Mitsubishi Electric are pleased to be able to offer complete security solutions from recording to storage and display
Mitsubishi Electric are pleased to be able to offer complete security solutions from recording to storage and display

COMING SOON! DX-TL304E DX-TL308E DX-TL5716EThe DX-TL304E and DX-TL308E are compact and affordably priced 4 and 8 channel DVR's that all utilise MPEG-4 compression providing reliable 24/7 surveillance.  The 304E and 308E provide real time recording up to 100 frames per second and 200 frames per second respectively.  Designed as compact and lightweight solutions, both DVR's can easily and conveniently be installed in virtually any location.  With a removable front panel for HDD access, up to two high-capacity HDDs are accommodated inside the unit to ensure a user friendly and easy maintenance DVR. Both models support multiple protocols for PTZ dome cameras.NEW! IP Camera SolutionsMitsubishi will be also be demonstrating their new IP security cameras on the stand. All have been designed as professional network cameras that feature full frame rate and quality settings up to D1. All IP cameras have a recording rate of 25 pictures per second and are compatible with MPEG-4. Available are indoor and outdoor vandal proof dome cameras that can notify an incident via email or FTP as well as internal network cameras that feature high resolution imaging quality, video motion detection and alarm input and output.DX-TL4EA perfect solution as an upgrade from an analogue security system to digital, the DX-TL4E is a 4 channel economically priced DVR that is quick and easy to set up and provides high quality recording and play back functionality. This DVR has an advanced video compression that enables long term recording with its 100 images per second recording speed.DX-TL4509E / DX-TL4516EThe DX-TL4509E a 9-channel digital recorder, and the DX-TL4516E, a 16-channel version come equipped with many of the advanced features of Mitsubishi's most advanced and highly regarded DVR, the DX-TL5000E. These include triplex functionality and built in motion detection, as well as a dual monitor output that allows for the simultaneous monitoring of both live and recorded footage on monitor A and B positions. Fully featured, the 4516 come as standard with 800Gb of HDD, and the4509E with 400GB HDD. Both models can accommodate 2 HDDs internally providing a maximum of 1Tb, assuming 500Gb drive are installed. Up to 15Tb, utilising 500GB HDDs can be added externally using the ZD6UE HDD extender box. Utilising the latest JPEG2000 compression technology for high quality, fine detailed pictures both 9 and 16 channel DVR's come with a built-in USB, CD/DVD-R/RW drive.

Add to Compare
Mitsubishi introduces new range of MPEG4 digital recorders and IP cameras
Mitsubishi introduces new range of MPEG4 digital recorders and IP cameras

NEW! DX-TL4EA perfect solution as an upgrade from an analogue security system to digital, the DX-TL4E is a 4-channel economically priced DVR that is quick and easy to set up and provides high-quality recording and playback functionality.  This DVR has an advanced video compression that enables long-term recording with its 100 images per second recording speed.COMING SOON! DX-TL304E, DX-TL308E and DX-TL5716EThe DX-TL304E and DX-TL308E are compact and affordably priced 4- and 8-channel DVRs and the DX-TL5716E is an advanced 16 channel version.  All utilise MPEG-4 compression providing reliable 24/7 surveillance.The 304E and 308E provide real time recording of up to 100 frames per second and 200 frames per second respectively.  Designed as compact and lightweight solutions, both DVRs can easily and conveniently be installed in virtually any location.  With a removable front panel for HDD access, up to two high-capacity HDDs are accommodated inside the unit to ensure a user friendly and easy maintenance DVR.  Both models support multiple protocols for PTZ dome cameras.The DX-TL5716E comes with a recording rate of 400 frames per second and features two built in high capacity HDDs, as well as a built-in USB, CD/DVD-R/RW drive a unique and advanced feature in today's market.  All of Mitsubishi's new MPEG-4 recorders come with motion detection, time and date search facility, are easy to install and operate, and can be connected easily to a DX-KB5 keyboard for advanced control.NEW! IP camera solutionsMitsubishi also demonstrated their new IP security cameras on the IFSEC stand.  All were designed as professional network cameras that featuring a full frame rate and quality settings up to D1.  All our IP units have a recording rate of 25 pictures per second and are compatible with MPEG-4.  Available are indoor and outdoor vandal proof dome cameras that can notify of an incident via email or FTP are available as well as internal network cameras that feature high-resolution imaging quality, video motion detection and alarm input and output.

