upgrade their video surveillance, casinos must also be mindful of the installation process. When moving to an IP-based system, ripping out old wires and replacing them with new is the standard practice. This practice can be both disruptive and costly, not to mention gaming regulations require casino activities be monitored at all times so a complete system shutdown would result in revenue loss. This cost can be hard to justify, especially when the current legacy analogue system remains in working condition with only the lower image resolution to date it. For these scenarios, the most cost-effective option is to leverage the legacy infrastructure, replace the existing cameras with new devices, and reap the benefits that HD video has to offer without any lapse in security. For casinos, HD images are critical for identifying unauthorised personnel and unlawful behaviours to create a safe environment for guests and staff. HD over Coax cameras now offer the same resolution as IP cameras with a plug and play approach, that cuts down on expense without sacrificing quality. For businesses and applications that are unable to adopt IP technology, whether it be cost or time prohibitive, HD over Coax now features most of the same benefits IP has to offer without breaking the bank. By providing clear images in real time, maximising existing infrastructure, and affording cyber security benefits, HD over Coax provides an attractive solution for many end users and integrators.

Video surveillance must modernise in storage, recording and on-demand access
Video surveillance must modernise in storage, recording and on-demand access

Dollars spent by video surveillance customers must go towards ensuring high-availability capture, storage and on-demand access to live and archived video. Reaching this goal mandates high-availability of independent components – camera, network, storage (edge, external), internet connectivity, display, all Video Management Software (VMS) components and an architecture that can take advantage of this. In this note, we focus on seeing our way through to a video surveillance architecture, that provides high availability storage, access to live and stored video content. Of all options available to store recorded video, edge recording is the only one that is unaffected by network failure Edge recording Of all options available to store recorded video, edge recording is the only one that is unaffected by network failure. This makes edge storage a must-have. But, this has some limitations at present: Edge storage capacity is limited. Edge media has a short lifetime, rated only for thousands of hours of continuous recording. Most cameras are not secure and physical damage to the camera could lead to catastrophic loss of edge stored content. As storage and compression technology evolve, the constraints imposed by (1) and (2) could go away. However, securing cameras will continue to be a barrier for most installations. Secure external storage It is thus imperative to also store video in secure external storage. Such an architecture uses edge storage to fill in content gaps created by network, external storage outages. As edge storage technology improves, larger gaps can be filled in, but one will always need external storage. By our definition, ‘external storage’ is a solution stack that includes storage media and all software (including VMS) that provide access to this storage. Access to live and archived video Access to live video can either be met by external storage or directly by the camera Every surveillance solution needs to provide access to live and archived video. Access to live video can either be met by external storage or (and) directly by the camera. All things being equal, having the camera directly provide live video access, is a higher-availability solution. There is dependence on fewer components in the chain. Solutions in the market use one of the above two approaches for access to live video. Due to limited capacity and low physical security of edge storage, it makes sense at present, to have external storage meet all requests for archive video. Thus, we are led to an architecture that has heavy dependence on external storage. Dual-recording For high-availability, external storage must be architected with redundancy. Ideally, independent components that make up external storage – storage media, associated hardware and software (including VMS components), should be individually redundant and have smart interconnectivity. However, solutions in the market rigidly tie these components together. Failure of a single component causes failure of external storage. For e.g. hardware failure of a server causes VMS component failure AND storage failure. DR provides a smart way to provide high-availability for external storage For these solutions in the market, high-availability is achieved by having additional external storage units that step-in during outages of primary units. If these additional units continuously duplicate primary units, access gaps are minimised, and archive access is un-affected during primary unit outages. This is the idea behind Dual-Recording (DR).  To meet cost budgets, these additional units can be configured to store subsampled (framerate, resolution) video content. A small number of additional units can support concurrent outages of all primary units. A few-to-many redundancy. Rising need for dual-recording Most cameras cannot be physically secured, and video content produced by a camera must be stored externally. Many VMS solutions use external storage to service live video access requests. Edge storage limitations impose restrictions on edge archive access at present. So, external storage is used to service requests for archive access too. Thus, a surveillance system ends up being over-dependent on external storage. DR provides a smart way to provide high-availability for external storage. As edge storage improves, it will be able to service archive access requests. VMS software will need to evolve, to use this capability smartly.
