Dahua Technology DH-IPC-HDW3849H-AS-PV-PRO IP camera Specifications

Dahua AI-powered 8MP TiOC Pro WizColor Eyeball Camera

Product Profile

Developed by Dahua Technology, WizSense is an AI-driven product line using independent AI chips and deep learning to accurately detect humans and vehicles. It offers intelligent, user-friendly solutions built on Dahua’s advanced technology.

Key Features

AI Coding & Deep Learning: Saves bandwidth and storage while enabling smart features like perimeter protection, Smart Motion Detection (SMD), Acupick, and AI Scene Self-adaptation (AI SSA).

Starlight Technology: Produces clear, vivid images in low light using a large aperture lens.

WizColor Technology
Combines AI-ISP, large pixel sensors, and wide aperture lenses to deliver vibrant, full-color images at night using available ambient light—without sacrificing image quality or monitoring distance.

Siren & Light Deterrence
Built-in sirens and customizable voice alarms respond to perimeter breaches for real-time deterrence.

Smart Motion Detection (SMD) 4.0
Classifies motion triggers to reduce false alarms from non-targets like animals. With an AI NVR, Quick Pick helps rapidly locate human and vehicle targets.

AI-ISP
Adapts imaging to different scenes for detailed, high-quality visuals.

Cybersecurity
Features include authentication, access control, encryption, and trusted protection against cyber threats.

Durability (IP67 & Wide Voltage)

IP67-rated: Dustproof and water-resistant up to 1m depth for 30 minutes.
Wide voltage range: Tolerates ±30% input voltage for reliable outdoor use in unstable power conditions.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Dahua Technology
Manufacturer	Dahua Technology Ltd
Category	CCTV>IP cameras
Model code	DH-IPC-HDW3849H-AS-PV-PRO
Series	WizSense Series
Chip Inch Size	1/1.8 inch
Colour Type	Colour / Monochrome
Resolution	8 MP resolution
Sensitivity Lux	0.0008 Lux@F1.0 (Color, 30IRE) ; 0.0004 Lux@F1.0 (B/W, 30IRE) ; 0 lux (Illuminator on)
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: Max. 8.2 W (12 VDC); 10 W (PoE)
Focal Length mm	2.8 mm; 3.6 mm
Wide Dynamic Range	Yes
Network Properties	Image Frame Rate: 25/30 fps Interface: RJ-45 (10/100 Base-T) Network Protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter Range	Auto/Manual 1/3 s–1/100,000 s
S/ N (Signal/ Noise) Ratio dB	>56 dB
Compression Type	H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Physical Specifications	Weight g: 800 Dimensions mm: Φ122.0 x 116.1
Environmental Specifications	Operating Temperature ^oC: -40 ~ +60 C (-40 ~ +140 F) Protection: IP67 Operating Humidity %: ≤ 95
Additional info	H.265 codec, high compression rate, ultra-low bit rate. Built-in multi-core light, the max. IR distance is 30 m and the max. warm light distance is 30 m. ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments. Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human). Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection. Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in dual Mic; 1-ch speaker; support two-way talk.
Download PDF version Download PDF version

Make

Dahua Technology

Manufacturer

Dahua Technology Ltd

Category

CCTV>IP cameras

Model code

DH-IPC-HDW3849H-AS-PV-PRO

Series

WizSense Series

Chip Inch Size

1/1.8 inch

Colour Type

Colour / Monochrome

Resolution

8 MP resolution

Sensitivity Lux

0.0008 Lux@F1.0 (Color, 30IRE) ; 0.0004 Lux@F1.0 (B/W, 30IRE) ; 0 lux (Illuminator on)

Electrical Specifications

Voltage: 12 V DC, PoE
Power Consumption: Max. 8.2 W (12 VDC); 10 W (PoE)

Focal Length mm

2.8 mm; 3.6 mm

Wide Dynamic Range

Yes

Network Properties

Image Frame Rate: 25/30 fps
Interface: RJ-45 (10/100 Base-T)
Network Protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P

Back Light Compensation

Yes

Auto Gain Control

Yes

White Balance

Yes

Electronic Shutter Range

Auto/Manual 1/3 s–1/100,000 s

S/ N (Signal/ Noise) Ratio dB

>56 dB

Compression Type

H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

Physical Specifications

Weight g: 800
Dimensions mm: Φ122.0 x 116.1

Environmental Specifications

Operating Temperature ^oC: -40 ~ +60 C (-40 ~ +140 F)
Protection: IP67
Operating Humidity %: ≤ 95

Additional info

H.265 codec, high compression rate, ultra-low bit rate.
Built-in multi-core light, the max. IR distance is 30 m and the max. warm light distance is 30 m.
ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in dual Mic; 1-ch speaker; support two-way talk.