Add to Compare
Mitsubishi Electric’s most dynamic MPEG-4 DVR - the DX-TL5716E
Mitsubishi Electric’s most dynamic MPEG-4 DVR - the DX-TL5716E

Mitsubishi Electric, a world leader in the design and manufacture of advanced security solutions, is pleased to introduce a new 16 channel digital recorder, the DX-TL5716E. Complementing Mitsubishi's comprehensive range of security solutions, the DX-TL5716E utilises MPEG-4 compression providing reliable 24/7 surveillance.  Ideal for multi-site locations, this DVR is the perfect solution for domestic, retail, banking and corporate applications.The DX-TL5716E is equipped with a range of features, including built in motion detection, time and date search facilities and a multiplexer output function that allows up to 6 different viewing modes for the simultaneous monitoring of both live and recorded footage. Built with real time recording and playback functionality, the DX-TL5716E provides up to 400 frames per second, enabling the reproduction of high quality, detailed images; in addition this DVR benefits from a 450TVL resolution, further enhancing the accuracy of recorded images.Mitsubishi's DX-TL5716E comes as standard with a built in CD-R/RW/DVD-R/RW drive which is a key feature in today's market, as well as multiple USB ports. Economically priced, a new user-friendly interface has been incorporated into the design; the GUI (graphical user interface) features large icons which represent different menu options easily selectable utilising an external mouse. Two high-capacity HDD's can be accommodated inside the unit and an additional 18 HDD's can be added externally if more memory is required using a DX-ZD6E memory expansion unit. Designed as a compact and lightweight solution, the DX-TL5716E can easily and conveniently be installed in virtually any location. Benefiting from a number of security features, including password and data tampering detection, this DVR can be programmed to restrict access to authorised users only. Furthermore, Mitsubishi has developed its own software solutions, PC200 and Nethunter IP. PC200 has been designed to manage DVR's only, while Nethunter IP can operate with both DVR and IP systems.All of Mitsubishi's DVR's are fully featured, easy to install and operate and can be connected easily to a DX-KB5 keyboard for advanced control. For added peace of mind Mitsubishi provides a 24 month warranty and support from its own in-house technical and service team.

Add to Compare
Mitsubishi Electric's DVR range includes the DX-TL4E, DX-TL4509E, DX-TL4516E and the DX-TL5000E
Mitsubishi Electric's DVR range includes the DX-TL4E, DX-TL4509E, DX-TL4516E and the DX-TL5000E

Economically priced, the DX-TL4E is the latest DVR offering from Mitsubishi designed specifically to meet the requirements of small retail outlets, commercial businesses, petrol stations and convenience stores, as well as domestic markets. A perfect solution as an upgrade from an analogue security system to digital, the DX-TL4E is quick and easy to set up and provides high-quality recording and playback functionality.  In addition, this DVR features Mitsubishi's own Dynamic Digital Compression™, an advanced video compression that enables long-term recording with its 100 images per second recording speed.  When set in standard mode, the DX-TL4E provides more than 50 days of continuous recording.Benefiting from a compact, slim and sleek design, the DX-TL4E is lightweight at 3.2kg - making it ideal for locations where space may be an issue.Mitsubishi's DVRs benefit from a number of advanced features including a dual multiplexer output that allows both live and recorded footage to be recorded simultaneously. Mitsubishi's 9 and 16 channel DVRs utilise the latest JPEG2000 compression technology, ensuring high-quality, fine detailed pictures are captured.  As standard, the DX-TL4509E and DX-TL4516E come with 400Gb HDD with the option to add an additional internal drive as well as another 7Tb externally, using the ZD5UE hard disk extender box.The DX- TL5000E is Mitsubishi's most advanced recorder and comes with 500Gb HDD and a recording rate of 200pps, with the option to upgrade to 35Tb.All of Mitsubishi's DX-TLs are now Kalagate approved and are suitable for a range of applications including retail, banking, corporate and the public sector; and all come with a 24-month warranty and support from Mitsubishi's in-house and service team.Visit us at IFSEC, Birmingham NEC 12-15th May 2008, Stand 13021

Add to Compare
